NETMACS II
MONITOR, ALARM, & CONTROL
SYSTEM
Product Manual Part Number: 438 0193PD
Issue 16, February 2007
Engineer: T. W.
Approved: T. W.
PECO II, Inc. 1376 State Route 598 Galion, OH 44833-0910
PECO II, Inc. 1376 State Route 598 Galion, OH 44833-0910
Phone: 419.468.7600 Visit us on the web at www.peco2.com
Phone: 419.468.7600 Visit us on the web at
www.peco2.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NETMACS II and is the answer not in the manual?

Questions and answers

Summary of Contents for PECO II NETMACS II

  • Page 1 Issue 16, February 2007 Engineer: T. W. Approved: T. W. PECO II, Inc. 1376 State Route 598 Galion, OH 44833-0910 PECO II, Inc. 1376 State Route 598 Galion, OH 44833-0910 Phone: 419.468.7600 Visit us on the web at www.peco2.com Phone: 419.468.7600 Visit us on the web at...
  • Page 2 PECO II, Inc. NETMACS II Manual -This page intentionally left blank- Page 2 Issue 16, February 2007...

  • Page 3: Table Of Contents

    PECO II, Inc. NETMACS II Manual Table of Contents TABLE OF CONTENTS....................3 FOREWORD........................5 PRODUCT INFORMATION .................... 5 WARNINGS ........................6 CAUTIONS ........................6 SECTION 1: INSTALLER INFORMATION..............7 CHAPTER 1: GENERAL INFORMATION....................7 GENERAL ........................... 7 SYSTEM DESCRIPTION......................7 CHAPTER 2: MECHANICAL INSTALLATION..................
  • Page 4 PECO II, Inc. NETMACS II Manual - This page intentionally left blank - Page 4 Issue 16, February 2007...

  • Page 5: Foreword

    PECO II, Inc. NETMACS II Manual Foreword This manual is intended to help the user of the NETMACS II to install, test, troubleshoot, and understand the system. If you should have any questions or problems, please contact one of the following sources: SERVICE - If for any reason further assistance is needed on any power equipment, complete engineering and field service groups are available in Galion, Ohio, to assist you in any way possible.

  • Page 6: Warnings

    80 percent of their ampere rating. Use of an attachment other than one approved by PECO II will void any and all warranties, implied or other, and will increase risk of fire, or may possibly cause electrical shock, injury, or death to personnel.

  • Page 7: Section 1: Installer Information

    1-5) and extend plant alarms created within the NetMACS II. Figure 1-1. Front View of NetMACS II NOTE: If the NetMACS II will be used with a TL1 SNMP Bridge, refer to manual #4380201PD for further TL1 details.

  • Page 8: Chapter 2: Mechanical Installation

    3. Inspect the equipment. Note any shipping damage, if present, and immediately notify the carrier and PECO II at the numbers listed at the front of this manual. It is recommended that if there is shipping damage, photographs be taken of the damage.
  • Page 9 PECO II, Inc. NETMACS II Manual Figure 1-3. Wall Mounting Brackets (NetMacs shown) WALL MOUNT OPTION (see Figure 1-3, detailed instructions for use and installation are also on the print) 1. Use brackets 4082048P for 19" mtg. For 23" mounting use brackets 4082048P-2.

  • Page 10: General

    Note 2: Wire sizes are based on the voltage drop considerations and the National Electric Code Table 310-16 for copper wire. 1.5 GENERAL The NetMACS II is installed with -20 to -60 VDC input power. In addition, several connections will be made for monitoring points, alarms, and interfaces. 1.6 INPUT POWER REQUIREMENTS (See The T-drawings contained as an attachment to this manual, the plant manuals, and the associated configuration sheets for diagrams of connections.)

  • Page 11: Analog Inputs (Ai), Digital Inputs (Di), & Digital Outputs (Do)

    All Analog Inputs (AI) and Digital Inputs (DI) are to be wired by the on-site installer. The inputs are on the back of the NetMACS II. The top row is for the positive input, while the bottom row is for the return. See Figure 1-5 and Table 1-2 and 1-3.

  • Page 12: Communication Installation

    PECO II, Inc. NETMACS II Manual 1.8 COMMUNICATION INSTALLATION A. Connect the communications to the NetMACS II as follows: 1. For local communications, connect to the serial interface via the DB25 connector located on the back of the panel. A null modem cable is required for connecting to a PC. For a DB9 PC connection, a DB25 to DB9 adapter is needed.

  • Page 13: Chapter 4: Initial Turn On & Acceptance Procedures

    User’s PC must be changed initially in order to connect to the Gateway. This allows the IP address of the Gateway to be changed to the address as assigned above. The IP address for the NetMACS II is stated on a tag, which is attached to the unit. This manual uses the Factory default IP address (Users IP address may be different) for the Gateway, which is 10.1.4.50, the IP address of the User’s PC must first...
  • Page 14 5. Click OK on all screens. The PC may require a reboot, if so reboot now. 6. Connect the crossover (Ethernet) cable to both, the PC and the NetMACS II. c. Abbreviated Instructions for Changing the User PC’s IP Address in Windows XP...
  • Page 15 PECO II, Inc. NETMACS II Manual 1. Open the network connections on the PC, as shown in figure 1-9. Figure 1-9 2. Right click on the LAN connection and select properties. Refer to Figure 1-10 below. Figure 1-10 Issue 16, February 2007...
  • Page 16 Default gateway 10.1.1.1 5. Click OK on all screens. The PC may require you to reboot, if so reboot now. 6. Connect the crossover (Ethernet) cable to both, the PC and the NetMACS II. Page 16 Issue 16, February 2007...
  • Page 17 PECO II, Inc. NETMACS II Manual 3. Serial Connection The Serial Connection does not require the IP address of the User’s PC to be changed. Rather, it uses the Direct Cable Connection component of the Windows9X™ Operating System to establish a PPP (point to point protocol) connection to the Gateway.
  • Page 18 PECO II, Inc. NETMACS II Manual D. Changing the IP Address of the Gateway (Refer to section 1.10.3) 1.10.2 STARTING CON_UI NOTE: This manual will use Drive A as the Floppy drive, the user’s computer Floppy Drive may differ. From the Start button, choose Programs, then MS-DOS™ Prompt. An MS-DOS™ window will open on the screen.

  • Page 19: Operational Checkout

    For the entire operational checkout, a computer with Con_ui loaded is needed (refer to paragraph 1.10). A. Connect a PC to the NetMACS II communication port RS-232 (DTE) J14 (Gateway) using a customer supplied null modem cable, or via the RJ45 Ethernet port (J15). Refer to sections 2.1.7 and 2.1.8.
  • Page 20 If temperatures differ by more than 2 degrees, enter an adjustment for the channel. H. Using Con_ui, clear the alarm log of the NetMACS II. (Type access, then enter, type clear, then enter, type alarm log, then enter.

  • Page 21: Section 2: Detailed System Component Information

    As shipped, a Factory Configuration is loaded into the NetMACS II, however, programming of the NetMACS II is relatively simple due to the internal operating system (user interface, DOS and Text based). Simple prompts at each access level provide guidance to the user. Once the prompts have been satisfactorily answered, the system will accept the programming routine without any additional programming required by the user.

  • Page 22: Optional Components

    2.1.9 24 UNIVERSAL MONITORING POINTS The NetMACS II is equipped with 24 universal monitoring points that can be either analog or digital. 2.1.10 CHANNELS The NetMACS II is equipped with 24 universal monitoring points to monitor either Digital or Analog Inputs, as determined by the user.

  • Page 23: Configuration Arrangement

    PWBs that are replaceable by field service technicians. The installation of these components is covered in paragraph 2.5, PWB Installation. The system is completely repairable to the board level in the field. The NetMACS II Control PWB can be removed and installed from/to the system.

  • Page 24: Battery Removal/Replacement

    Section 1.11. 2.6 BATTERY REMOVAL/REPLACEMENT There is a 3.6 V lithium battery installed on the NetMACS II Control PWB (figure 2-1) to retain system memory in the event the power was lost to the system. This battery should be replaced annually.

  • Page 25: Section 3: Specifications And Troubleshooting

    The following information is intended to give the user a quick reference to information that is necessary to install and operate the system. Included are input requirements and other information that may be useful during the operation or installation of the NetMACS II. Input Requirements:...

  • Page 26: Troubleshooting

    E. Tripped circuit breakers. F. Broken wires. G. Check the indicators on the NetMACS II Control PWB to ensure the correct ones are illuminated and the timing is correct. Timing should be approximately on one second and then off one second for the green LED.
  • Page 27 NOTE: In the following step, when the DC input and the memory backup battery are removed, the NetMACS II memory will be lost. After the DC power and the NetMACS II memory backup battery have been reinstalled, re-program the NetMACS II.
  • Page 28 PECO II, Inc. NETMACS II Manual e. Connect using the defaults per the manual f. Set desired IP Address per Section 1.10.3 of this manual g. Power down. h. Return Dip Switch settings to state in step ‘b.’ i. Change to your IP address per Section 1.10 using Setup -> Network -> IP….. -> Ethernet 2.

  • Page 29: Section 4: System Configurations / Parts List

    In many cases the parts are used on all systems produced by PECO II. If the component is used on all systems, the configuration model code will have a dash.
  • Page 30 PECO II, Inc. NETMACS II Manual -This page intentionally left blank- Page 30 Issue 16, February 2007...

  • Page 31: Attachments

    PECO II, Inc. NETMACS II Manual ATTACHMENTS Issue 16, February 2007 Page 31...
  • Page 32 PECO II, Inc. NETMACS II Manual -This page intentionally left blank- Page 32 Issue 16, February 2007...
