Summary of Contents for NS P50

Page 1 Environmental Monitor Version 4.7 22 September 2015 P50 Product Manual...
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION WARRANTY BEST INSTALLATION PRACTICE SAFETY INFORMATION SENSORS MODELS APPROVALS ELECTRICAL SPECIFICATIONS COMMUNICATIONS MAINTENANCE PROCEDURES FAULT FINDING TERMS AND CONDITIONS ANNEXURE A RISK ASSESSMENT INTRODUCTION RISK IDENTIFICATION STANDARDS AND COMPLIANCE IDENTIFIED REGULATORY RISK HAZARD IDENTIFICATION DATA ANALYSIS INCIDENT INVESTIGATION P a g e...
Page 3 Manufactured and Distributed by: Ningi 22 Langa Crescent Corridor Hill Witbank, MP 1035 South Africa Phone +27 13 656 3147 Fax +27 13 656 3190 Sales sales@ningi.com Queries: admin@ningi.com Website: www.ningi.com Technical Support: support@ningi.com P a g e...
Page 4: Introduction
• Smoke (MOS) (NOT Recommended) **Although the P50 can be fitted with a MOS sensor we do not recommend this options for the P50, we therefor recommend a dedicated MOS sensor such as our S16 monitor. The P50 is South African manufactured and is certified to the International Standards and Compliance IEC (SANS) 10086-2:2006.
Page 5: Warranty
The P50 operates as a user friendly device with real time data available to the user. All the measurements and data are available on the 16x2 OLED display, audio/visual indicator and RS485 network. All parameters are adjustable via personal computer.
Page 6: Best Installation Practice
BEST INSTALLATION PRACTICE This section of the manual is intended as a guideline only for the installation of the P50 environmental sensor as shown in a typical underground operation. This guideline does not supersede local authority or rules for your environment as installations are required to be approved by the authoritative person responsible for the ventilation/environmental monitoring where the device is to be located.
Page 7 Figure 2 – Path Position The P50 should not be mounted to close to either side of the ventilation path, or where cross flows could influence the reading. Figure 3 – Installation Attitude When the P50 is hung it should be hung as level as possible.
Page 8 Figure 4 – Directional Position For optimal Velocity readings the P50 should be positioned ensuring the Sensor indicated is positioned in the airflow Sensor to remain in the airflow Air Flow P a g e...
Page 9: Safety Information
Operating temperature range -10°C to 50°C • Response time 30 sec Methane (CH4) P50 High quality sensors are used to ensure long term reliability and accurate measurements. The sensor has an effective range of 0 to 100%, but to ensure a better resolution the CH4 sensor is optimized to measure a range of 0 to 5%.
Page 10 Methane (CH4) P51 High quality sensors are used to ensure long term reliability and accurate measurements. The sensor has an effective range of 0 to 1000000ppm, but to ensure a better resolution the CH4 sensor is optimized to measure a range of 0 to 50000ppm. Specifications •...
Page 11 Oxygen (O2) The oxygen sensor measures the full range accurately and consistently Specifications • Sensor range 0 to 30% • Operating range 0 % to 30% • Operating temperature range -20°C to 50°C • Response time < 15 sec Barometric pressure A high accuracy pressure sensor is used to measure absolute barometric pressure.
Page 12 Ambient temperature The ambient temperature sensor has long term stability measuring in a range of 0 to 100% RH (Normal Operating Range and is condensation resistant) Specifications • Sensor range -40°C to 125°C • Normal Operating range 20°C to 60°C •...
Page 13 Hydrogen (H2) High quality sensors are used to ensure long term reliability and accurate measurements. The sensor has an effective range of 0 to 1000ppm. Specifications • Sensor Range 0 to 1000ppm • Operating range 0 to 1000ppm • Operating temperature range -20°C to 50°C •...
Page 14: Models
Power Off In order to save battery power the P50 will shut down when the external power is removed and the P50 unit is placed upside down. The P50 will resume normal operation when the external power is restored regardless of the orientation of the P50.
Page 15: Approvals
APPROVALS Marking: Type: P50 Sensor Ex rating: Ex ia 1 (-20°C to +50°C) IA No: MASC M/11-437X Serial No: (See validity of report) Ingress Protection: IP65 Safety Parameters: Connector P5 Ui = 18V Li =0 Ii = 3A Ci =0 Pin 3 w.r.t 4...
Page 16: Electrical Specifications
Battery capacity 2200 2200 4400 Battery Voltage RS485 baud rate 2400 9600 57600 Local alarm Relay Contacts P50 220V Relay Contacts P50 220V Relay Contacts P50 Exia VCD(Ex) Relay Contacts A (Ex) Connections 0-EXIA Grey Cable Ningi Cable Yellow...
Page 17 220V Grey Cable Ningi Cable 220V Neutral Yellow Blue 220V Live RS485 A/+ Green RS485 B/- Orange COM 1 Purple N/O 1 Purple COM 2 Grey N/O 2 Grey 16 | P a g e...
Page 18: Communications
COMMUNICATIONS The P50 utilises an Isolated RS485 communication setup standard on all models. The Modbus RTU protocol is used for all real time data and configuration settings. Modbus RTU All sensor readings and configuration settings are available via the RS485 Modbus RTU network.
Page 19 The alarm trigger register is a bitwise register indicating if the P50 is in an alarm condition, zero indicating no alarm condition. The alarm register bits are only active when the alarm levels has been set on the P50.
Page 20 Register Description Unit PWord 40001 Air Velocity m/s/10 40002 CH4/VOC %/10 40003 1000 40004 Vin (Supply Voltage) VDC/10 40005 Ambient Temperature °C 40009 Mode 65535 40010 WS Alarm m/s/10 40011 WS Delay 9999 Sec/10 40012 CH4/VOC Alarm %/10 40013 CH4/VOC Delay 9999 Sec/10 40014...
Page 21 Register Description Unit Pass Word Level 40129 CH4/VOC Delay Up 65535 Sec/10 40130 CO Delay Up 65535 Sec/10 40131 Smoke Delay Up 65535 Sec/10 40133 O2 Delay Up 65535 Sec/10 40139 CO2 Delay Up 65535 Sec/10 40142 WS Delay Up 65535 Sec/10 40145...
Page 22: Maintenance Procedures
Spare MAINTENANCE PROCEDURES Calibration To ensure the correct operation and legal compliance, the P50 is to be submitted for calibration on a 6 monthly basis. The calibration includes a detailed functionality check and all gas sensors are tested and certified to comply with the required operational specifications.
Page 23 2. Ensure there are no kinks, twists, or holes in the gas pipe. 3. Ensure the gas pipe is correctly fitted to the gas hood. 4. Extend the pole to a comfortable length in order for the P50 to fit correctly and securely into the gas hood.
Page 24 Figure 5 – Maintenance of your P50 Ensure that these points are Wiped clean Dirt and built up of debris will impact on accuracy of readings 23 | P a g e...
Page 25: Fault Finding
FAULT FINDING General Ensure there is no damage to the unit, this will void the warranty and the IS approval where applicable Ensure the correct cable is used, IS certification will indicate the correct cable for IS installations. For non-IS installations, the incorrect cable will result in larger voltage drops and the unit may not function as intended.
Page 26: Terms And Conditions
Ningi (PTY) LTD was negligent regarding the design or manufacture of the part. P50 is a registered trademark of Ningi (PTY) LTD. Ningi (PTY) LTD does not assume liability for the use of this product beyond the original purchase price of the product.
Page 27: Annexure A
ANNEXURE A P50 Risk Assessment and Product Risk Register 26 | P a g e...
Page 28 P50 Risk Assessment and Risk Minimization 27 | P a g e...
Page 29: Risk Assessment Introduction
The intent and purpose of this Product Risk Assessment and Risk Minimization document is to aid and assist the product owner in the safe operation of the P50 Environmental Monitor and to identify and outline any known risks associated with not only the product itself but also its associated operational functionality.
Page 30: Risk Identification
RISK IDENTIFICATION The following list by association is the possible risks identified with the P50 holistically, its operational, or physical functionality. Corrective or mitigated actions and methodology of managing such risks are documented herein to indicate a systematic process to ensure that legislative compliance and best quality of service can be obtained within a reasonable and practicable timeframe and/or cost to suit both manufacturer and customer.
Page 31: Identified Regulatory Risk
(Group II) shall be covered by an IA certificate. • SANS 10086-2:2006 The P50 fully complies and is certified to form part of a system loop approval which is regulated by the above SANS 10086-2 standard. IDENTIFIED REGULATORY RISK It is common in the field of engineering and production that changes is regulatory,...
Page 32: Hazard Identification
RSK-NS-P50. The appropriate action as indicated in RSK- NS-P50 should then be followed as the best course of action. Data analysis includes a relevant and up to date calibration certificate for each P50 environmental monitor.
Page 33: Incident Investigation
INCIDENT INVESTIGATION Incident investigation shall commence where the risk assessment and risk register steps have been followed and exhausted to no avail. The incident investigation shall engage all elements of the incident and the process shall follow whichever course is necessary to produce the required outcome which will lead to full close-out of the investigation immediately preceded by a full investigation report to follow.
Page 34 22 September 2015 P50 Product Manual...
Page 35 Intentionally Blank Page 22 September 2015 P50 Product Manual...
