Summary of Contents for Deep Innovations PoolScout
- Page 1 PoolScout Owners Manual V1 • July 2022...
-
Page 2: Installa�On
PoolScout Owners Manual Before you begin Important Safety Instruc�ons What’s Included What’s Needed Installa�on Requirements Wiring Overview Installa�on How to Install PoolScout The Ideal Moun�ng Loca�on Camera Adjustments Moun�ng Junc�on box Ethernet Cable PoolScout Camera Power Cable Wired Alarm Opera�on Ge�ng Setup... - Page 3 Virginia Graeme Baker Pool & Spa Safety Act. WARNING: When you place the PoolScout System in “Shut Down” mode, the PoolScout System will NOT operate to accomplish the Purpose; and all its pool safety functionality will be disabled and it will NOT work to detect or warn you of any hazardous conditions associated with your Pool or any Pool Patron.
-
Page 4: What's Needed
Internet with at least 5.0 Mbps upload speed • Available ethernet port on the home network’s router • A mobile device running the PoolScout app on at least iOS 12 or Android 6.0 (available on the AppStore and Google Play) • Power drill and drill bits •... - Page 5 Before you begin Wiring Overview PoolScout Camera Ethernet Cable These connec�ons are made inside the junc�on box Power Cable ← to Router Wired Alarm...
- Page 6 Junction Box from indoors. The power supply will be plugged into an indoor electrical socket as shown on page 4 and 6. The ideal mounting height for the PoolScout Camera is 7-10 feet off of the ground tilted downward. The Alarm Module must mount close enough to the camera so that the Alarm Cable will reach.
- Page 7 Shouldn’t interfere with its surroundings or be vulnerable to damage • Should be accessible from the inside of the exterior wall where the PoolScout will be mounted • Should allow for the 100 foot ethernet cable to be run from the home network’s Router...
- Page 8 Installa�on Camera Adjustment The PoolScout Camera will fasten to the supplied Junction Box and its mount has a fully articulating hinge. By loosening the locking screws, you can rotate the mount and camera as shown in the diagram below. Loosen the locking screws and roughly position the camera in its intended location 1.
- Page 9 Power Adapter As shown above, an access hole may be needed to run the cables that will power and communicate with the PoolScout system. An existing outdoor opening may be considered if you can route the cables through from indoors. If not, a hole will need to be drilled.
- Page 10 Installa�on Junc�on Box After drilling the access hole, remove the Junction Box cover and rear knockout. Center the box over the hole to test fit. Position the exit fitting (used for Alarm Module wiring) where desired. When satisfied, spread caulk around the outside back of the Junction Box, leaving a small space at the bottom for water to run out.
- Page 11 When routing is complete, secure the cable along the run using the supplied cable clips. PoolScout Camera The PoolScout Camera mounts to the Junction Box cover using four stainless steel fasteners into pre-drilled holes. Do not install the box cover and camera until wiring is completed.
- Page 12 Installa�on Power Cable Plug the 100’ Power Cable into the Power Adapter. Find a convenient indoor wall receptacle and position the Power Adapter in a permanent location close by (do not plug it into the receptacle until installation is complete). Run the other end of the 100’...
- Page 13 Wired Alarm As shown below, the one side of the Power Splitter will plug into the PoolScout Alarm Cable. The Alarm Cable power connector will come prewired to the RED and BLK conductors. In addition to the power connector, there are two additional conductors (WHT and YEL) that must be wired to the camera’s alarm connector.
- Page 14 QR code found on the underside of the PoolScout camera (if the QR code on the camera is not available, the QR code can also be found on the side of the PoolScout Camera box).
- Page 15 Opera�on Having Issues? For further information or technical support,: Email: support@poolscout.co Call: +1 (737) 252-7665...
- Page 16 PoolScout is a registered trademark of Deep Innovations Ltd © 2017-2020, Deep Innovations LLC...
