Summary of Contents for elint FCAM3000SMART
- Page 1 INSTALLATION NSTRUCTIONS FLOOD LIGHT SECURITY CAMERA For more support, please email us at elint-se@outlook.com Your questions will be answered promptly. FCAM3000SMART...
-
Page 2: Parts Included
SHUT POWER OFF AT REQUIRED TOOLS THE ELECTRICAL BOX (NOT INCLUDED) If you don’t know where your breaker is or how to turn off power to your floodlight circuit, consult with a licensed electrician. FCAM3000SMART... - Page 3 HOW EVERYTHING GOES TOGETHER: Installation Option #1: Flush-mount Junction Box Head Lights Quick Connector Neutral Mounting Hot Wire Wire Screws Deco nuts & Safety Wire Mounting rubber & hook Cross Bar Camera Lens washers LED Indicator Light Microphone PIR Sensor FCAM3000SMART...
- Page 4 Head Lights Quick Connector Exterior J-box (NOT INCLUDED) White/Neutral Mounting Black/Hot Wire Screws Wire Camera Lens Metal bracket (For Deco nuts & Mounting Safety Wire LED Indicator External J-box Only) rubber washers Cross Bar & hook Light Microphone PIR Sensor FCAM3000SMART...
-
Page 5: Before Installing
Floodlight Cam ships with the camera upside down on the fixture. Ensure to rotate the camera head so that the PIR sensor is parallel to the ground. Rotate the camera head to the Bring the PIR sensor down 90°. Bring the camera head to the front. right 90° FCAM3000SMART... - Page 6 INSTALLING THE CROSS-BAR BRACKET • Install mounting cross bracket to the junction box using J-box mounting screws. HANG THE FLOODLIGHT FOR EASY CONNECTION • Use the provided safety wire and hook to hang the Floodlight Camera from the mounting cross bracket. FCAM3000SMART...
-
Page 7: Turn Power On
6. TURN POWER ON • Add silicone sealant around the canopy Restore power at the electrical between the metal plate and J-box as well as breaker box. the metal plate and canopy. This will prevent moisture from getting to the wiring compartment. FCAM3000SMART... - Page 8 • Using the exterior J-box mounting screws, 3/16 x 0.5in (shorter screw) , install mounting crossbar and metal bracket adapter to the junction. HANG FLOODLIGHT FOR EASY CONNECTION • Use the provided safety wire and clip to hang the Floodlight Camera from the mounting cross bracket. FCAM3000SMART...
- Page 9 6. TURN POWER ON • Add silicone sealant around the canopy between Restore power at the electrical the metal plate and J-box as well as the metal plate breaker box. and canopy. This will prevent moisture from getting to the wiring compartment. FCAM3000SMART...
- Page 10 Consult the dealer or an experienced radio/TV technician for help. Any modifications to this product will void the product warranty and could void the user’s authority to operate the equipment. FCAM3000SMART...
