- Page 1 INSTALLATION AND MAINTENANCE MANUAL ILMEN R290 Versión: 7 TRANSLATION OF THE For additional copies visit: www.frost-trol.com ORIGINAL DOCUMENT D004028 Difusión Restringida Interna ...
-
Page 2: Table Of Contents
SPARE PARTS REQUEST ..............23 FAULTS AND REPAIRS ..............24 6.1. MALFUNCTIONS ................24 TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com D004028 Versión: 7 Difusión Restringida Interna ... - Page 3 6.3. DISMANTLING THE CABINET ............26 6.4. DECLARTION OF ROHS CONFORMITY ..........27 GUARANTEE ................. 27 TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com D004028 Versión: 7 Difusión Restringida Interna ...
-
Page 5: Safety Advice
Make sure that the drainage holes are not obstructed by any remaining merchandise, as this could impede the drainage of excess water resulting from defrosting. TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com D004028 Versión: 7... - Page 6 If the power cord is damaged, it must be replaced by the manufacturer in order to avoid a hazard. Earthing is mandatory according to current legislation, as is providing protection against power surges, short circuits and indirect contacts. TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com D004028 Versión: 7...
- Page 7 Any other use not explicitly mentioned in this handbook must be considered as hazardous. The manufacturer disclaims all liability for damage resulting from improper, incorrect or unreasonable use. TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com...
-
Page 8: General Information
1. GENERAL INFORMATION Welcome to the new ILMEN series of plug-in refrigerated display cabinets from Frost-trol for the sale of perishable food products. We are delighted by your decision to choose us. This assembly and maintenance manual has been especially designed with a view... -
Page 9: Description Of The Refrigerated Display Cabinet
Available with 2, 3 or 4 triple glazed doors, this cabinet is fitted with automatic closure springs, and vertical lighting. With display gable ends as an option. The cabinet has a wide range of optional accessories. If you need details about its assemblage, please contact with Frost-trol, S.A. 1.1. GENERAL CHARACTERISTICS PM0P000SF2051017 PM0P000SF2041017 1439 [56 5/8"]... -
Page 10: Technical Information And Access To Eprel
1.3. SHOP CONDITIONS Frost-trol refrigerated display cabinets are designed to operate in air-conditioned areas that maintain an air temperature of 25º C and a maximum relative humidity of 60 % (climate class 3, in accordance with ISO EN 23953-2). The performance of... -
Page 11: Fixation Of The Recommended Temperature In Each Compartiment
Check the unit carefully to make sure that it is not damaged and no part or accessory is missing. For information about missing parts or accessories please contact the Frost-Trol Commercial Department or our official representative for your country. TRANSLATION OF THE... -
Page 12: Damage Sustained In Transit
Technical Department. If you need to get in contact with Frost-Trol with regard to a specific element, please make sure that you are able to quote the model and serial number. This information can be found on the nameplate, which is located inside the refrigerated display cabinet. -
Page 13: Intallation Of Refrigerated Display Cabinet
It’s mandatory to leave 8cm between the cabinet rear wall and the supermarket wall to ensure the airflow. Keep the condensing unit openings free from obstructions. 2.2. UNPACKING Unpacking is reserved for skilled personnel. TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com D004028 Versión: 7 -12- Difusión Restringida Interna ... -
Page 14: Levelling
Poor levelling could result in problems with the drainage of water resulting from defrosting, which could cause the unit to break down. TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com D004028 Versión: 7... -
Page 15: Doors Levelling
Consult the circuit diagrams that are supplied with each cabinet when carrying out the electrical connections and observe all of your country’s safety regulations in full. TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com D004028 Versión: 7... -
Page 16: Cleaning
Before the first use, it’s mandatory to clean the unit thoroughly, both inside and out, with non-abrasive detergents and rinse well with water. Dry the inside with a cloth so that no water remains inside the unit (See chapter 4). TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com... -
Page 17: Operation
The controller will show the temp. read by The set point is Press SET the probes again modified and saved Table 5.How to set the set point. TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com D004028 Versión: 7 -16- Difusión Restringida Interna ... -
Page 18: How To Access And Set Parameters
The display will show the name of the first Press SET Example “F0” for ‘Fan’. parameter in the functional block selected. Table 7.Accessing the parameters by selecting category. TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com D004028 Versión: 7... -
Page 19: Alarms With Manual Reset
Loaded product should be at least at its range temperature or better. The cabinet is not able to decrease product temperature; cabinet only is able to preserve temperature. Please note the following points when loading the cabinet: TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com D004028 Versión: 7... - Page 20 An improper preservation temperature may turn the foodstuffs into something harmful for the consumer’s health and facilitate germ and toxin spreading. The preservation period will depend on the type of product and the storage temperature. TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com D004028 Versión: 7...
-
Page 21: Maintenance And Cleaning
Finally, leave the doors half-open to avoid unpleasant smells. IMPORTANT! The components of the refrigerating circuit must not be cut or separated. TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com D004028 Versión: 7... -
Page 22: Generic Cleaning Routine
Gloves should be worn to protect hands when cleaning inside the evaporator and the condenser. This will protect hands against possible cuts or scratches from the unit’s internal elements. TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com... -
Page 23: Condenser Cleaning Procedure
Use a soft nonmetal brush or a vacuum cleaner. ‐ The condenser’s coil must be cleaned 12 times a year. Otherwise, the efficiency of the appliance might drop significantly. TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com D004028 Versión: 7... -
Page 24: Spare Parts Request
*The series number is indicated inside the refrigerated cabinet, on the characteristics plate. ** Taking the customer’s standing position as a reference. *** You may request to Frost-trol the spare parts cross-section. Table 10. Name plate According to point 2 in the Annex II from the Regulation 2019/2024 (Ecodesign),... -
Page 25: Faults And Repairs
In case of malfunctioning, the following information is completely necessary to find the reasons of the trouble and suggest the solution for it: TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com... - Page 26 Line voltage measured at the cabinet’s terminal board (for plug in): Compressor amps (for plug in): Defrost heaters amps (when it’s mounted): Other details, or photos, that could help will redound to find a quicker solution. TRANSLATION OF THE ILMEN R290 SOLID LINES For additional copies visit: ORIGINAL DOCUMENT www.frost-trol.com D004028 Versión: 7...
-
Page 27: Final Shutdown
INSTALLATION AND MAINTENANCE MANUAL 6.2. FINAL SHUTDOWN We, Frost-trol SA, declare this product is covered by Directive 2002/96/CE (Waste Electrical and Electronic Equipment) designed to halt the increase of this type of waste and promote recycling as well as decreasing disposal. The symbol of the crossed-out waste bin that appears on the Nameplate declares: that the product was put in circulation after 13th ‐... -
Page 28: Declartion Of Rohs Conformity
6.4. DECLARTION OF ROHS CONFORMITY We, Frost-trol, S.A. declare under our sole responsibility that the refrigerated cabinet complies with the provisions of Directive 2002/96/EEC (RoHS). In all the homogeneous materials used for its production, any content of lead, mercury, hexavalent chrome, polybrominated biphenyl (PBB), and polybrominated diphenyl ether (PBDE) does not exceed, in weight 0.1%;... - Page 29 ESPAÑA PLANTA CABANES: CV 159 Km 2 - 12180 Cabanes (Castellón), Spain -Tel. (+34) 964 342 740 - Fax. (+34) 964 215 148 - info@frost-trol.com MÉXICO: Av. Pirules, 134 B esquina con Av.Tejocotes, Fraccionamiento San Martin Obispo Cuautitlán Izcallí CP 54769, Estado de México - Tlf. (+52) 55 58193189 - info.mx@frost-trol.com Difusión Restringida Interna ...
