BWC-SM1

User Guide

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BWC-SM1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Smart Systems BWC-SM1

  • Page 1: Bwc-Sm1

    BWC-SM1 User Guide...

  • Page 2: Table Of Contents

    1 Table of Contents BWC-SM1 ............................1 USER GUIDE ..........................1 TABLE OF CONTENTS ......................2 INTRODUCTION ........................3 ................................ 3 VERVIEW ................................. 3 EATURES ..............................3 ONTENTS SPECIFICATIONS .......................... 4 BODY CAMERA OVERVIEW ....................5 BODY CAMERA MANAGEMENT SOFTWARE ............... 6 ...........................

  • Page 3: Introduction

    Fast record activation on the go with a quick press of the button on the front of the device. Small and lightweight, the BWC-SM1 offers high performance and ease of use on field. Review and bookmark videos on Android and iPhone using a secure APP that connects directly to the BWC-SM1 using a secure wireless connection.

  • Page 4: Specifications

    Specifications CAMERA Image Sensor 4MP CMOS Image Stabilization 6-axis Image Stabilization Field of View 140° VIDEO AND RECORDING Video Recording H.265, H.264, MP4 Recording Resolution 1920x1080p, 1280x720, 848x470 Frame Rate 30 frames per second Pre-Record Buffer 60-120 seconds Post-Record Buffer 5-60 seconds Recording Status Notification Vibration and Audible notification...

  • Page 5: Body Camera Overview

    3 Body Camera Overview Key Buttons Power Button Hold for 2 seconds to turn Camera On or Off. Push once to enable WiFi feature on the camera Record Button Push once to start recording. Hold down for 3 seconds to stop recording. Photo Button /Stealth Button Push once to take a photo while recording.

  • Page 6: Body Camera Management Software

    4 Body Camera Management Software 4.1 System Requirements The Body Camera Management Software provides users with tools to make changes to the body camera, including accessing recorded data stored on the camera.  Windows 7, 8, and 10  USB Port 4.2 Software Interface Connect Body Worn Camera to a PC.

  • Page 7: Camera Info Menu

    The software will prompt for User Type and Password. Default Password General User 000000 Admin 888888 *Note: For security reasons, it’s recommended to change default password. 4.2.1 Camera Info menu Camera info menu contains body camera information. In this menu Camera ID and User ID can be entered.

  • Page 8: Network Settings Menu

    4.2.2 Network Settings menu Network Settings menu allows authorized users to configure camera’s WiFi network. Wireless Settings Link Mode Disables WiFi Auto Automatically enables WiFi on power Manual Manually enable WiFi by using power button on the Body Camera. Single Push on power button enables/disables WiFi feature.

  • Page 9: Camera Settings Menu

    4.2.3 Camera Settings menu Authorized users may adjust Camera settings inside the Camera Settings menu. Camera Settings Main Resolution Recording resolution selection Image Quality Video recording quality selection Streaming Resolution Streaming resolution selection Streaming Bitrate Wireless streaming bitrate selection Streaming Frame Rate Streaming frame rate selection Mute Recording Enables/Disables audio recording...

  • Page 10: Encryption Menu

    4.2.4 Encryption menu The device supports AES256 Encryption method that protects recorded data files stored on the device. Encryption Settings Data Encryption Enables Data Encryption Disables Data Encryption Decryption Play Plays back Encrypted data Disables playback of Encrypted Data 4.2.5 Password menu Authorized users may change Camera login password in this menu.

  • Page 11: Mobile App

    4.3 Mobile App Scan QR code above to access the SmartPhone mobile app to use with the Body Camera. Ensure that WiFi is enabled on the Body Camera device. Enter camera’s WiFi password as it has been configured in Network Settings (See Section 5.2.2) under AP Settings.

  • Page 12: Access From Pc

    Tap image icon to access stored Images and Videos on the device from the Smartphone App Tap camera icon to start/stop recording manually using Smartphone App Tap Mode icon to access device’s basic settings. 4.4 Access from PC The stored videos may be accessed from the PC either via direct USB C-Type connection or via WiFi settings.
  • Page 13 Connect to the device via WiFi by selecting Camera’s SSID (refer to Section 4.2.2) under AP Setting in Network Setting section. Enter device’s password found in AP Setting by selecting Connect using a security key instead option on wireless access from PC. Default password: 12345678 When PC has successfully connected to the Device, Open a Browser Enter Camera’s IP address in the Browser Search tab.
  • Page 14 1-909-466-1999 support@smartsystemsca.com Smart Systems Law Enforcement Body Camera User Guide This guide is dated 2020. © 2020Smart Systems, LLC. All rights reserved. All trademarks are the property of their respective owners. This document applies to Smart Systems Law Enforcement Body Camera...
