Summary of Contents for Hagerman HagClock
- Page 1 HAGERMAN T E C H N O L O G Y HagClock Low Jitter Clock Upgrade Made in USA...
- Page 2 HagClock Low Jitter Clock Upgrade Copyrights & Trademarks © Copyright Hagerman Technology LLC 2006. All rights reserved. No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent. HagClock is a trademark of Hagerman Technology LLC.
- Page 3 A special output buffer provides accurate transmission of the clock into your CD player’s circuitry. HagClock can be mounted inside most transports and taps off of their existing power supply rails. Requires dealer installation by a qualified technician.
- Page 4 First, locate the existing crystal within the CD transport. Make sure it is either a 11.2896M or 16.9344M type, and use the appropriate HagClock. Find a location within the chassis to mount the clock. Place it as close to the existing crystal as possible.
- Page 5 HagClock Low Jitter Clock Upgrade CD transport oscillator modifications, wiring.
- Page 6 HagClock Low Jitter Clock Upgrade Troubleshooting Problem Solution LED does not light up. Correct power not supplied. CD player locks up. Wrong frequency used? Double check installation. Could also be that the start-up delay of the reference oscillator is too long.
- Page 7 This document contains proprietary information and except with written permission of Hagerman Technology LLC such information shall not be published, or disclosed to others, or used for any purpose, and the document shall not be copied in whole or in part.
- Page 8 This document contains proprietary information and except with written permission of Hagerman Technology LLC such information shall not be published, or disclosed to others, or used for any purpose, and the document shall not be copied in whole or in part.
