Huali Precision Mould UHD02 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Digital Camera
Auto focus function (AF)
UHD02
Instruction Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the UHD02 and is the answer not in the manual?

Questions and answers

Summary of Contents for Huali Precision Mould UHD02

  • Page 1 Digital Camera Auto focus function (AF) UHD02 Instruction Manual...
  • Page 2 Preface Thank you for purchasing this digital camera. Please read this manual before operating this product. After you finish reading this manual, store it in a safe place for future reference. Contents covered in this user manual refer to the latest information in preparation of this user manual.
  • Page 3 baby. 4.Please store this equipment out of the reach of children and infants. It can cause serious injury to children if the camera or battery is accidentally damaged. 5.Do not attempt to disassemble or modify any part not described in this guide. Unpacking or modifying of camera may result in a high voltage shock.
  • Page 4 10.Your hands may feel hot because temperature of camera body will rise after a long time of us. Please be careful when operating this equipment for a long time. 11.Please unplug the battery if you not use the camera. The battery shall be charged once every 6 months.
  • Page 5 1:Lens 2:Flash 1: Hot-shoe 2: Charging Indicator 3: Working Indicator...
  • Page 6 9: Down / Delete 4: T-Zoom in 10: Menu 5: W- Zoom out 11: Display 6: Up / Flash light 12: Left / Delay 7: Right / Continuous shooting 13: LCD display 8: OK 1: Battery door 2: Tripod slot 3: Memory slot 1: MIC interface 2: USB interface...
  • Page 7 Preparation of the Camera Install battery This camera uses high capacity rechargeable external lithium battery. Please put the battery into the battery slot correctly according to the battery and battery compartment slot. Battery charging The following symbols indicate the current remaining battery power.
  • Page 8 battery into the charger directly. (3) Battery charging time (estimated) In the normal environment, it takes 3 hours to be fully charged. (4) Continuous working hours (estimated) When [system] is set to photo mode and all other settings are factory default settings, it can work for 1.5 hours. When [system] is set to video mode and other resolutions, and all other settings are factory default settings, it can work for 1.5 hours.
  • Page 9 inward again. Notes: Turn off power of the camera before replacing memory card. Insert card in the correct direction. Do not use too much force when inserting card to avoid damaging card or camera parts. Please check if the direction is correct if card can’t insert.
  • Page 10 saved by PC in the memory card, the recording time may be reduced or data may be unable to recorded properly. Format memory card A memory card first used in this camera is recommended to be formatted, or failure, such as, inability to record may occur.
  • Page 11 Set date/time Press “MENU” twice to enter system setting menu, press Down button to find the “Time Set / Date Set” sub-menu, press “OK” to set corresponding date and time. Language setting Enter system setting, press the Down button to find the “Language”...
  • Page 12 Light Source Auto/50Hz/60Hz Frequency LED Indicator Turn On/Turn Off (Press OK to switch) Auto Screen Turn Off/30s/1min/2min Saver Auto Power Off Turn Off/3min/5min/10min Button prompt High/Middle/Low/Turn Off Sound Startup Music Open/Close Simplified Chinese/traditional Chinese/English/Japanese/Korean/R Language ussian/German/French/Italian/ Spanish/Portuguese/Thai YYYY/MM/DD MM/DD/YYYY Time Format DD/MM/YYYY Time Set hour minute second...

  • Page 13: Mode Dial

    Mode Dial Rotate the mode dial button to select the corresponding mode. The corresponding reference of the mode is as follows: icon Mode Photo Interval photography Recording Slow motion recording Time-lapse recording Playback Take pictures Set the mode dial to camera mode, the camera screen will display the following interface.
  • Page 14 10:Playback 1:Photo mode 11:System time 2:Image pixels 12:System date 3:Image quality 13:Exposure 4:Fill light (turn off) 14:ISO 5:Current stored quantity 15:Exposure Metering 6:Current memory remaining storage 16:Scene 7: Current remaining battery power 17:White balance 8:Zoom in/Zoom out 18:Setting 9:Zoom factor Menu setting contents in photo mode Sub-menu Menu content...
  • Page 15 Exposure -3/-2/-1/0/1/2/3 Setting Metering Average Metering/Center Metering/Spot Mode Metering/Matrix Metering Super high quality / high quality / Image Quality standard Sharpness High/Middle/Low Long Auto/2S/5S/10S/15S/20S/30S Exposure Auto/100/200/400/800/1600/3200/6400 Time Turn On/Turn Off (Press OK to switch) Watermark Shooting auto focus function (AF) In the photographing mode, the shoot button has two layers.

  • Page 16: Recording Video

    press the first layer to focus, then press the second layer to shoot. 1. When the distance between the camera and the object is more than 3.3ft, gently press the first layer of the shoot button, and the focus logo frame will appear on the display until the camera has focused clearly.
  • Page 17 1: Recording mode 2: Video resolution 3: Fill light 4: Current recorded time 5: Current memory card remaining recording time 6: Current remaining battery power 7: Zoom in/Zoom out 8: Zoom factor 14: Exposure Metering 9: Playback 15: Scene 10: System time 16: White balance 11: System date 17: Setting...

  • Page 18: Playback Mode

    Exposure -3/-2/-1/0/1/2/3 Setting Average Metering/Center Metering Metering/Spot Metering/Matrix Mode Metering Sharpness High/Middle/Low Video Quality High/Middle/Low Auto/100/200/400/800/1600/3200/6400 Time Turn On/Turn Off (Press OK to switch) Watermark Record Audio Turn On/Turn Off (Press OK to switch) Video pause This camera supports video pause. During the recording, press the Power button, the recording is stopped and press it again, the recording is continued.
  • Page 19 Press the down button to choose whether to delete the current photo or video. Power OFF Long press POWER button to turn off the digital camera. If you set the auto turn off menu, when the digital camera is free ,it will turn off automatically without operation in more than 3 min/5min/10min, so to save power.
  • Page 20 App. (1) Turn on the camera first, enter the menu of system setup, find the submenu of wireless hotspot, and press the OK key to turn on WiFi. The camera screen will show WiFi name or password. (2)Open the settings on your phone or tablet. ------ WLAN finds the camera WIFI ID, enters the WIFI password, and connects the phone to the camera.
  • Page 21 hotspot). (4) Enter the downloaded APP (XDV PRO), turn on the GPS function at the same time, click to select the WiFi with the same name as the WiFi displayed on the camera screen, you can enter the APP page, and control the camera to take pictures, video or menu settings through it.
  • Page 22 Step 2: Disconnect the WiFi hotspot of the camera, connect the mobile data flow of the mobile phone or tablet, the APP interface will prompt "please restart the APP", select "OK"to automatically exit; then you need to enter the APP again, and the APP will prompt "Required turn on or off WLAN"...
  • Page 23 unplugging the HD cable. (switch TV signal into HD mode) Connect computer and webcam Connect the camera to the available USB port on the computer with the USB cable. After inserting the USB cable, the camera will automatically turn on. Press the up and down button to select the charging mode, storage mode or webcam mode, and press the OK to enter.
  • Page 24 Note: do not disconnect the USB connection when downloading the file. Do not plug and unplug the memory card when connecting the USB, so as to avoid data loss. Select webcam mode, the camera can be used as a camera. Tip: if the camera cannot be enabled after connection, please go to the device manager of the computer, find the image device menu or camera menu, and click to check...
  • Page 25 as a webcam. Trouble Measures The battery is low, please replace it with a new one. The battery is not installed in place; Camera can’t please confirm that the battery is start after battery installed correctly. is installed There may be an error in the camera program, please pull out the battery, reinstall, and then turn on.
  • Page 26 Please check whether the USB data cable is connected correctly. Please check whether the USB Unable to interface of computer is working connect to PC properly. Please check the compatibility of the computer system. Blurred shooting Check whether the camera shake effect when shooting.
  • Page 27 fault. (3) Due to the optical properties of the lens, there may be color dispersion (magnification of chromatic aberration) at the edges of the image. This is not a camera fault. (4) It is normal for the memory card to get hot after a long period of use.
  • Page 28 Format:MP4 Video Resolution: 4K_3840X2160 (30FPS) Video 2.7K_2688X1520(30FPS) Resolution FHD_1920X1080(60FPS) FHD_1920X1080(30FPS) HD_1280x720 (120/60/30FPS) External MIC Support Fill Light ＜1.0m Range Auto / sunny / cloudy / incandescent / White balance fluorescent Exposure –3.0EV～+3.0EV USB Interface USB2.0（high speed） Auto Power -Off Off /3mins /5mins /10mins LCD Screen 3.0-inch ultra HD screen（16:9）...
  • Page 29 FCC Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.
