Page 1 SWD-24 is a plug-and-play multi-subwoofer driver for your home theater setup. Without programming and through simple connections, the SWD-24 allows you to immediately run up to four powered subwoofers from your audio video receiver (AVR). This product is intended for Page 1 SWD-24 User Guide - Rev.
Page 2 Your subwoofer should be set as below, so as to not interfere with the crossover and parametric equalization (PEQ) parameters that are set up in the miniDSP. Page 2 SWD-24 User Guide - Rev. 04182022deercreekaudio.com...
Page 3 Shown below is configuration 1: Monaural subwoofer setup 80 Hz. This is most common and how the SDW-24 is configured out of the box, or by selecting configuration 1 from the remote control. 3. Four selectable home theater configuration modes 3.1 Monaural subwoofer setup 80 Hz Page 3 SWD-24 User Guide - Rev. 04182022deercreekaudio.com...
Page 4 This configuration is used in systems with AVRs that have dual independent subwoofer outputs. Input 1 feeds subwoofers 1 and 2, input 2 feeds subwoofers 3 and 4. The SWD-24 low pass filter is set to 120 Hz, so if a lower cutoff frequency is desired, set that on the subwoofer crossover.
Page 5 This configuration is used in systems with AVRs that have left and right subwoofer outputs, which will be combined into one virtual monaural subwoofer. The SWD-24 low pass filter is set to 120 Hz, so if a lower cutoff frequency is desired, set that on the subwoofer crossover.
Page 6 ● Flexible parametric room equalization filters ● Programmable time delay correction ● Compatible with REW software and miniDSP UMIK measurement microphone 6. What's Included ● SWD-24 Multi-Subwoofer Driver ● IR Remote Control Page 6 SWD-24 User Guide - Rev. 04182022deercreekaudio.com...
Page 7 ● Thumb drive with SWD-24 software driver configuration .xml file ● U.S. regulated 12V power supply ● USB cable ● miniDSP plug-in license and REW software link 7. Specifications ● Based on miniDSP 2x4 HD ● Distortion < 0.1% THD at maximum input ●...
