Summary of Contents for Ascentic TouchSelect
- Page 1 User Manual TouchSelect USB Touch Panel Interfaces TS04-USB, TS09-USB, TS22-USB...
- Page 2 The Audio Authority TouchSelect USB series offers flexible solutions ® for any interactive display. TouchSelect panels come in three configurations: 4 position (TS04-USB), 9 position (TS09-USB), and 22 position (TS22-USB). The TouchSelect RS-485 series offers the same configurations with different features.
- Page 3 USB-A Communication The TouchSelect USB series communicates via a standard USB connection. Any of the TouchSelect control panels may be connected to a compatible device such as a BrightSign player or Ascentic MediaHub. When touched, the TouchSelect panel transmits the touch location and its address over the bus. Any USB-A capable device can be programmed to respond to these messages, enabling player controls and switching activity.
- Page 4 TS04-USB Example System: • A touch panel controls volume and plays video tracks. • Start a demo by touching “Play Next” and adust volume by touching “Volume” keys. • Touch panels connect via USB to the MH6-4K MediaHub Hypothetical TS09-USB Overlay Choose Your Headphones Vol + Vol -...
