AZEK TimberTech PRO Installation & Maintenance Manual

Table of Contents

Quick Links

Decking Installation & Maintenance Guide

TimberTech PRO

, TimberTech EDGE

Fastening Methods ........................................................................................................ 4

TimberTech

Square Shouldered Boards ...................................................................... 5

Trimming a TimberTech

Hidden Fasteners .................................................................................... 7

CONCEALoc

Cortex

Hidden Fastening System .............................................................................. 10

Care and Cleaning ....................................................................................................... 12

Warranty ...................................................................................................................... 13

Notes ........................................................................................................................... 14

decking | railing | lighting | fastening

, and Specialty Decking

Decking .................................................................................... 2

Deck ..................................................................................... 6

i T

T r

c e

. h

o c

Table of Contents

Need help?

Do you have a question about the TimberTech PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for AZEK TimberTech PRO

Page 1: Table Of Contents
Decking Installation & Maintenance Guide TimberTech PRO , TimberTech EDGE , and Specialty Decking ® ® Installing TimberTech Decking ..................2 ® Fastening Methods ......................4 TimberTech Square Shouldered Boards ..............5 ® Trimming a TimberTech Deck ..................6 ®...
Page 2: Installing Timbertech ® Decking
Decking is fit for the intended use. Since all installations are requirements: unique, it is also the installer’s responsibility to determine specific requirements for each deck application. AZEK Building Products • Cordless Driver • Spacing Tools recommends that all applications be reviewed by a licensed •...
Page 3 1/8”. To determine how much TimberTech decking material you • TimberTech PRO Reserve-FR Grooved Decking installed will need, start by calculating the square footage of your with edge to edge gap spacing of a maximum 3/16”...
Page 4 Installing TimberTech Decking ® Installation Preparation Follow these guidelines for best deck installation: • For best results, installing solid wood blocking between each joist, • TimberTech Deck Boards are one-sided products. Deck Boards are to placed every 4’ - 6’ within the structure, can help reduce movement be installed with the grain side up for the walking surface.
Page 5: Fastening Methods
45 degrees Fahrenheit to avoid splitting and screw shear. 5.360” Alternate fasteners are stainless steel or high-quality coated composite deck screws.* .94” Terrain TimberTech PRO Legacy, PRO Reserve, and EDGE Premier: .94” Collection Use Cortex, TOPLoc or a minimum #8 x 2-1/2” stainless EDGE Prime and Prime+ steel or other high-quality coated composite deck screws.*...
Page 6 • Pre-drilling is required when within 1-1/2” of the ends of the board and for temperatures below 45 degrees Fahrenheit to avoid end splitting and screw shear. • TimberTech Cortex requires pre-drilling with a 7/32" bit for ALL applications in TimberTech Pro Reserve, Pro Legacy, and EDGE Premier Directional Notch Bevel TwinFinish, ReliaBoard, DockSider, TwinFascia and TwinRiser Boards: The surfaces of these products are directional in manner.
Page 7: Trimming A Timbertech Deck
• 12’ lengths – 9/16” thick by 12” wide. • Cedar and Grey Fascia Riser • All TimberTech PRO and EDGE colors • All TimberTech PRO and EDGE colors • 12’ lengths – 9/16” thick by 12” wide. Page 7...
Page 8: Concealoc ® Hidden Fasteners
CONCEALoc Hidden Fastener ® Important Information CONCEALoc Hidden Fasteners were designed exclusively to CONCEALoc Accessories • 100-square-foot coverage box. Includes stainless steel install TimberTech grooved boards. clips and screws. • Bulk Bucket – 1,000-square-foot coverage. Includes stainless Always be sure to check and cut the factory cut steel clips and screws.
Page 9 CONCEALoc Hidden Fastener ® INSTALL CONCEALoc FASTENERS ® • Install provided screw at 45° angle through the fastener and into the joist while applying pressure on the fastener. • Install one fastener and screw at each joist. • Make sure fastener is in full contact with edge of board and the screw is holding the fastener down tight to the deck board.
Page 10 CONCEALoc Hidden Fastener ® HOW TO: INSTALL ON DIAGONAL • When the deck is located in a corner of the house, start with small triangular piece of decking in the corner and work your way out. • Offset the center 1/2” towards the long point of the joist, so screw will not exit the side of the joist when driven.
Page 11: Cortex ® Hidden Fastening System
Cortex Hidden Fastening System ® Cortex Hidden Fastening System Installation Instructions ® Suggested Drills Impact Drivers are not recommended when Corded or cordless (18V battery) drill with 1/2” chuck. using TimberTech Cortex. Important Information Restricted Cortex Uses The TimberTech Cortex System is designed for traditional •...
Page 12 Cortex Hidden Fastening System ® PRE-DRILL • Pre-drill deck board with a 7/32" drill bit DRIVE SCREWS INTO JOISTS • Using Setting Tool provided, drive screw at medium or high speed until it disengages at the proper level below the deck surface. •...
Page 13 TimberTech Deck composite deck cleaners, in powder or liquid form, should looking great. not be used with TimberTech PRO and EDGE deck boards. These recommended products can be purchased at many TimberTech PRO and EDGE deck boards are a capped hardware stores including Lowe’s and Home Depot as...
Page 14: Care And Cleaning
TimberTech PRO, TwinFinish, Reliaboard, and Docksider products are covered by a 30-year limited warranty for residential applications and a 10-year warranty for commercial applications. TimberTech PRO products are covered by a 30 year residential fade and stain warranty. TimberTech EDGE products are covered by a 25-year limited warranty for residential applications and a 10-year warranty for commercial applications.
Page 15: Notes
Notes Page 15...
Page 16 Decking Installation & Maintenance Guide TimberTech.com © 2021 The AZEK Company LLC InstallGuide-Decking-Pro-Edge-TimberTech-2021 | 03/21...
