Summary of Contents for INTERNATIONAL CARBONIC PF-2-PB
- Page 1 PF-2-PB INSTALLATION AND BRIXING PROCEDURES PUSH SERVE PUSH SERVE INTERNATIONAL CARBONIC INC. 16630 Koala Rd. Adelanto, California 92301 800 854-1177 12/16/05...
- Page 2 At this time, inspect for any missing parts and if parts are missing notify factory. The PF-2-PB has been designed to fit in place of any existing FT, FT-II, PF or PFC-II valve. On International Carbonic Inc. equipment no modification of existing valve plates will be necessary.
- Page 3 5. Install water and syrup inlets to corresponding inlet holes on back of valve. All PF-2-PB valves are marked with raised letters at the inlet fitting. 6. Reconnect syrup lines and check for leaks. Repeat this procedure for water or soda connection.
- Page 4 Syrup Outlet #2 BRIXING PF-2 VALVE Syrup Outlet #1 1. The water and syrup flows are individually adjusted by their respective metering pin located FRONT under the valve. 2. One recommended method utilizes a ratio brix cup, see illustration. The brix cup is divided into two sections.
- Page 5 PF-2-PB EXPLODED VIEW SYM QTY PART NO. DESCRIPTION E-623 NUT, SOLENOID E-525 COIL, W/SHIELD, SOLENOID, 24 VAC E-739 FLUX PLATE E-527 STEM, SOLENOID VALVE E-730 PLUNGER & SPRING ASSEMBLY E-531 GASKET, SOLENOID STEM E-591 BODY, TWIST LOCK E-162 SCREW, TAP TIGHT...
- Page 6 HERE PUSH HERE E-1061 SWITCH, TWO FLAVOR ASSY. PART NO. DESCRIPTION E-1066 CAP, COVER ALL E-1072 CONTROL BOX E-1063 SWITCH MOUNTING PLATE E-157 SUB MINIATURE SWITCH E-1070 SPRING E-1068 ACTUATING PLATE INTERNATIONAL CARBONIC INC. I C I ADELANTO, CALIFORNIA 3/97...
- Page 7 YELLOW SYRUP COIL #1 BLUE WATER COIL 24 VOLT BLUE SYRUP COIL #2 YELLOW TITLE INTERNATIONAL CARBONIC INC. PF-2-PB ELECTRICAL I C I SCHEMATIC DATE 12-16-05 DRN. BY CHK. BY APPR. BY ADELANTO, CALIFORNIA...
