- Page 1 Assembly and installation manual Fixed Mosquito Screen 2012...
- Page 2 ASSEMBLY AND INSTALLATION MANUAL FIXED MOSQUITO SCREEN 2012 Index 1. Components 2. Assembly 3. Installation important It is important for the safety of persons and the integrity of the product to read these instructions carefully before installing, opera- ting, repairing or using the screen for the first time. Both documents make up a complete instruction manual This document is an integral part of the titled mosquito screen model and is intended for the installer.
- Page 3 ASSEMBLY AND INSTALLATION MANUAL FIXED MOSQUITO SCREEN 2012 1. Components Fixed mosquito screen profile Cross screen profile 008145 008170 Fixed mosquito screen angles Cross bar cap (2 units) 008011 008154 PVC-coated fibreglass mesh Rubber band 008092 008082 Brush 69x55 mm Stainless steel bracket 008083 008090...
-
Page 4: Frame Assembly
ASSEMBLY AND INSTALLATION MANUAL FIXED MOSQUITO SCREEN 2012 2. Assembly 2.1 Measures and allowances Step 1 Step 2 Take measurements of the dimensions of the opening where the Cut the profiles with the following allowances: mosquito screen will be installed. Height (H)= -64 mm It is advisable to take two measurements of each dimension Width (L)= -64 mm... - Page 5 ASSEMBLY AND INSTALLATION MANUAL FIXED MOSQUITO SCREEN 2012 2.4 Installation of the cross bar (Reinforcement profile) If the size of the mosquito screen is greater than 1,500 mm in height or width, it would be advisable to install a crossbar (rein- forcement profile) cutting it with the following allowance: interior size of the hole -4 mm.
-
Page 6: Installation
ASSEMBLY AND INSTALLATION MANUAL FIXED MOSQUITO SCREEN 2012 2.6 Cutting Of The Fiberglass Mesh Once the fabric has been installed and stretched in the frame, cut the excess with a knife, taking care to cut the fabric in the right area, so as not to damage it. 3. - Page 7 Giménez Ganga, S.L.U. Polígono Industrial El Castillo C/ Roma, 4 03630 • Sax (Alicante) • España saxun.com...
