Cloud Nine Ergo C959 Manual

Hide thumbs

Advertisement

Table of Contents

C959 ErgoTKL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C959 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cloud Nine Ergo C959

  • Page 1 C959 ErgoTKL...
  • Page 2 GET THE MOST OUT OF YOUR KEYBOARD: >>> DOWNLOAD THE CLOUD NINE APP <<< Customize backlighting, program custom macros, upgrade to the latest firmware, and more...
  • Page 3 KEYBOARD LAYOUT Media Hotkeys Keyboard Interface (R) Keycap Puller Smart Control Wheel Keyboard Interface (L) Extra Esc & Macro Keycaps Windows® Lockout Key USB Pass-Through Port Backlighting Key Keyboard Port Macro Keys Linking Cable Fn Key Keyboard Cable...

  • Page 4: Setting Up Your Keyboard

    SETTING UP YOUR KEYBOARD 1) Connect the linking cable (A,B) to each of the keyboard halves. (Note: “ ” logo faces up.) 2) Connect the keyboard cable (C) to a free USB-A port on your Windows® PC or Apple Mac®.
  • Page 5 SMART CONTROL WHEEL Pressing the Fn key (A) + Smart Control Wheel (B) will cycle through the available modes with the color changing to indicate the current mode. After selecting a mode, rotate the wheel left, right, or click to adjust mode settings. Smart Control Wheel backlighting can be turned on/off by...

  • Page 6: Lighting Effects

    BACKLIGHTING EFFECTS Keyboard backlighting effects can be changed by pressing the backlighting key (A). All backlighting can be turned on/off by pressing the Fn key (B) + backlighting key (A). LIGHTING EFFECTS White Explode Colorful Launch Falling Ripples Glittering Flowing Breath Sine wave Spectrum...

  • Page 7: Macro Keys

    MACRO KEYS Macros can be recorded at any time (without software) via on board commands. The keyboard supports a maximum of 16 key combinations per macro. The macro functions: Select All / Copy / Paste / Cut are preprogrammed into the 4 macro M-keys (B). To assign a new macro function, follow these steps: 1) Press the Fn key (C) + any single macro M-key (B) to start recording.

  • Page 8: Media Hotkeys

    MEDIA HOTKEYS Fn key (B) + F1 key (A) Media Player Fn key (B) + F2 key (A) Play/Pause Fn key (B) + F3 key (A) Stop Previous Fn key (B) + F4 key (A) Fn key (B) + F5 key (A) Next WINDOWS®...

  • Page 9: Factory Reset

    FACTORY RESET To return the keyboard to its factory settings, press the Fn key (A) + “Esc” key and hold for 3 seconds. Note: All custom programmed macros and backlight colors will be erased when the keyboard is returned to factory settings.
  • Page 10 DISPOSITION DU CLAVIER FRANÇAIS Câble du Clavier Raccourcis média Interface du Clavier (D) (embout pour l’ordinateur) Extracteur de Touche Molette de Contrôle Intelligente Interface du Clavier (G) Touche de Verrouillage de Windows® Port USB Touches Ech & Macro de rechange Touche de Rétroéclairage Port du Clavier Touches Macro...
  • Page 11 MOLETTE DE CONTRÔLE INTELLIGENTE FRANÇAIS Appuyez sur la touche Fn (F) + la molette Smart MODE COLOR Control (B) pour permuter entre les différents modes (click) disponibles. La couleur change pour indiquer le mode Volume Blanc Haut / Bas Muet sélectionné.
  • Page 12 KEYBOARD LAYOUT ENGLISH Media Hotkeys Keyboard Interface (R) Keyboard Cable (computer end) Smart Control Wheel Keyboard Interface (L) Keycap Puller Windows® Lockout Key USB Pass-Through Port Extra Esc & Macro Keycaps Backlighting Key Keyboard Port Macro Keys Linking Cable Fn Key Keyboard Cable (keyboard end) SETTING UP YOUR KEYBOARD 1) Connect the linking cable (K) to each of the keyboard interface ports (G,H).
  • Page 13 SMART CONTROL WHEEL ENGLISH Pressing the Fn key (F) + Smart Control Wheel (B) MODE COLOR will cycle through the available modes with the color (click) changing to indicate the current mode. Volume White Up / Down Mute After selecting a mode, rotate the wheel left, right, or click to adjust mode settings.
  • Page 14 LEGAL Cloud Nine Ergo LLC. All rights reserved. Cloud Nine, the cloud 9 logo, ErgoTKL, “Engineered To Fit You.” are trademarks or registered trademarks of Cloud Nine Ergo LLC and/or affiliated companies in the United Stands or other countries. Windows and the Windows logo are trademarks of the Microsoft group of companies.
  • Page 16 Engineered To Fit You. ™ c9ergo.com ©2021 Cloud Nine Ergo LLC. All Rights Reserved.
