Related Manuals for Shurikey Gear SZB81
Summary of Contents for Shurikey Gear SZB81
- Page 2 手里键Saizo 80%静电容V2机械键盘说明书 Shurikey Saizo 80% EC V2 Mechanical Keyboard Manual...
- Page 3 布局图 Layout...
- Page 5 左边旋钮控制背光： 轻按旋钮开启或关闭背光。 顺时针旋转增强亮度， 逆时针旋转降低亮度。 The left knob is to adjust the backlight. Press the knob to switch on/off the backlight. Turn clockwise to increase the brightness and counterclockwise to decrease. 右边旋钮控制音量： 轻按旋钮开启或关闭声音。 顺时针旋转增大音量， 逆时针旋转减小音量。 The right knob is the volume control. Press the knob to switch on/off media sound. Turn clockwise for volume up and counterclockwise for volume down.
- Page 6 指示灯说明 Indicator Lights 左侧灯为 Caps Lock 指示灯： 大写时亮白灯， 小写时灯熄灭。 The left one is the Caps Lock indicator. It lights up in white for uppercase input mode; lights off for lowercase input mode. 右侧灯为 Scroll Lock 指示灯： 锁定时亮白灯， 不锁定时灯熄灭。 The right one is the Scroll Lock indicator. It lights up in white when Scroll Lock is locked while lights off when unlock.
- Page 7 蓝牙开机 Turn on the Bluetooth 2 秒内轻敲 3 下空格键， 键盘开机。 Press the Space Bar for three times within two seconds to turn on the keyboard. 连接状态查看 Bluetooth Connection State 开机后， 默认键盘背光灯全亮。 All LED will be lit as default after the keyboard powers on. 键盘最多可同时连接...
- Page 8 设备连接 Device Connection 键盘开机后， 在需要连接的设备搜索蓝牙键盘。 F1、 F2、 F3 频道下搜索到的蓝牙键盘名称分别对应 “ WK- VD01 ” 、 “WK- VD02” 和 “WK-VD03” 。 After the keyboard is powered on, search for Bluetooth Keyboard on your device. The name of the keyboard is shown as “WK-VD01” , “WK-VD02” or “WK-VD03” . 第一次配对需要输入密码，...
- Page 9 蓝牙关机 Turn off the Bluetooth 蓝牙状态下， 长按 3 秒 Fn + Delete 关机。 In Bluetooth mode, press and hold Fn + Delete for three seconds to turn off the keyboard. 设备切换 Switch from Bluetooth Mode to Wired Mode 通过 Fn + Delete 的按键组合在有线和蓝牙模式之间切换。 从有线切换至蓝牙时， Caps Lock 指示灯闪 3 下， 键盘自动连接上一次配对的蓝牙设备；...
- Page 10 关机状态下插入 USB 线后键盘进入有线模式。 When the keyboard is powered off, plug in the USB cable and the keyboard will enter wired mode. 在蓝牙模式下， 插入 USB 线后键盘会切换到有线模式， 蓝牙指示灯熄灭。 In Bluetooth mode, with the USB cable plugged in the keyboard will switch to wired mode and the Bluetooth indicator will light off.
- Page 11 睡眠模式 Sleep Mode 有线模式下， 键盘会与电脑一同进入睡眠模式。 轻按空格键唤醒。 In wired mode, the keyboard will enter sleep mode with the computer. Press Space to wake up the keyboard. 蓝牙模式下， 键盘会与电脑一同进入睡眠模式。 电脑关机 5 分钟后， 键盘会进入睡眠。 电脑开机后， 轻按空格键 唤醒。 In Bluetooth mode, the keyboard will enter sleep mode with the computer or in five minutes after the computer is powered off.
- Page 12 重新配对 Pair New Devices 长按 5 秒Fn + F1/F2/F3 键， 断开对应频道的蓝牙连接。 蓝牙指示灯闪烁后键盘重新进入配对模式。 Press and hold Fn + F1/F2/F3 for five seconds to disconnect corresponding Bluetooth connection. The indicator light will flash and then the keyboard will enter pairing mode again. 低电量提示...
- Page 13 灯光效果 Light Effects 灯效 亮度调节 速度调节 Light Effects Brightness Adjustment Speed Adjustment 常亮 可调节 不可调 Always Lit × √ 单点亮 不可调 可调节 Single Key × √ 涟漪 可调节 可调节 Wave Mode √ √ 呼吸 不可调 可调节 Breathing Mode × √ 心电图...
- Page 14 灯光控制 Light Controls 按键组合 功能 Key Combination Function Fn + ↑ 上一个灯效 （循环） Fn + ↑ Previous Effect (Loop) Fn + ↓ 下一个灯效 （循环） Fn + ↓ Next Effect (Loop) Fn + ← 灯效速度减慢 Fn + ← Lower the Speed Fn + →...
- Page 15 多媒体功能 Multimedia 按键组合 功能 Key Combination Function Fn + U 上一曲 Fn + U Skip Back Fn + I 暂停/播放 Fn + I Pause/Play Fn + O 下一曲 Fn + O Skip Next Fn + Z 音乐 Fn + Z Music Fn + X 邮件...
- Page 16 其他组合键功能 Other Key Combinations 按键组合 功能 Key Combination Function Fn + P Print Screen Fn + [ Scroll Lock Fn + ] Pause Fn + ; Home Fn + ‘...
- Page 17 其他功能 Other Functions Fn + Alt + Win 键， 锁定或解锁 Win 键。 Press Fn + Alt + Win, lock/unlock Win. 长按 3 秒 Fn + 左 Ctrl， Caps Lock 指示灯闪三下， Caps Lock 与左 Ctrl 键值互换。 再次长按 3 秒 Fn + Caps Lock，...
- Page 18 系统兼容 System Compatibility 兼容 Win8、 Win10、 Win11、 Mac OS （特殊键值非完全兼容） （ 设备自带或者外接蓝牙为4.0及以上） 。 This keyboard is compatible to Win8, Win10, Win11, MAC OS (special key codes not fully compatible). Other types of Bluetooth should be updated to no less than 4.0 for compatibility.
