BODY TRACKING AND HAPTIC
SUIT
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BODY TRACKING AND HAPTIC SUIT and is the answer not in the manual?

Questions and answers

Summary of Contents for Shockwave BODY TRACKING AND HAPTIC SUIT

  • Page 1 BODY TRACKING AND HAPTIC SUIT USER MANUAL...
  • Page 2 SHOCKWAVE 383, 9 Main, 7 HSR Layout, Bengaluru, KA India SUPPORT: www.shockwavesuit.com support@shockwavesuit.com...
  • Page 3 COMPLIANCE FCC Compliance Statements Contains FCC ID:2A094-MK02 The equipment has a model number assigned as SS00 . This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2.
  • Page 4 ISED Compliance Statements Contains IC: 26442-MK02 This device complies with ISED's license-exempt RSSs. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil est conforme aux RSS exemptés de licence de l’ISED.

  • Page 5: Table Of Contents

    Putting on your suit Strapping the lower body straps Inserting the batteries Powering the suit Calibrating the suit 3. Wash care instructions for your Shockwave Suit How to wash How to dry Don’ts 4. Health and safety warnings Conditions for use...

  • Page 6: Accessories

    1. Accessories The Shockwave suit comes with the following accessories • Battery compartment for 3 x AA batteries (not included) with cable and connector • 1 x USB to 2.1mm DC Jack power cable • 1 x Tightening Belt • 1 x Silicone Cap...

  • Page 7: Setting Up Your Shockwave Suit

    2. Setting up your Shockwave Suit Setting up your Shockwave suit involves the following steps • Putting on your suit • Strapping the lower body straps • Inserting the batteries • Powering the suit • Calibrating the suit Putting on your suit...
  • Page 8 If required, use the belt provided to tighten the suit around your waist for a body-tight fit Strap the hanging lower body pieces around your legs and fasten them with the Velcro...
  • Page 9 Insert 3 x AA batteries in the battery box provided with the suit and secure the cover...
  • Page 10 Put the battery compartment inside the side pocket of the suit Connect the power cable of the battery compartment to the power connector in the suit and switch the power button to ‘on’...
  • Page 11 The suit can also be powered using the provided USB to DC Jack cable by a regionally compliant PORTABLE battery pack whose voltage should not exceed 5V. The pack has to be standalone and should not be directly or indirectly connected to any public utility power e.g. Mains electricity, laptops etc The Portable battery pack should always be kept inside the pocket The logo on the back of the suit will start blinking red every 5 seconds indicating the suit being powered The suit will begin advertising using Bluetooth 5.0 and can be connected to all supporting hardware with...
  • Page 12 On a successful connection the blinking logo on the back of the suit will turn from red to blue Follow the link on the website www.shockwavesuit.com/downloads to download the software required to calibrate the suit. The body tracking sensors need to be calibrated with your receiving device. Follow the instructions inside the software to perform the calibration.

  • Page 14: Wash Care Instructions For Your Shockwave Suit

    • How to dry • Don’ts How to wash We recommend that you hand-wash your Shockwave suit - Detach the battery compartment from the suit - Before washing, ensure that you have covered the power port with the silicone cap...

  • Page 15: How To Dry

    How to dry After washing, you can dry the shockwave suit outside in the sunlight or you may air dry at normal temperature - Avoid air drying at very high temperature - Avoid using an electrical drier to dry the suit - Avoid using electrical iron (or similar equipment) to dry the suit Don’ts...

  • Page 16: Health And Safety Warnings

    4. Health and Safety Warnings Read the following instructions and warnings to reduce the risk of personal injury and discomfort including electric shock, fire and other damage to you or your surroundings. Conditions for Use • The product is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge, unless they have been given supervision or instructions concerning the use of product by person responsible for their safety.

  • Page 17: Storage

    • The product is intended to be used in conjunction with other devices like Virtual Reality headsets, personal computers etc . Please make sure you follow the safety guidelines outlined in those products when using them with the Shockwave suit.

  • Page 18: Heating And Overuse

    • DO NOT store batteries with hazardous or combustible material; store in a cool, dry, ventilated area. • While your Shockwave suit is weatherproof and safe to use outside, DO NOT allow the batteries or battery compartment to get wet prior to or during use.
  • Page 19 • Follow local guidelines to dispose of used batteries. To the extent permissible by applicable law, failure to follow these warnings and/or directions could result in damage to your product that will not be covered by Shockwave suit’s warranty.
