Summary of Contents for Freeweel FLEX R-1
- Page 1 FREEWEEL EBIKES FLEX R-1 OWNER’S MANUAL Thank you for purchasing our ebike. We hope that it will bring you years of riding pleasure. If you have any comments or concerns, please contact us at support@freeweel.com or visit our website at www.freeweel.com...
- Page 2 Your e-bike will need to be serviced after 160KM or 5 full battery charge cycles, whichever comes first. This is what we call the “wear in period” of the e-bike. Freeweel recommends having service done at your local e-bike shop by a certified and reputable e-bike mechanic.
-
Page 3: Installing The Front Wheel
Multi-purpose bike tool Before removing the packaging material from the e-bike, remove all items from the box and make sure everything listed above is present. If anything is missing or damaged contact Freeweel immediately for assistance. INSTALLING THE FRONT WHEEL DANGER: Your wheels must be fully seated in the fork’s dropouts and the nuts firmly tightened to... -
Page 4: Installing The Pedals
STEP 3: Tighten the nut and the quick release nut onto both sides of the wheel axle. When both sides are moderately tight, close the quick release bar to securely tighten the wheel. If you are not sure of the correct tightness, consult a local bike shop NOTE: When installed correctly, the wheel should spin freely without any wobble. - Page 5 The battery comes with almost a full charge. You should plug your battery in when you first receive it to ensure it is fully charged prior to your first ride. Do not charge the battery with chargers other than the charger provided by Freeweel Ensure there is no dirt, debris, or flammable items nearby when using the charger.
- Page 6 Lithium Ion batteries can be dangerous. Take care when using and charging your battery. Failure to follow the above guidelines could result in damage to property and/or serious injury. Contact Freeweel immediately if you have any questions regarding battery safety.
- Page 7 Display Content Flex R1 interface Precautions Take care when using the display and do not connect/disconnect it while the power is on. Avoid striking or knocking the display Do not remove the waterproof film attached to the display as this may impair its waterproofing. ...
- Page 8 Push Assistance 6km/h 3.3. Press and hold DOWN to enable the push assistance mode. The motor will cause the bike to travel at 6km/h. 6km/h illustration Pedal Assist (PAS) Level 3.4. Press UP and DOWN to alter the PAS level, changing the output power of the motor. The range of PAS levels is 1-5.
- Page 9 Charging interface Error codes 3.7. When the system encounters an error, the display would show the relevant error code. Only once the problem/s has been resolved will the display return to normal functionality. The e-Bike will cease functioning so long as an error code is shown.
- Page 10 The default value is 26inch.Please press UP and DOWN to change the wheel size and then press MODE to confirm, entering into next setting. Wheel size setting Speed limit setting will set the Max speed of the bike. When the bike exceeds the setting speed, the controller will stop the outputting of the motor to protect the riders.
- Page 11 7 (seven) calendar days of the receipt of the Products. Should the Customer fail to inform Freeweel within the above mentioned term, its rights to exercise any of its rights with regard to such irregularity or defect have lapsed.
-
Page 12: Warranty
The Customer shall not be entitled to return Products to Freeweel before Freeweel has agreed in writing to such return. WARRANTY Freeweel guarantees each new Freeweel e-bike frame against defects in workmanship and materials for one (1) year from the date of delivery. All original components are guaranteed for a period of one (1) year from the date of delivery.
