OPERATION AND INSTALLATION MANUAL
Temperature and humidity measuring sensor - TEMPHU
V2.5 Published on 2021-08-16
General information
The TEMPHU is advanced technology sensor measures the magnitude of the
temperature, humidity and used indoors. The data transmitted from the sensor is based
on Class A LoRaWAN® wireless network. TEMPHU is powered with one or two batteries
and able to operate up to 15 years depending on the configuration and either one or two
batteries are inserted. The TEMPHU sensor is easily configured and connected to the
LoRaWAN® wireless network. The calibration is not needed for the TEMPHU since it has
automatic self-calibration based on integrated advanced intelligent (AI) computational
algorithm.
The main technical characteristics and benefits of TEMPHU sensor:
•
Compatible with LoRaWAN® specification 1.0.3
•
Measures temperature
•
Measures humidity
•
Measurements at regular intervals with integrated advanced intelligent (AI) computational algorithms
•
Indoor use
•
Easy to use and deploy
•
Powered by batteries
•
Data transmission up to 10 km.
•
Battery life is up to 10 years depending on settings and environmental conditions
Applications
•
Indoor environment measuring
•
Smart buildings
•
Government buildings
•
Public buildings
•
Banks
•
Industrial facilities
•
Factories
UAB " Nano sensorics"
�� Pakaunės g. 70, LT-47243 Kaunas
�� www.nanosensorics.com
✉ info@nanosensorics.com
Product features
•
LoRaWAN communication
•
Computational AI algorithm.
•
Indoor temperature sensor
•
Indoor humidity sensor
•
Configuration over the air
•
Robust enclosure
•
Auto self-calibration
Advertisement
Summary of Contents for nano sensorics TEMPHU
- Page 1 The data transmitted from the sensor is based on Class A LoRaWAN® wireless network. TEMPHU is powered with one or two batteries and able to operate up to 15 years depending on the configuration and either one or two batteries are inserted.
- Page 2 • Use a screwdriver to unscrew the back cover as showed in the picture: • Use the lithium batteries type AA 3.6V (1 or 2 units) to install in the TEMPHU sensor as showed in the picture: • Use a screwdriver to screw the back cover with four screws as showed in the picture.
- Page 3 LoRaWAN network. The TEMPHU sensor has to be installed reliably and with appropriate screws. The sensor must not be placed near any air vents windows, door openings where the constant fresh air flow is possible. The sensor is not suitable to be installed for the outdoor locations.
- Page 4 Sensor dimensions: Important safety information Read this manual before attempting to install the device. UAB „ Nano sensorics” will not accept responsibility for any damage or injury resulting from not following the instructions in this manual. • The sensor is for indoor use;...
- Page 5 Configurable via downlink configuration, NFC configuration is optional Data Upload Configurable via downlink configuration, NFC configuration is optional Interval Radio / Wireless specification Wireless LoRaWAN® 1.0.3 Technology Wireless Security LoRaWAN® End-to-End AES encryption UAB “ Nano sensorics” �� Pakaunės g. 70, LT-47243 Kaunas �� www.nanosensorics.com ✉ info@nanosensorics.com...
- Page 6 Warranty period is 1 year from manufacturing date, with additional possibility to extend it for additional charge. UAB “ Nano sensorics” �� Pakaunės g. 70, LT-47243 Kaunas �� www.nanosensorics.com...
