- Page 1 SVC i-SERIES UNDERWATER HOUSING USER MANUAL Revision 2.3.1 29 Firemens Way, Poughkeepsie, New York 12603 Voice: (845) 471-7007, Fax: (845) 471-7020, E-mail: svcinfo@spectravista.com Copyright © 2019 Spectra Vista Corporation...
-
Page 3: Table Of Contents
Table Of Contents Overview ........................1 Handles ......................... 4 Clear Panels ........................4 Controls ......................... 5 Installation – Instrument Into Enclosure ASM512-500 / ASM1024-500 ..... 6 SPECIAL NOTE – Enclosure Leak Check ..............15 Removal of the Instrument from the Housing ............15 Ballast Weights ...................... - Page 4 Table of Figures Figure 1 ASM512-500 Housing, Rear View ..............1 Figure 2 ASM1024-500 Housing, Rear View .............. 2 Figure 3 ASM512-500 Housing, Front View ............... 3 Figure 4 ASM1024-500 Housing, Front View ............. 3 Figure 5 Rear Controls (ASM512-500 and ASM1024-500) ........5 Figure 7 Trim Blocks (Right Side Shown) Installed ............
-
Page 5: Overview
Overview This User Manual applies to the following SVC products: ASM512-500 Underwater Housing for SVC HR-512i Spectroradiometers ASM1024-500 Underwater Housing for SVC i-Series full-range Spectroradiometers The Underwater Housing provides a secure and convenient means to conduct submerged data collections at depths of up 40 meters (130 feet) in either salt or fresh water. The standard 4°... -
Page 6: Figure 2 Asm1024-500 Housing, Rear View
DRAW LATCHES (4 TOTAL) ANODIZED ALUMINUM HOUSING SACRIFICIAL ZINC (3 TOTAL) HANDLES (4 TOTAL) O-RING SEALS REAR ACRYLIC PANEL (2 TOTAL) Figure 2 ASM1024-500 Housing, Rear View The front optical glass port is also sealed with an O-ring, and is semi-permanently installed (shown in Figures 3 and 4). -
Page 7: Figure 3 Asm512-500 Housing, Front View
HANDLES (4 TOTAL) FRONT OPTICAL PORT TARGET ACQUISTION PROTECTIVE SKIDS SACRIFICIAL ZINC PUSHBUTTON Figure 3 ASM512-500 Housing, Front View FRONT OPTICAL PORT SACRIFICIAL ZINC (3 TOTAL) HANDLES (4 TOTAL) TARGET ACQUISTION PUSHBUTTON PROTECTIVE SKIDS Figure 4 ASM1024-500 Housing, Front View... -
Page 8: Handles
Handles Two sets of handles are provided to facilitate operation of the submerged unit in either a horizontal or a vertical orientation. The handles are held in place with stainless socket head cap screws. On the right-hand side handle, a waterproof pushbutton switch, operated by the diver’s thumb, has been incorporated to acquire spectral scans when the instrument is located vertically, with the optical port at the bottom. -
Page 9: Controls
Controls When the instrument is installed within the Underwater Housing, the touch-screen controls are accessed via a set of specially-designed, sealed actuator pins (aka plungers), using a design which has been well-proven in the field. These plungers are incorporated into the rear acrylic panel (shown in Figure 5). The plungers are used by the diver to operate the menus on the LCD panel on the rear of the instrument. -
Page 10: Installation - Instrument Into Enclosure Asm512-500 / Asm1024-500
Installation – Instrument Into Enclosure ASM512-500 / ASM1024-500 Confirm that the two P/N MAC1024157 stainless steel lifting eyes (shown in Figure 6) have been removed from the instrument prior to installing it in the Underwater Housing. The lifting eyes are replaced by two aluminum trim blocks (P/N MAC1024166). (See Figure 7), secured with the original lifting eyes’... -
Page 11: Figure 8 Alignment Probe Installed On Instrument Base Plate
Install the instrument Alignment Probe onto the instrument base plate using two of 1/4-20 x 0.625” Hex Socket Head Flat Countersunk screws as shown below (See Figure 8). The alignment probe mates with the Alignment Fixture that is mounted within the Underwater Housing. -
Page 12: Figure 9 Instrument Prior To Rear Panel Installation
Turn the instrument upside down, and gently place it on a table near an edge (See Figure 9) in order to install the Enclosure Rear Panel. Hang about 1 inch of the instrument over the edge. Figure 9 Instrument Prior To Rear Panel Installation Place the Rear Panel over the bottom of the instrument, and fasten it to the instrument using four thumbscrews (See Figure 10 –... -
Page 13: Figure 11 Hr-1024I Instrument After Rear Panel Installation
INTERCONNECT CABLE PLUGS 6-32 x 3/8” INTO OPTICAL THUMBSCREWS PLATE 8-32 x 3/8” THUMBSCREWS Figure 11 HR-1024i Instrument After Rear Panel Installation Slide a fully-charged battery into the assembly (See Figure 12). The Rear Panel assembly onto the instrument is now complete. Figure 12 Instrument Battery Installed... -
Page 14: Figure 13 Rear Panel Pre-Installation Test
Now turn the Rear Panel assembly over, so that the instrument is oriented as shown below (See Figure 13). LASER / TRIGGER POWER ON BATTERY CHARGE POWER OFF PERCENTAGE Figure 13 Rear Panel Pre-Installation Test Turn on the instrument and operate all of the controls and LCD plungers in order to confirm that they all work properly. -
Page 15: Figure 14 View Down Into Enclosure
Place the enclosure on the floor facing upwards, as shown below (See Figure 14). The four draw latches should be wide open and the internal trigger cable should be pulled free and its connector made ready to attach to the mating connector on the bottom of the rear panel tray. DRAW LATCHES ALIGNMENT RECEIVER... -
Page 16: Figure 15 Connecting Cabling
While one person holds the Rear Panel / Instrument assembly just above the enclosure opening, have a second person connect the internal trigger cable connector to its mate on the bottom of the Rear Panel. (See Figure 15). INTERNAL TRIGGER CABLE CONNECTOR Figure 15 Connecting Cabling... -
Page 17: Figure 16 Lowering Rear Panel Assembly Into Enclosure
Continue lowering the Rear Panel / Instrument assembly down into the enclosure (See Figure 16). Take care that neither the cabling nor the instrument’s cloth hand strap becomes pinched as the assembly is lowered down into the enclosure. Figure 16 Lowering Rear Panel Assembly Into Enclosure Note that in order for the Alignment Probe to settle into the Alignment Receiver, the assembly may have to be tilted back/forth during the last 2-3 centimeters until the two parts engage correctly. -
Page 18: Figure 17 Rear Panel Inserted Into Enclosure
When they have engaged, the assembly will come to rest on the first O-ring as shown below (See Figure 17). Figure 17 Rear Panel Inserted Into Enclosure The assembly is completed by firmly pressing down on the Rear Panel handles until it is fully inserted into the enclosure, and then engaging the four Draw Latches. -
Page 19: Special Note - Enclosure Leak Check
SPECIAL NOTE – Enclosure Leak Check While each housing has been water tested for leaks prior to shipment, it is strongly recommended (owing to the cost of the Spectroradiometer) that the empty housing be “bounce dived” to the maximum expected working depth prior to the unit’s first use after shipping or after storage for any extended period. -
Page 20: Figure 18 Draw Latch, Used For Rear Panel Extraction
LATCH HOOK DRAW LATCH CROSS BAR RELEASE TAB DRAW LATCH Figure 18 Draw Latch, Used for Rear Panel Extraction... -
Page 21: Figure 19 Using Jackscrews To Extract Rear Panel
Figure 19 Using Jackscrews To Extract Rear Panel The Rear Panel supports the use of four nylon jackscrews (P/N HDW001409) as an aid to extracting the Rear Panel / Instrument assembly from the enclosure (See Figure 19). After releasing all four latches, insert the four jackscrews as shown, hand-tightening each until they all bottom out against the rear face of the enclosure opening. -
Page 22: Ballast Weights
Ballast Weights Standard dive weights may be used to provide any necessary ballast. The weights may be secured to the black skids located on the bottom of the housing, using standard cable ties. It is recommended that the unit be set up to be very slightly negative to allow for easy underwater maneuvering. -
Page 23: Specifications - Asm512-500 / Hr-512I
Specifications – ASM512-500 / HR-512i The following specifications apply to the underwater housing for the SVC HR-512i: Unit Size 13.5 inch long, 13.3 inch wide, 8.4 inch high 34.3 cm. long, 33.8 cm. wide, 21.3 cm. high Unit Weight (Including Instrument) 31.6 lb. -
Page 24: Specifications - Asm1024-500 / Full-Range Instruments
Specifications – ASM1024-500 / Full-Range Instruments The following specifications apply to the underwater housing for the SVC full-range i-Series instruments: Unit Size 17.3 inch long, 13.5 inch wide, 8.3 inch high 43.9 cm. long, 34.3 cm. wide, 21.1 cm. high Unit Weight (Including Instrument) 43 lb. - Page 25 Document Revision Sheet Revision Section Revised By Date Level Revision 1.0.0 05/30/2018 Initial version 2.0.0 02/05/2019 Images, new hsg. design 2.1.0 03/25/2019 Photos, new hsg. design 2.1.1 Installation 04/16/2019 Photos, new tray design Added full range 09/01/2019 instrument housing Combined the 512i and 1024i installation 12/10/2019 sections per new 512i...
