KODAK
Portable Projection Screen 120"
With Foldable Legs and Front/Rear Projection
User Guide
RODPJSFFSG120

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RODPJSFFSG120 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kodak RODPJSFFSG120

  • Page 1 KODAK Portable Projection Screen 120" With Foldable Legs and Front/Rear Projection User Guide RODPJSFFSG120...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION SAFETY PRECAUTIONS ABOUT SPECIFICATIONS PACKAGE CONTENTS PRODUCT OVERVIEW 4-12 ASSEMBLY INSTRUCTIONS CARE & MAINTENANCE 14-16 WARRANTY INFORMATION GET IN TOUCH TO SEE THIS GUIDE IN FRENCH, ITALIAN, GERMAN, OR SPANISH, PLEASE VISIT WWW.KODAKPHOTOPLUS.COM OR USE THIS QR CODE: Um diese Anleitung auf Französisch, Italienisch, Deutsch oder Spanisch zu lesen, besuchen Sie bitte www.kodakphotoplus.com oder nutzen Sie diesen QR-Code.
  • Page 3: Introduction

    INTRODUCTION Thank you for purchasing the KODAK Portable Projection Screen 120” with Foldable Legs and Front/Rear Projection. This User Guide is intended to provide you with guidelines to ensure that operation of this product is safe and does not pose risk to the user.
  • Page 4: About

    ABOUT • Lightweight, collapsible frame and legs for quick, simple setup. No tools required! • Included, heavy-duty bag for portability and storage convenience • Great for parties, concerts, meetings, and other large gatherings • Quality, embossed screen eliminates glare and enhances sharpness of color •...
  • Page 5: Package Contents

    PACKAGE CONTENTS 6 Hand screws x 12 Front/rear screen fabric 7 Outdoor stakes x 4 2 Foldable screen frame 8 Ropes x 2 3 Foldable legs x 2 9 Silver loops x 2 4 Front support braces x 2 10 User guide 5 Projection screen carrying bag...
  • Page 6: Product Overview

    PRODUCT OVERVIEW 1 Screen fabric 2 Screen frame 3 Screen leg 4 Front support brace ASSEMBLY INSTRUCTIONS NOTE: This assembly may require two (2) people to complete. 1. Remove the screen frame from the packaging and place it on a large, flat surface. Then, carefully unfold the larger sections of the frame so the length of the frame is fully extended.
  • Page 7 2. Next, unfold the smaller sections of the frame so the width of frame is fully extended.
  • Page 8 NOTE: You should hear a click sound to know when joints of the frame are securely locked in place. click 3. Then, take out the screen fabric and place it at one corner of the frame. Next, start unfolding the fabric until it is completely spread out within the frame.
  • Page 9 4. Fasten the screen fabric to the frame. Make sure to fasten the corners first before fastening the sides of the screen. 5. Unfold the screen legs. Make sure you hear the click sound to know that the joints of the legs are locked in place. (The front piece of the legs is the only part that should still be folded up.) click...
  • Page 10 6. Fasten the back piece of the screen legs to the back of the screen legs using one (1) hand screw for each leg. 7. Lay the frame on a flat surface with the screen frame facing up and place the screen legs on back of the frame. 8.
  • Page 11 NOTE: To adjust the height of the screen, change the position of where the screen legs are attached to the frame. 9. Once the legs are fastened to the frame, lift the screen so the entire assembly is standing upright. (This will require a two-person team lift.)
  • Page 12 10. Once the screen is upright, extend the front piece of the legs out. 11. Connect the front support brace to the front piece of the screen leg using two (2) hand screws so the projection screen is stable. Then, do the same for the second front support brace.
  • Page 13 PROJECTOR SETUP: • For rear projection, set your projector up behind the screen. • For front projection, set your projector up front of the screen. (Make sure projector has clear line of sight of the screen and no people are blocking the projection.) TO DISASSEMBLE: 1.
  • Page 14 3. Grab the rope and insert it through the loop on the top corner of the frame. 4. Then, repeat steps 2 through 3 for the other side of the projection screen. 5. Raise up the screen so it stands upright. Grab the end of the rope and tie it to a stake.
  • Page 15: Care & Maintenance

    CARE & MAINTENANCE: • When the screen is in use, please do not touch the screen surface with hands or sharp objects. Clean the screen surface with a damp, soft cloth. Wipe the screen carefully. • When storing the product, the screen is made from anti-crease material •...
  • Page 16: Warranty Information

    LIMITED WARRANTY TO ORIGINAL CONSUMER This KODAK Portable Projection Screen 120” with Foldable Legs and Front/ Rear Projection (“Product”), including any accessories included in the original packaging, as supplied and distributed new by an authorized retailer is warranted by C&A Marketing, Inc. (the “Company”) to the original consumer purchaser only, against certain defects in material and workmanship (“Warranty”) as follows:...
  • Page 17 (g) Consumable parts, such as batteries, fuses, and bulbs; (h) Cosmetic damage; or (i) If any KODAK Portable Projection Screen 120” with Foldable Legs and Front/Rear Projection serial number has been removed or defaced. This Warranty is valid only in the country where the consumer purchased the Product, and only applies to Products purchased and serviced in that country.
  • Page 18 EXTENT PERMITTED BY APPLICABLE LAW, THE COMPANY PROVIDES THE PRODUCT “AS-IS” AND “AS-AVAILABLE” FOR YOUR CONVENIENCE AND THE COMPANY AND ITS LICENSORS AND SUPPLIERS EXPRESSLY DISCLAIM ALL WARRANTIES AND CONDITIONS, WHETHER EXPRESSED, IMPLIED, OR STATUTORY, INCLUDING THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, QUIET ENJOYMENT, ACCURACY, AND NON-INFRINGEMENT OF THIRD-PARTY RIGHTS.
  • Page 19: Get In Touch

    CUSTOMER SERVICE Should you experience any problems with your product, please contact us before returning the item to the place of purchase. We’re here to help! U.S. Support: kodak@camarketing.com 844-516-1539 International Support: kodakintl@camarketing.com 844-516-1540...
  • Page 20 The Kodak trademark, logo, and trade dress are used under license from Eastman Kodak Company. All other products, brand names, company names, and logos are trademarks of their respective owners, used merely to identify their respective products, and are not meant to connote any sponsorship, endorsement, or approval.
