B&B Electronics 1110F Manual

Asynchronous, carrier controlled fiber optic modem
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Technical Support e-mail: support@bb.elec.com -- Fax (815) 433-5104
1110F1799 Manual
B&B Electronics Mfg Co – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104
B&B Electronics Ltd – Westlink Comm. Pk – Oranmore, Galway, Ireland – Ph 353-91-792444 – Fax 353-91-792445
Arrow.com.
Downloaded from
Asynchronous, Carrier Controlled
Fiber Optic Modem
Models: 1110F 1110M
Document No. 1110F1799
International Headquarters
B&B Electronics Mfg. Co. Inc.
707 Dayton Road -- P.O. Box 1040 -- Ottawa, IL 61350 USA
Phone (815) 433-5100 -- General Fax (815) 433-5105
Home Page: www.bb-elec.com
Sales e-mail: sales@bb-elec.com -- Fax (815) 433-5109
European Headquarters
Westlink Commercial Park, Oranmore, Co. Galway, Ireland
Phone (353) 91 792444 -- Fax (353) 91 792445
Home Page: www.bb-europe.com
Sales e-mail: sales@bb-europe.com
Technical Support e-mail: support@bb-europe.com
1996 B&B Electronics -- Revised April 1999
B&B Electronics Ltd.
CE
CE
Cover Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1110F and is the answer not in the manual?

Questions and answers

Related Manuals for B&B Electronics 1110F

Summary of Contents for B&B Electronics 1110F

  • Page 1 Asynchronous, Carrier Controlled Fiber Optic Modem Models: 1110F 1110M Document No. 1110F1799 International Headquarters B&B Electronics Mfg. Co. Inc. 707 Dayton Road -- P.O. Box 1040 -- Ottawa, IL 61350 USA Phone (815) 433-5100 -- General Fax (815) 433-5105 Home Page: www.bb-elec.com Sales e-mail: sales@bb-elec.com -- Fax (815) 433-5109...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1.0 WARRANTY INFORMATION............1 1.1 RADIO AND TV INTERFERENCE..........1 1.2 SERVICE ..................2 2.0 GENERAL INFORMATION............3 2.1 FEATURES................... 3 2.2 DESCRIPTION ................3 3.0 CONFIGURATION................. 5 3.1 SETTING THE EXTERNAL DCE/DTE SWITCH ......5 3.2 SETTING INTERNAL DIP SWITCHES ........5 3.2.1 Detailed Switch Settings............

  • Page 3: Warranty Information

    1.0 WARRANTY INFORMATION B&B Electronics warrants all Model 1110 components be free from defects, and will—at our option—repair or replace the product should it fail within one year from the first date of shipment. This warranty is limited to defects in workmanship or materials, and does not cover customer damage, abuse or unauthorized modification.

  • Page 4: Service

    1.2 SERVICE All warranty and non-warranty repairs must be returned freight prepaid and insured to B&B Electronics. All returns must have a Return Materials Authorization number on the outside of the shipping container. This number may be obtained from B&B Electronics Customer Service Department at (815) 433-5100 x218.

  • Page 5: General Information

    2.0 GENERAL INFORMATION Thank you for your purchase of this B&B Electronics product. This product has been thoroughly inspected and tested and is warranted for One Year parts and labor. It any questions or problems arise during installation or use of this product, please do not hesitate to contact B&B Electronics Technical Support at (815) 433-5100.
  • Page 6 Measuring only 6.8 x 5.3 x 1.9 cm (2.66” x 2.10" x .73"), the Model 1110 is able to fit into tight installation spaces. A convenient pop-open/snap-shut ABS plastic case allows easy access to configuration switches. On the RS-232 side, the Model 1110 comes equipped with either a male or female DB-25 connector;...

  • Page 7: Configuration

    3.0 CONFIGURATION The Model 1110 is simple to install and is ruggedly designed for excellent reliability: just set it and forget it. This section will describe how to configure the Model 1110's DCE/DTE switch and how to set the internal DIP switches. 3.1 SETTING THE EXTERNAL DCE/DTE SWITCH For your convenience, the Model 1110 has an externally accessible DCE/DTE switch (see Figure 1, below).

  • Page 8: Detailed Switch Settings

    Figure 2. Use a small screwdriver to open the Model 1110 case. 3.2.1 Detailed Switch Settings The DIP switches on the Model 1110 PC board are labeled 1-8. Only switches 1-5 are used. Switches 6-8 are reserved for future use. Below are descriptions of the Model 1110 DIP switch settings. Switch 1: Carrier Control The setting for Switch 1 determines whether carrier is constantly on or controlled by RTS.

  • Page 9: Switch 4: Enable Carrier Detect Led

    Switch 4: Enable Carrier Detect LED The setting for Switch 4 determines whether the Model 1110 “carrier detect" LED indicator is enabled. When enabled, the carrier detect LED will glow red if a proper carrier frequency is recognized. Carrier Detect LED Enabled Disabled *Factory default...

  • Page 10: Installation

    4.0 INSTALLATION The Model 1110 is easy to install. After configuring the DIP switches, simply connect the two fiber cables and then connect the RS-232 interface. Figure 3 below shows the location of the fiber connections on the Model 1110's rear panel. Figure 3.

  • Page 11: Operation

    5.0 OPERATION Once you have configured each Model 1110 properly and connected the fiber and RS-232 cables, you are ready to operate the units. This section describes the LED status monitors and the power up process. 5.1 LED STATUS MONITORS The Model 1110 features two status LEDs that indicate the condition of carrier detect and fiber optic output.

  • Page 12: Appendix A. Specifications

    APPENDIX A. SPECIFICATIONS Transmission Line: Dual optical cable Transmission Mode: Asynchronous, half or full duplex, point-to-point Interfaces: EIA RS-232, CCITT V.24 Data Rates: 0 -19.2 Kbps Distance: 3.2 Km (2 miles) over continuous fiber RTS/CTS Delay: Switch-selectable: No delay, 9.5 mS, 79.5 mS Receiver Sensitivity: -45 dBm Coupled Power Output: -30 to -36 dBm Optic Wavelength: 850 nm...

  • Page 13: Appendix B. Pin Configurations

    APPENDIX B. PIN CONFIGURATIONS 1110F1799 Manual B&B Electronics Mfg Co – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 B&B Electronics Ltd – Westlink Comm. Pk – Oranmore, Galway, Ireland – Ph 353-91-792444 – Fax 353-91-792445 Arrow.com.

  • Page 14: Appendix C. Block Diagram

    APPENDIX C. BLOCK DIAGRAM 1110F1799 Manual B&B Electronics Mfg Co – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 B&B Electronics Ltd – Westlink Comm. Pk – Oranmore, Galway, Ireland – Ph 353-91-792444 – Fax 353-91-792445 Arrow.com.

  • Page 15: Appendix D: Declaration Of Conformity

    APPENDIX D: Declaration of Conformity 1110F1799 Manual B&B Electronics Mfg Co – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 B&B Electronics Ltd – Westlink Comm. Pk – Oranmore, Galway, Ireland – Ph 353-91-792444 – Fax 353-91-792445 Arrow.com.
  • Page 16 radiate radio frequency energy and, if not installed and accordance with the instructions, may cause harmful in radio communications. Operation of this equipment in a area is likely to cause harmful interference, in which ca will be required to correct the interference at personal e FCC Class A Equipment Statement Arrow.com.
