operator manual
Lettuce King I and Lettuce King IV
This document includes:
• Safety Notices
• Specifi cations
• Installation Instructions
• Operating Instructions
• Cleaning Instructions
• Warranty Statement
P/N: 2802381
Revision: C
Lettuce King I
Lettuce King IV
Lincoln Foodservice Products, LLC
1111 North Hadley Road
Fort Wayne, Indiana 46804
United States of America
Technical Support Hotline: (800) 678-9511
Telephone: (260) 459-8200
www.lincolnsmallwares.com
Advertisement
Table of Contents
Summary of Contents for Lincoln Redco Lettuce King I
- Page 1 Lettuce King I and Lettuce King IV This document includes: • Safety Notices • Specifi cations • Installation Instructions • Operating Instructions • Cleaning Instructions • Warranty Statement P/N: 2802381 Revision: C Lettuce King I Lettuce King IV...
- Page 2 WARNING AND SAFETY INFORMATION This machine contains sharp blades and can cause serious injury or death if not handled WARNING: properly. All operators of this equipment should read this operator manual before operating equipment. In order to avoid damage to people and the appliance, read and follow the manufacturer’s CAUTION: instructions for the cleaning of this equipment.
- Page 3 BASE INSTALLATION - LETTUCE KING I Tools required for proper installation: • One (1) 3/16” Allen Wrench (included) • Four (4) Fil. Hd. Screws, 1/4-20 x 3/8” • Four (4) Lock Washers • Two (2) Leg Castings Allen Wrench Fil. Hd. Screws &...
- Page 4 BASE INSTALLATION - LETTUCE KING IV Tools required for proper installation: • One (1) 7/16” Socket Wrench (not provided) • Four (4) Hex Hd. Screws, 1/4-20 x 1/2” • Four (4) Rubber Seals • Two (2) Legs Rubber Seal Insert Leg into Main Frame being sure to Hex Hd.
- Page 5 Prior to fi rst use, it is important to clean the unit. Wash new blades with warm soapy water CAUTION: and rinse thoroughly to remove the thin protective oil fi lm. OPERATING INSTRUCTIONS - LETTUCE KING I Blades are sharp and can cause serious injury. Never use machine unless all four rubber CAUTION: feet are in place.
- Page 6 fi lm. Allow yourself ample room to work on a fl at, dry surface. Open the Lettuce King I or Lettuce King IV by raising the pusher head until it stops. To allow more room, the pull pin on the Lettuce King IV may be removed from the frame casting and the entire pusher head may be removed.
- Page 7 BLADE REPLACEMENT (CONT’D) LETTUCE KING IV The following instructions pertain to the Lettuce King IV. A. When replacing both blade assemblies, you will fi nd it easier to install the bottom blade assembly fi rst. B. Be sure that blade block shields are installed (see exploded view drawing letter “F”). C.
