Corometrics 340 Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Corometrics
OPERATOR'S MANUAL
340R
Telemetry Receiver
COROMETRICS
TOCO
Model 340
IUP
XXX
MANUAL P/N 2003720-001 REV. B
+
~

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 340 and is the answer not in the manual?

Questions and answers

Summary of Contents for Corometrics 340

  • Page 1 Corometrics Model 340  OPERATOR’S MANUAL MANUAL P/N 2003720-001 REV. B 340R Telemetry Receiver COROMETRICS TOCO...
  • Page 3 Corometrics Model 340  OPERATOR’S MANUAL MANUAL P/N 2003720-001 REV. B 340R Telemetry Receiver COROMETRICS TOCO...
  • Page 4 CAUTION: In the United States of America, Federal Law restricts this device to sale by or on the order of a physician. GE Medical Systems Information Technologies. Corometrics and Marquette are registered trademarks of GE is a registered trademark of General Electric Company. All other product and brand names are trademarks or registered trademarks GE Medical Systems Information Technologies of their respective companies.

  • Page 5: Table Of Contents

    Product Features ........... . 2-3 Revision B Model 340 Telemetry System 2003720-001...
  • Page 6 IUP ............. 5-4 Model 340 Telemetry System...
  • Page 7 Model 340R Receiver ..........9-4 Revision B Model 340 Telemetry System 2003720-001...
  • Page 8 For your notes Model 340 Telemetry System Revision B 2003720-001...

  • Page 9: Figures

    Attaching the Transmitter Antenna ........4-9 Revision B Model 340 Telemetry System 2003720-001...
  • Page 10 Connecting a Tocotransducer or IUPC Cable ......4-14 Model 340 Telemetry System...
  • Page 11 MECG Supplies ............8-8 Revision B Model 340 Telemetry System 2003720-001...
  • Page 12 For your notes viii Model 340 Telemetry System Revision B 2003720-001...

  • Page 13: Safety

    ........Revision B Model 340 Telemetry System 2003720-001...

  • Page 14: General Information

    Information Technologies ; the electrical installation of the relevant room complies with the requirements of appropriate regulations; and the equipment is used in accordance with the instructions for use. Model 340 Telemetry System Revision B 2003720-001...

  • Page 15: Definitions Of Terminology

    An IMPORTANT notice indicates an emphasized Important note. It is something you should be particularly aware of; something not readily apparent. A NOTE indicates a particular point of information; Note something on which to focus your attention. Revision B Model 340 Telemetry System 2003720-001...

  • Page 16: Equipment Safety Information

    If you feel interference is affecting the equipment, contact your Service Representative to check the equipment in your environment. Model 340 Telemetry System Revision B 2003720-001...
  • Page 17 Consideration relating to the choice shall include: use of the accessory in the patient vicinity; and evidence that the safety certification of the accessory has been performed in accordance with the appropriate IEC 601.1 and/or IEC 601.1.1 harmonized national standard. Revision B Model 340 Telemetry System 2003720-001...
  • Page 18 STRANGULATION—Make sure all patient cables, leadwires, and tubing are positioned away from the patient’s head to minimize the risk of accidental strangulation. Model 340 Telemetry System Revision B 2003720-001...

  • Page 19: Cautions

    PERFORMANCE—Report all problems experienced with the equipment. If the equipment is not working properly, contact your Service Representative for service. The equipment should not be used if it is not working properly. Revision B Model 340 Telemetry System 2003720-001...

  • Page 20: Equipment Symbols

    B equipment with an F-type isolated (floating) part. The paddles indicate the equipment is defibrillator proof. ALTERNATING CURRENT (AC). IPX1 DRIP PROOF. EQUIPOTENTIALITY. POWER OFF: disconnection from the mains. POWER ON: connection to the mains. Model 340 Telemetry System Revision B 2003720-001...

  • Page 21: Fcc Information

    Model 340 Telemetry System requires an FCC General Radio Telephone License. Any changes or modifications made to the Model 340 Telemetry System that are not expressly approved by Information Technologies , could void the user’s authority to operate this equipment.
  • Page 22 For your notes 1-10 Model 340 Telemetry System Revision B 2003720-001...

  • Page 23: Introduction

    ........Revision B Model 340 Telemetry System 2003720-001...

  • Page 24: Product Summary

    A 120 Series Monitor requires a Communications Board in order to interface to a Model 340 Telemetry System. If your monitor does not have this option, an upgrade kit is available as cat. no. (REF) 1559BAO. Contact your...

  • Page 25: Product Features

    Models 115 and 145: cat. no. (REF) 5600 ultrasound transducers cannot be used with a Model 340. Use only cat. no. (REF) 5700 transducers when the using a Model 115 or 145 with a Model 340 Telemetry System.
  • Page 26 For your notes Model 340 Telemetry System Revision B 2003720-001...

  • Page 27: Controls, Indicators, And Connectors

    ....... Model 340T Transmitter ......Revision B Model 340 Telemetry System 2003720-001...

  • Page 28: Model 340R Receiver

    Controls, Indicators, and Connectors: Model 340R Receiver Model 340R Receiver Model 340R Front Panel 340R Telemetry Receiver COROMETRICS TOCO Figure 3-1. Model 340R Receiver Front Panel Model 340 Telemetry System Revision B 2003720-001...
  • Page 29 The green Signal indicator lights continuously when the receiver is accepting radio frequency Signal Indicator signals from the transmitter. The Signal indicator flashes if the signal strength is weak or marginal. Revision B Model 340 Telemetry System 2003720-001...

  • Page 30: Model 340R Rear Panel

    REPLACE FUSE AS MARKED. ANTENNA ULTRASOUND 120V ~ 50-60HZ 30W CONNECT TO COROMETRICS 0.25A SLOW BLOW MONITORS ONLY OUTPUTS TO MONITOR CAUTION Note: Antenna shown removed. Figure 3-2. Model 340R Receiver Rear Panel Model 340 Telemetry System Revision B 2003720-001...
  • Page 31 4-2 for complete interconnection details. Twist-on connector for attaching the Model 340R Antenna Connector Receiver antenna. Binding post terminal directly connected to the Equipotential Lug chassis for use as an equipotentiality connection. Revision B Model 340 Telemetry System 2003720-001...

  • Page 32: Model 340T Transmitter

    Controls, Indicators, and Connectors: Model 340T Transmitter Model 340T Transmitter Model 340T Bottom Panel Figure 3-3. Model 340T Transmitter Bottom Panel Model 340 Telemetry System Revision B 2003720-001...
  • Page 33 Corometrics 5600 Series continuous-wave Ultrasound Input ultrasound transducers are not compatible with the Model 340 Telemetry System. The 5600 Series Transducer was designed for use with Models 115 and 145 Monitors and Models 320 and 330 Telemetry Systems. Connect an FECG cable/legplate or MECG cable plug to this grey receptacle.

  • Page 34: Model 340T Top Panel

    Controls, Indicators, and Connectors: Model 340T Transmitter Model 340T Top Panel Note: Antenna shown removed. Figure 3-4. Model 340T Transmitter Top Panel Model 340 Telemetry System Revision B 2003720-001...
  • Page 35 Connect the headset to this receptacle to listen to Headset Connector the fetal heart rate derived from ultrasound. Connect a Corometrics Remote Event Marker to this receptacle. When the marker’s button is pressed for at least one second, an event mark...

  • Page 36: Model 340T Rear Panel Battery Compartment

    4–5 seconds. This signals approximately 10 minutes of remaining battery power. The chirping continues until the battery power is completely depleted, at which time the Model 340T stops transmitting data. 3-10 Model 340 Telemetry System Revision B 2003720-001...

  • Page 37: Setup Procedures

    Chapter 4 Setup Procedures This section contains step-by-step instructions for connecting and testing your Model 340 Telemetry System. ,03257$17 CHANNEL NUMBERS—Ensure that the Model 340R Receiver and Model 340T Transmitter are operating on the same frequency; the channel numbers must be identical.

  • Page 38: Connecting The Receiver And Monitor

    BP Auto Cancel Volume Volume BP Stop Setup Select Maternal ULTRASOUND ULTRASOUND 2 ECG AND SpO ELECTRICALL ELECTRICALLY ISOLATED REFER TO MANUAL FOR PROPER TRANSDUCERS Note: Model 118 shown. Figure 4-1. Positioning the Receiver Model 340 Telemetry System Revision B 2003720-001...

  • Page 39: Attaching The Receiver Antenna

    Figure 4-2. Attaching the Receiver Antenna 4. Connect the appropriate ultrasound, ECG, and uterine activity interconnect cables to the corresponding , and Ultrasound connectors on the receiver rear panel. Figure 4-3. Attaching the Receiver Interconnect Cables Revision B Model 340 Telemetry System 2003720-001...

  • Page 40: Attaching The Monitor Interconnect Cables

    Remote Marks Note: Model 118 shown. Figure 4-5. Attaching the Remote Mark Interconnect Cable Model 340 Telemetry System Revision B 2003720-001...

  • Page 41: 120 And 170 Series

    120 SERIES COMMUNICATIONS OPTION—A 120 Series Monitor requires a Communications Board in order to interface to a Model 340 Telemetry System. If your monitor does not have this option, an upgrade kit is available as cat. no. (REF) 1559BAO. Contact your Service Representative for more information.

  • Page 42: Attaching The Monitor Interconnect Cable To A 120 Series Monitor

    4. Plug one end of the interconnection cable into the Auxiliary Output connector ( ) on the receiver rear Connect to Corometrics Monitor Only panel. 5. Plug the other end into the respective telemetry connector on the real panel of the monitor:...

  • Page 43: Setting Up The Model 340T Transmitter

    3. Remove the cover plate. Use your thumb to lift the raised end. Battery Compartment Lift Here Figure 4-9. Accessing the Batteries 4. Remove the depleted batteries. &$87,21 BATTERY DISPOSAL—Follow the battery manufacturer’s recommendations or your hospital policy for the disposal of used batteries. Revision B Model 340 Telemetry System 2003720-001...

  • Page 44: Transmitter Battery Orientation

    6. Replace the battery compartment cover plate. Insert the lip of the cover in the lower portion of the compartment opening; swing the other end of the cover down and snap into place. Model 340 Telemetry System Revision B 2003720-001...

  • Page 45: Attaching The Antenna

    Figure 4-11. Attaching the Transmitter Antenna Attaching the Carrying Strap Secure the metal clips at each end of the carrying strap to the belt attachment loops on each side of the transmitter. Figure 4-12. Attaching the Carrying Strap Revision B Model 340 Telemetry System 2003720-001...

  • Page 46: Performing A Functional Checkout

    Model 340R Battery Receiver: Off: the transmitter batteries have power. Flashing Red: the transmitter batteries are low and should be replaced before further patient use. Continuous Red: the transmitter batteries are depleted. 4-10 Model 340 Telemetry System Revision B 2003720-001...

  • Page 47: Testing The Ultrasound Functions

    Setup Procedures: Performing a Functional Checkout Testing the Ultrasound Functions ,03257$17 TRANSDUCER TYPE—Use only Corometrics 5700 Series Ultrasound Transducers with the Model 340 Telemetry System. 1. Plug an ultrasound transducer into the connector on the Ultrasound transmitter. Figure 4-14. Connecting an Ultrasound Transducer 2.
  • Page 48 4. Plug the headset into the transmitter’s headset connector Figure 4-15. Connecting the Headset 5. Rub the face of the ultrasound transducer. Verify that you can hear ultrasound audio tones from both sides of the headset. 4-12 Model 340 Telemetry System Revision B 2003720-001...

  • Page 49: Testing The Ecg Functions

    FHR value reads 120 BPM; the corresponding FHR heartbeat indicator flashes at a rate of 120 times per minute; and the ECG “beep” is heard from the speaker. Figure 4-16. Connecting an FECG Cable/Legplate Revision B Model 340 Telemetry System 4-13 2003720-001...

  • Page 50: Testing The Ua Functions

    Figure 4-17. Connecting a Tocotransducer or IUPC Cable ,03257$17 DEFAULT REFERENCE VALUE—Most monitors have a default UA reference of 10 relative units. Take into consideration that newer model monitor’s can be configured to store a custom default value. 4-14 Model 340 Telemetry System Revision B 2003720-001...
  • Page 51 127( Place the switch back in the position UA Mode Selector TOCO unless you plan to monitor with an IUPC. Revision B Model 340 Telemetry System 4-15 2003720-001...

  • Page 52: Testing The Remote Event Marker Function

    Verify that an appropriate mark is printed on the paper: : This annotation is commonly used to record an “event.” This mark is available on all Corometrics-brand monitors. : This annotation is commonly used as an indication that the mother has perceived fetal movement. (Refer to your monitor’s operator’s manual to learn if your monitor supports this feature.

  • Page 53: Monitoring Via Telemetry

    Monitoring....Monitoring Reminders ......Revision B Model 340 Telemetry System 2003720-001...

  • Page 54: Suggestions For Ambulatory Monitoring

    5. Make sure the transducer cables are not dragging on the floor. If the cables are available. Contact your patient is in danger of tripping over the cables, drape them over the Information Technologies Sales patient’s arm; or shorten the length by taping a loop. Representative. Model 340 Telemetry System Revision B 2003720-001...

  • Page 55: Monitoring Reminders

    Monitor, disconnect all transducers from the front panel of the monitor. Ultrasound Use only Corometrics 5700 Series ultrasound transducers with a Model 340 Telemetry System. Remind the patient to use the headset to check for continual pickup of the fetal heart rate signal following each fetal movement.

  • Page 56: Tocotransducer

    Remember to place the receiver’s switch in the UA Mode Selector position. TOCO When connecting or re-connecting a Corometrics Trimline Tocotransducer to the transmitter’s connector, you must wait at least 10 seconds before pressing the monitor’s button. If UA Reference any device (monitor, receiver, transmitter is off), you must wait at least ten seconds from the time the last device is powered on.

  • Page 57: Maintenance

    All equipment, no matter how reliable, needs to be maintained on a regular basis. This section describes general care and cleaning instructions for the Model 340 Telemetry System. General Cleaning Precautions......

  • Page 58: General Cleaning Precautions

    Model 340R Receiver from the AC power source and transducers. detach all accessories. Do not immerse accessories in any liquid. Do not use abrasive cloth or cleaners on the monitor, the Model 340R Receiver, the Model 340T Transmitter, or any accessories. Model 340 Telemetry System Revision B 2003720-001...

  • Page 59: Cleaning The Transmitter And Receiver

    Cleaning the Transmitter and Receiver 1. Wipe any fluids from the surface of each unit. 2. Dampen a soft cloth with isopropyl alcohol and gently rub soiled area until clean. 3. Dry with a soft, dry cloth. Revision B Model 340 Telemetry System 2003720-001...
  • Page 60 For your notes Model 340 Telemetry System Revision B 2003720-001...

  • Page 61: Troubleshooting

    Chapter 7 Troubleshooting This section of the manual provides a troubleshooting guide for the most basic Model 340 operational problems. If the response to a specific question is not found, contact the Service Department at one of the following telephone numbers: Call 1-800-558-5120.

  • Page 62: Problem Chart

    Low Battery Replace the batteries. Dispose of used continuously with no Transmitter batteries are depleted. batteries according to the manufacturer’s – transducers plugged into instructions. transmitter. Model 340 Telemetry System Revision B 2003720-001...
  • Page 63 Wrong interconnection cable(s) in use. Verify interconnection method. Replace the batteries. Dispose of used Transmitter batteries have less than 10 Transmitter “chirps” every 4–5 seconds. batteries according to the manufacturer’s minutes of energy left. instructions. Revision B Model 340 Telemetry System 2003720-001...
  • Page 64 For your notes Model 340 Telemetry System Revision B 2003720-001...

  • Page 65: Supplies And Accessories

    Supplies and Accessories This section provides an overall listing of supplies and accessories for use with a Corometrics Model 340 Telemetry System and with Corometrics Fetal or Maternal/Fetal Monitors. To order any of the supplies and accessories listed in this manual: Call 1-800-558-5120.

  • Page 66: General

    Detachable IEC AC Power Cord, United States Plug 1392AAA Remote Event Marker, 8-foot Cord 3919BAO Remote Event Marker, 5-foot Cord 3919CAO Headset for Model 340 Telemetry System 3316AAO Ultrasound Interconnect Cable (Models 115, 145 only) 1399AAO Ultrasound Interconnect Cable (Models 116, 118, 150, 151, 155 only) 1399BAO...

  • Page 67: Paper

    Table 8-2. Paper Supplies Item Catalog Number (REF) Z-Fold Chart Paper Pack, 30–240 BPM Heart Rate Scale (40/carton) 4305CAO Z-Fold Chart Paper Pack, 50–210 BPM Heart Rate Scale (40/carton) 4305DAO Chart Guard Label Packet 4914BAO Revision B Model 340 Telemetry System 2003720-001...

  • Page 68: Ultrasound

    Foam Style with Velcro Closure ,03257$17 TRANSDUCER TYPE—Use only Corometrics 5700 Series Ultrasound Transducers. Do not use a Corometrics 5600 Series Transducer. The 5600 Series Transducers are only for direct connection to a Model 115 or Model 145 Fetal Monitor or for use with a Model 320 or Model 330 Telemetry System.

  • Page 69: Fecg

    Button-Style Legplate for Qwik Connect Plus Spiral Electrode, 8-foot Cord 1590CAO Strap Adaptor for Qwik Connect Plus Spiral Electrode Legplates 1594AAO ECG Conductive Cream Bottle, 118 ml (12/carton) 4514AAO Reusable Legplate Strap with Velcro Closure (24/carton) 2023AAO Single-Patient Use Legplate Strap 8036AAO Revision B Model 340 Telemetry System 2003720-001...

  • Page 70: Tocotransducer

    4425CAO Reusable Belt for Button-Style Transducer, Elastic Style (10/carton) 4425EAO Semi-Reusable Belt for Loop-Style Transducer, Velcro Style 4425FAO (2/pack; 50 packs/carton) Single-Patient Use Belt for Loop-Style Transducer, 8024AAO Foam Style with Velcro Closure Model 340 Telemetry System Revision B 2003720-001...

  • Page 71: Iupc

    Supplies and Accessories: IUPC IUPC Table 8-6. IUPC Supplies Item Catalog Number (REF) Corometrics Softrans IUPC with Amnio Infusion/Sampling 2076AAO Capabilities (10/carton) Corometrics Softrans Intermediate Cable 1336AAO Reusable Strain Gauge Pressure Transducer, 10-foot Cord 4007BAX (with Holder) Reusable Strain Gauge Pressure Transducer, 10-foot Cord...

  • Page 72: Mecg

    Multi-Link Grabber Leadwires, Set of 3, Grouped Detachable, 31 inches 412682-001 Multi-Link Grabber Leadwires, Set of 5, Individually Detachable, 31 inches 414556-001 Leadwire Adapter, 3-Lead Multi-Link to 3-Lead DIN 414371-001 Electrodes, Round, Foam, Pouches of 30, Case of 300 9431-004 Model 340 Telemetry System Revision B 2003720-001...

  • Page 73: Technical Specifications

    127( Specifications are subject This section contains a detailed list of the technical specifications for the to change without notice. Model 340 Telemetry System. This chapter lists specifications for the following: Model 340T Transmitter ......9-2 Model 340R Receiver .

  • Page 74: Model 340T Transmitter

    –50 to +250 mmHg RF Section Output Power: 10 mW Available Frequencies: 430–470 MHz Channel Bandwidth: 25 kHz Transmission Range: 1640 ft (500 m), line of sight Antenna Type: Flexible, detachable, BNC interconnect Model 340 Telemetry System Revision B 2003720-001...
  • Page 75 Four “AA” Alkaline Cells, 6.0 Vdc at 2450 mAh Life: 20 h, approximately Control: On/Off Switch Audio Indicator: Low Battery Connectors: Remote Event Marker Input, Headset Output Use of the headset will deplete the batteries more rapidly Revision B Model 340 Telemetry System 2003720-001...

  • Page 76: Model 340R Receiver

    Use only with Models 115, 116, 118, 145, 150, 151, and 155 Monitors. UA Output: Use only with Models 115, 116, 118, 145, 150, 151, and 155 Monitors. Auxiliary Output: Use only with Series 120 and 170 Monitors. Model 340 Telemetry System Revision B 2003720-001...
  • Page 78 MANUAL P/N 2003720-001 Ê2003720-001kŠ...
