RD WORKS FP405R-QA Owner's Manual

Electric fireplace insert with heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Electric Fireplace Insert with Heater
OWNER'S MANUAL
Model No. FP405R-QA
PLEASE SAVE THESE INSTRUCTIONS
WARNING: READ THIS OWNER'S MANUAL CAREFULLY BEFORE USE.
PET OWNERS WARNING:
The health of some small pets including birds are extremely sensitive to the
fumes produced during the first-time use of many appliances. These fumes are
not harmful to humans but we recommended that you do not use your heater
around birds and small pets during its initial use until the manufacturing
corrosion coatings burn off.
Customer Service: 1-888-538-008
Service Email:
service@hena.ca

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FP405R-QA and is the answer not in the manual?

Questions and answers

Summary of Contents for RD WORKS FP405R-QA

  • Page 1 Electric Fireplace Insert with Heater OWNER’S MANUAL Model No. FP405R-QA PLEASE SAVE THESE INSTRUCTIONS WARNING: READ THIS OWNER’S MANUAL CAREFULLY BEFORE USE. PET OWNERS WARNING: The health of some small pets including birds are extremely sensitive to the fumes produced during the first-time use of many appliances. These fumes are...

  • Page 2: Important Instructions

    Thank you for choosing our Electric Fireplace. This owner’s manual will provide you with valuable information necessary for the proper care and maintenance of your new product. Please take a few moments to thoroughly read the instructions and familiarize yourself with all the operational aspects of your new heater. IMPORTANT INSTRUCTIONS When using this electric unit, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following:...

  • Page 3: Specifications

    12. A heater has hot and arcing or sparking parts inside. DO NOT use in areas where gasoline, paint, explosive and/or flammable liquids are used or stored. Keep unit away from heated surfaces and open flames. 13. Always plug heaters directly into a wall outlet receptacle. Never use with an extension cord or relocatable power tap (outlet/power strip).

  • Page 4: Safety Features

    SAFETY FEATURES Overheat Safety Feature This heater is equipped with a overheat safety feature. When the heaters internal components reach a certain temperature that could cause overheat and possible fire, the heater will automatically shut off. WARNING: It is normal for the power cord to feel warm to the touch; however, a loose fit between the outlet and the plug may cause overheating of the plug.
  • Page 5 1、Power indication light: After electrifying show red, press the power button to display the red light and flame open. 2、Power button: Powers the display on and off. 3、Signal-receiving window: For receiving remote control signal. 4、Low range mode lights: Low range mode indicator lights up for low-grade heat. 5、Heater button: Set up the heater mode and turn off the heat.

  • Page 6: Operating Your Heater

    Remote Control Power button: Powers the display on and off. Flame light button: Adjust the brightness of the flame Heater button: Set up the heater mode and turn off Timer button: User setting timing ℃/℉Button (Button for alternating between Fahrenheit and Celsius) the heat Down button：For setting temperature or time downward Up button: For setting temperature or time upward...
  • Page 7 Turn the heater on by pressing the ON/OFF button on the control panel or by pressing the Power button on the supplied remote control. Once power is off, heating element will stop working at first. Fan will prolong working for 3min to emit plenty of Or POWER heat inside.
  • Page 8 Adjust the brightness of the flame and turn off 4. Setting timer-power- off Caution! ONLY under power-on mode you can set timer-power-off function. When starting the unit, press the timer button on the control panel. Adjust the time by pressing the arrows on the control panel or remote control.

  • Page 9: Troubleshooting

    Press Temp Up and Temp Down buttons once for 3 seconds. Locking is fulfilled when a buzzer rings. When locked, control panel and remote control failed to function. When release is needed, please re-press Temp Up and Temp Down buttons once for 3 seconds. Release is fulfilled when a buzzer rings.

  • Page 10: Warranty Information

    WARRANTY INFORMATION This product carries a one (1) year warranty against defects in workmanship and materials. Hometech agrees to replace a defective product, within the stated warranty period, when returned to the place of purchase with proof of purchase. This product is not guaranteed against wear or breakage due to misuse and/or abuse.
