SN50 & SN40 Series
Pneumatic Stapler
OPERATIONS and MAINTENANCE MANUAL
BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD READ AND STUDY
THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND
INSTRUCTIONS. KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE
REFERENCE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SN50 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for corgrap SN50 Series

  • Page 1 SN50 & SN40 Series Pneumatic Stapler OPERATIONS and MAINTENANCE MANUAL BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD READ AND STUDY THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS. KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE REFERENCE.
  • Page 2: Table Of Contents

    SN50 & SN40 Series Pneumatic Stapler INTRODUCTION The tool is designed for high speed, high volume nailing. These tools will deliver efficient, dependable service when used correctly and with care. As with any fine power tool, the manufacturer’s instructions must be followed for best performance. Please study this manual before operating the tool and understand the safety warnings and cautions.
  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS TO AVOID SEVERE PERSONAL INJURY OR PROPERTY DAMAGE TO AVOID SEVERE PERSONAL INJURY OR PROPERTY DAMAGE BEFORE OPERATING THIS BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD READ AND STUDY THIS MANUAL TOOL, ALL OPERATORS SHOULD READ AND STUDY THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS.
  • Page 4: Specifications And Technical Data

    SPECIFICATIONS AND TECHNICAL DATA SPECIFICATIONS SN50S5 SN40P/ SN40P-R SN50S4 SN40S2/ SN40S2-R MODEL SN50S5LM SN50S53LM SN50GSI SN40GSW/ SN40GSW-R HEIGHT- in (mm) 10.7" (272) 10.7" (272) 10.7" (272) 9.9” (251) WIDTH- in (mm) 3.7" (94) 3.7" (94) 3.7" (94) 3.7" (94) LENGTH- in (mm) 14.3"...
  • Page 5: Operation

    OPERATION Refer to Operation Instructions Instructions and warnings on pages before proceeding proceeding to use this tool. FOUR TYPES TYPES OF OPERATION FOR THIS SERIES TOOL. OOL. CONTACT TRIP – IDENTIFIED BY BLACK IDENTIFIED BY BLACK TRIGGER The common operating procedure procedure on “Contact Trip”...
  • Page 6: Air Supply And Connections: Fittings, Hoses, Filters, Air Consumption, Regulators, Supply Source

    AIR SUPPLY AND CONNECTIONS DO NOT USE OXYGEN, COMBUSTIBLE GASES, OR BOTTLED GASES AS A POWER SOURCE FOR THIS TOOL AS TOOL MAY EXPLODE, POSSIBLY CAUSING INJURY. FITTINGS: Install a male plug on the tool which is free flowing and which will release air pressure from the tool when disconnected from the supply source.
  • Page 7: Fastener Loading

    FASTENER LOADING EYE PROTECTION PROTECTION which conforms to ANSI/ CE specifications specifications and provides protection against flying particles both from the FRONT FRONT and SIDE should ALWAYS be be worn by the operator and others in the work work area when connecting to air suppl supply, loading, operating or servicing this tool.
  • Page 8: Depth Of Drive Adjustment

    “DEPTH OF DRIVE ADJUSTMENT DEPTH OF DRIVE ADJUSTMENT” ” The “DEPTH OF DRIVE ADJUSTMENT DEPTH OF DRIVE ADJUSTMENT” feature provides close control of the fastener drive d feature provides close control of the fastener drive depth; from flush with the work surface to shallow or deep countersink. First, set the air pressure for consistent flush with the work surface to shallow or deep countersink.
  • Page 9: Tool Operation Check

    OPERATION 1. CONTACT TRIP OPERATION: The CONTACT TRIP MODEL tool contains a contact trip that operates in conjunction with the trigger to drive a fastener. There are two methods of operation to drive fasteners with a contact trip tool. SINGLE FASTENER PLACEMENT: To operate the tool in this manner, first position the contact trip on the work surface, WITHOUT PULLING THE TRIGGER.
  • Page 10 d. Without touching the trigger, press the contact trip against the work surface, then pull the trigger. THE TOOL MUST CYCLE. 2. SEQUENTIAL TRIP OPERATION: a. Press the contact trip against the work surface, without touching the trigger. THE TOOL MUST NOT CYCLE. b.
  • Page 11: Maintaining The Pneumatic Tool

    MAINTAINING THE PNEUMATIC TOOL When working on air tools, note the warnings in this manual and use extra care evaluating problem tools. Disconnect air supply and empty the magazine when inspecting or maintaining the tool. REPLACEMENT PARTS: Use only genuine parts from the manufacturer or distributor. Do not use modified parts or parts which will not give equivalent performance to the original equipment.
  • Page 12: Troubleshooting/Repairs

    TROUBLESHOOTING/REPAIRS The troubleshooting and/or repairs shall be carried out only by the authorized dealer/distributor or by other pneumatic tool specialists. DIRECTIONAL EXHAUST DEFLECTOR Loosen screw as shown. Adjust to desired exhaust direction and tighten screw. QUICK JAM-RELEASING MAGAZINE The stapler contains a “Quick Jam-Releasing Magazine” feature. The magazine is spring loaded to reduce jamming.
