UTS iSandBOX Standard Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Tel. +7-3822-901439
E-mail: world@ar-sandbox.com
www.ar-sandbox.com
Installation Manual
for iSandBOX hardware and software
system
Tomsk, Russia
2019
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iSandBOX Standard and is the answer not in the manual?

Questions and answers

Summary of Contents for UTS iSandBOX Standard

  • Page 1 Tel. +7-3822-901439 E-mail: world@ar-sandbox.com www.ar-sandbox.com Installation Manual for iSandBOX hardware and software system Tomsk, Russia 2019...
  • Page 2 Safety Rules To avoid incidents, it is PROHIBITED to: ● perform any maintenance operations while the plug is in the socket; ● use DYI or non-standard parts; ● cover ventilation slots; ● operate the device under high humidity conditions; ● operate the device under heavy dust concentration; ●...

  • Page 3: Table Of Contents

    Index Preparation ............................... 4 1.2. Set of tools and metalware for product assembly ..................5 1.3 iSandBOX Standard / Mini Supply Package .................... 6 Assembly ..............................9 2.1. Frame assembly ............................9 2.2. Installing the legs and column support ....................11 2.3.

  • Page 4: Preparation

    1. Preparation Before starting the assembly and setting up your iSandBOX, check if the shipment package and the provided set of tools and metalware are in place. Also check for defects (cracks, chips, sharp metal edges). Before assembling Standard and Mini versions, make sure you chose the right spot for your interactive sandbox.

  • Page 5: Set Of Tools And Metalware For Product Assembly

    1.2. Set of tools and metalware for product assembly № Description Quantity (ea.) For iSandBOX For iSandBOX Standard Mini 10 wrench 13 wrench Philips screwdriver М8х20 screw М6х65 screw М6х60 screw М6х40 screw М6х16 screw Flat screw М4х10 Cup head screw М4х10 М6 nut 6 fender washer 8 washer...

  • Page 6: Isandbox Standard / Mini Supply Package

    1.3 iSandBOX Standard / Mini Supply Package № Description Image Projector casing Laminated chipboard panel (central, with B2 mark) Laminated chipboard panel (side, with B1 and B3 mark) Column support Sandbox column with a casing for PC base unit...
  • Page 7 Sand container support legs with or without wheels Side walls of the sand container Sand container lining Spreader bar Crossbar Underframe...
  • Page 8 Lower column housing Acoustic system Power cable Box with tools and metalware...

  • Page 9: Assembly

    2. Assembly 2.1. Frame assembly Metalware Image Quantity (ea.) М6х40 screw М6 washer М6 nut Table A. Metalware used for frame assembly To assemble the frame, you will need: Spreader bar (А) – 2 ea.; crossbar – 2 ea. and underframe. Fixing points are indicated in arrows of the same color in pairs.
  • Page 10 Figure 1. Secure the crossbeams to the spreader bar using М6х40 screws (8 ea.), М6 washers (16 ea.), M6 nuts (8 ea.) and a 10 wrench (Figure 2). !Attention! Screw hats must be pointing down. Figure 2. Crossbeams must be installed correctly. The holes must be positioned on the corners of the structure and should not be covered by the plates.

  • Page 11: Installing The Legs And Column Support

    !Attention! Screw hats must be pointing down. Figure 3. 2.2. Installing the legs and column support Metalware Image Quantity (ea.) М8х20 screw М6х65 screw М8 washer...
  • Page 12 М6 washer М6 nut Table B. Metalware used for installing legs and support column Secure the legs on the plates using М8х20 screws (16 ea.), М8 washers (16 ea.) and a 13 wrench. Fixing points are shown on Figure 4. The correct position of the legs is shown with the arrows of the same color (stickers are located on the leg and the plate).

  • Page 13: Installing The Speakers

    Figure 5. Secure the column support using М6х65 screws (4 ea.), М6 washers (8 ea.), M6 nuts and a 10 wrench. Fixing points are shown on Figure 6. The support should be located on the side of frame A. The fixing is shown on Figure 6 (B). Figure 6.
  • Page 14 Metalware Image Quantity (ea.) Flat screw М4х10 Table C. Metalware used for speakers installation Speakers are supplied with mounting brackets (Figure 7). The upper bracket is furnished with threaded fixtures. There is no need to disassemble them. Figure 7. Place the speaker (with a threaded fixture) onto the frame. The plastic parts of the frame have threaded fixtures.

  • Page 15: Assembling And Installing The Sand Reservoir

    2.4. Assembling and installing the sand reservoir Metalware Image Number for Number for iSandBOX iSandBOX Standard Mini (ea.) (ea.) М6х16 screw М6х60 screw М6 washer М6 nut Plastic cap Table D. Metalware used for the sand reservoir installation Place the laminated chipboard panels on the assembled frame, following the numbers shown in Figure 9.
  • Page 16 Mount and secure the sand reservoir on the laminated chipboard panels (Figure 11). Figure 11. Install the sand reservoir for the iSandBOX Standard using М6х60 screws (16 ea.), М6 washers (32 ea.) and М6 nuts using a 10 wrench. After that, cover thread ends with plastic caps (16 ea.) (Figure 12).

  • Page 17: Column Installation

    Install the sand reservoir for the iSandBOX Mini version using М6х60 (14 ea.), М6 washers (28 ea.) and nuts (14 ea.) using a 10 wrench. Then close thread ends with plastiс caps (14 ea.) (Figure 13). Figure 13. 2.5. Column installation Metalware Image Quantity (ea.)
  • Page 18 Place the column on the frame, inserting the mounting hooks into the bearer holes (Figure 14). Figure 14. Connect the column to the support and the container using М6х16 screws (8 ea.), М6 washers (8 ea.) and a 10 wrench (Figure 15). Figure 15.
  • Page 19 Put the sound wire and power cable of the audio system subwoofer through the hole at the column base inside the column. Connect these wires to the slots on the motherboard of the base unit and to the power filter (Figure 16). Figure 16.

  • Page 20: Installing The Projector Casing And Connecting The Cables

    2.6. Installing the projector casing and connecting the cables Metalware Image Quantity (ea.) М6х16 screw М6 washer Plastic cap Table F. Metalware used for projector casing installation Install the projector casing to the fixture plate. Put the cable set inside the casing and secure it with М6х16 screws (6 ea.), М6 washers (6 ea.) and a 10 wrench (Figure 18).
  • Page 21 Open the projector head casing door (Figure 19). Figure 19. Connect the cable set to the matching projector jacks (Figure 20). Figure 20. Connect power cable and USB cable to Kinect sensor (Figure 21). Figure 21.
  • Page 22 Close the projector casing door. !Attention! In the new assembly versions, Kinect is located inside the column. To get access to Kinect, remove the column cover. For this purpose, unscrew М4х10 cup head (12 ea.). Figure 22. Connect the cables to corresponding connectors in the sandbox column (Figure 23). Figure 23.

  • Page 23: Placing The Sand Reservoir Lining

    2.7. Placing the sand reservoir lining Metalware Image Quantity (ea.) М4х10 cup head screw Table G. Metalware used for installing the sand container lining Flatten the lining sheet and place it inside the container. Place the short side of the sheet to the short part of the container, and the long side to the long part.
