Installation and REMOVAL INSTRUCTIONS
•
Before installing or handling this product, read instruc+ons carefully and completely. Due to possible danger to
persons or machinery resul+ng from improper use of this product, it is very important to follow correct
procedures. Proper installa+on, maintenance and opera+on procedures must be observed. All instruc+ons
included in this manual must be followed carefully. Handling, installa+on and removal of this product must be
done by skilled personnel, familiar with the product, the applica+on and all hazards involved.
•
Suitable safety devices should be provided and applicable safety rules should be observed as specified in safety
codes. Those are neither the responsibility of MAV S.p.A., nor are provided by MAV S.p.A.
•
Contraven+on of install and safety instruc+ons will void all claims under warranty.
•
During storage or handling opera+ons, use only tested and approved handling and/or li4ing tools. Make always
sure that components of Locking Assembly are secured against slipping, falling or rolling.
•
Prior to ini+a+ng installa+on or removal procedures, check to ensure that no loads are ac+ng on Locking
Assembly, sha4 or any connected component. Motor and drive train must be switched off and secured against
accidental ac+va+on.
•
Locking Assemblies MAV 1008 provide a rigid, zero-backlash, fric#onal keyless connec#on between a sha' and hubs
such as gears, pulleys, cams, levers, rotors and many others.
They are suited for transmi*ng torque, axial load, bending moment and radial load, separately or in combina#on.
Applied loads are transmi-ed via pressure and fric#on across the fi*ng surfaces between Locking Assembly, sha'
and hub bore.
In #ghtened condi#on, Locking Assemblies exert high radial pressure on sha' and in hub bore.
•
Locking Assemblies MAV 1008 are supplied ready for installa#on and are composed of (fig. 1):
◦
one front thrust ring (w/ complete slit up to size 180x235, w/ staggered slit from size 190x250)
◦
one rear thrust ring (w/ complete slit up to size 180x235, w/ staggered slit from size 190x250)
◦
one outer ring (w/ complete slit up to size 380x475, w/out slit from size 400x495)
◦
one set of socket head cap screws ISO 4762 grade 12.9
Locking Assembly MAV 1008
GENERAL RECOMMENDATIONS and WARNINGS
GENERAL INFORMATION
Rev. 3/2020
Page 1 of 5
Advertisement
Table of Contents
Related Manuals for MAV 1008
Summary of Contents for MAV 1008
- Page 1 GENERAL INFORMATION • Locking Assemblies MAV 1008 provide a rigid, zero-backlash, fric#onal keyless connec#on between a sha' and hubs such as gears, pulleys, cams, levers, rotors and many others. They are suited for transmi*ng torque, axial load, bending moment and radial load, separately or in combina#on.
- Page 2 Fig. 1. Composi#on. • Lubrica#on. Func#onal values are rated with screws, locking rings, sha4 and hub contact areas coated with a film of mineral or synthe+c-base oil with low content of addi#ves (specific corrosion-protec#on purpose products as well as products used to release oxidized connec#ons are not recommended). DON'T USE low fric+on lubricants based on molybdenum disulphide, graphite, copper and other similar compounds (e.g., Molykote®, Never-Seeze®...
- Page 3 Motor and drive train must be switched off and secured against accidental ac+va+on. Locking Assemblies MAV 1008 are supplied ready for installa#on. Should the unit be disassembled and re-assembled, make sure that the outer ring is not reversed and the slits in all rings are aligned.
- Page 4 Tighten the screws by hand in a crosswise pa-ern, star#ng with a screw located at 90° approx. respect to slit in the front thrust ring (fig. 3), un#l fi*ng clearances with sha' and hub bore are bridged and connected components are slightly locked, while making sure that hub is aligned as required using a dial indicator.
- Page 5 REMOVAL SAFETY NOTICE Prior to ini+a+ng the removal procedure, check to ensure that no loads are ac+ng on Locking Assembly, sha4 or any connected component. Motor and drive train must be switched off and secured against accidental ac+va+on. Some locking screws will be used for removal. The user shall make sure that the end +p of these screws is ground flat and chamfered, in order to prevent damage to the threads and allow their removal from push-off...
