NewHank DU 22
Thank you for buying NewHank DU 22, this guide will take
you know how to use this product.
1. Product Introduction
This product is applied to the audio system field to realize
the USB signal and Dante network audio signal conversion
function.
2. Product Feature
1. Function Introduction: Support USB signal and Dante
network audio signal conversion
2. Input & Output:2 channel
3. Technical Parameters
Model No.
Product Type
Function
RJ45 Port
Connection
Power supply
Sampling rate
Network transmission
USB
Operating temperature
Size (LxWxH)
Weight
NewHank DU 22
Audio signal adapter
The USB signal and Dante network
audio signal conversion
1
RJ45 and USB A type
USB
48kHz
Dante IP AES67 RTP audio
Specification level USB 2.0 devices
0-40℃
652mm x 32mm x 22mm
0.2kg
4. Product Overview
5. Product Connect
Follow the below steps to set up a Dante network for
controlling.
1. Download and install the Dante Controller from
Audinate website (www.audinate.com).
2. Connect the device to the switch using Dante network
audio system with network cable
3. The analog audio transmission device is connected
through the XLR interface
4. Search for devices in Dante Controller software, Select
and open the devices to be configured，On the Routing
page, match the input row with the output column with
a custom check.
Once set up and configured the audio routing between
5.
audio device, the audio device will remember and save
the settings.
