- Page 1 DC-DC POWER CONVERTER MODULE MP 24/12V User’s Manual...
-
Page 2: Table Of Contents
Table of Contents 1 Description and Operation ........................4 1.1 Purpose ............................4 1.2 Specifications ..........................4 1.3 Standard Delivery .......................... 5 1.4 Measuring Instruments, Tools, and Accessories ................5 1.5 Marking and Sealing ........................5 1.6 Packaging ............................5 2 Intended Use ............................ -
Page 3: Description And Operation
Description and Operation Purpose 1.1.1 MP 24/12V DC-DC Power Converter Module (hereinafter referred to as the MP) is designed to supply power to equipment of fire and intrusion alarm systems that require 12 V dc. 1.1.2 MP is intended for round-the-clock operation with specified output parameters when cooperating with RIP-24 battery backed power supplies. -
Page 4: Standard Delivery
Standard Delivery The standard delivery for MP is shown in Table 2. Table 2 Item Quantity, pcs MP 24/12V DC-DC Power Converter Module MP 24/12V Operations Manual Fasteners (woodscrew and wall plug) Package Measuring Instruments, Tools, and Accessories While mounting, commissioning, and maintaining the product, please use the instruments, tools, and accessories shown in Table 3. -
Page 5: Operating The Mp
2.2.3 Mounting 2.2.3.1 Installation, mounting, and maintenance shall not be carried out until the equipment is disconnected from power. Installation and maintenance shall be carried out by professionals qualified for Accident Prevention of Class II or higher. 2.2.3.2 Installation and Preparing for Use Install the module at a place convenient for arranging power lines (on walls or other structures at places protected against atmospheric precipitations and mechanical damage). -
Page 6: Maintenance Procedures
4.4. Claims shall be submitted to the following address: NVP BOLID, #4 Pionerskaya Str., Korolyov, Moscow Region, 141070, Russia Phone/fax: +7 (495) 775-71-55 (PBX) E-mail: info@bolid.ru. 4.5. In case of any issue related to use of the product, please contact the technical support: +7 (495) 775-71-55 or e-mail support@bolid.ru. -
Page 7: Transporting
No. МВД РФ.03.000972. 9.4. Production of MP 24/12V is awarded with the conformity certificate GOST R ISO 9001. The certificate can be found at the website in the section ABOUT COMPANY. - Page 8 Appendix A Overall and Mounting Dimensions of MP...
- Page 9 Appendix B Layout of Connection and Indication Elements...
