IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY
Tools Needed
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to
be faulty. Should you need to return the unassembled product, please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of two persons is required to assemble this product.
PRODUCT INFORMATION
• Made from MDF,hollow board & Honeycomb board with a pvc foil & a wood effect finish foil.
• Made in China.
CARE INSTRUCTIONS
•Gloss finishes are prone to light surface scratch and it is therefore very imporant that
you care for this item correctly.
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Do not use furniture polish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent scratching
or damage.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.
FITTINGS
MILANO WHITE GLOSS S DESK
ASSEMBLY INSTRUCTIONS
Page 1 of 10

Advertisement

loading
Need help?

Need help?

Do you have a question about the MILANO WHITE GLOSS S DESK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Next MILANO WHITE GLOSS S DESK

  • Page 1 MILANO WHITE GLOSS S DESK ASSEMBLY INSTRUCTIONS IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 PARTS STEP ONE Please note: Remove the protective film after assembly of this product unless it is stated in the steps to do so - this will prevent accidental scratches during assembly 1.Insert 8 x cambolts (E) into panels 4, 5 & 6 and tighten with a screwdriver.
  • Page 3 STEP THREE 1. Glue and insert 1 x wooden dowel (A) into panel 5. 2. Please remove the protective film from the surfaces of 9 & 2. 3. Attach panel 9 to panel 5 . 4. Insert 2 x camlocks (D) into panel 9. Ensure the arrow indicators are pointing towards the panel edges before tightening with a screwdriver.
  • Page 4 STEP SIX 1. Please remove the protective film from the surface of panel 1. Please note: There is a choice of Walnut effect or white gloss for the back panel 1 . The colour you prefer needs to face the panels 7,6,2 & 5 when attaching. 2.Attach panel 1 to panels 7, 6 , 2 &...
  • Page 5 STEP NINE 1.Use 8 x stickers (F) to cover the holes on panels 7, 9 , 10 & 11. 2.Use 2 x stickers (G) to cover the holes on panel 3. STEP TEN 1.Please check the height of metal bracket (O) - from the ground 1596 mm- to determine the height of hole on the wall 2.
  • Page 6 (O) with 1 × screw (J) with a screwdriver to tighten 3.This product must be fitted to the wall to prevent damage to the product during use. Periodically check that no fittings have loosened. Next Retail Ltd, Desford Road, Leicester, LE19 4AT Page 6 of 10...
  • Page 7 Page 7 of 10...
  • Page 8 Page 8 of 10...
  • Page 9 Page 9 of 10...
  • Page 10 Page 10 of 10...
