Vollrath VCBA118-37 Operator's Manual

Thank you for purchasing this Vollrath® unit. Before use, read
and familiarize yourself with the following operating and safety
instructions and save them for future reference. Also save the
original box and packaging for shipping if repairs are needed.
SAFETY PRECAUTIONS
To ensure safe operation, carefully read and understand the
following statements. This manual contains safety precautions
which are explained below.
WARNING
Warning indicates the presence of a hazard that will or can
cause severe personal injury or death.
CAUTION
Caution indicates the presence of a hazard that will or can cause
minor or major personal injury if the caution is ignored.
NOTICE: Notice is used to note information that is important
but not hazard-related.
To reduce risk of injury or damage to the equipment
• Plug only into grounded electrical outlets that match the
voltage on the rating label.
• Do not use extension cords to connect the this equipment.
• Use this equipment in a flat, level position.
• Unplug equipment before cleaning or moving.
• Unplug equipment when not in use.
• Keep equipment and power cord away from open flames,
electric burners or excessive heat.
• Do not operate unattended.
• Closely supervise equipment operating in public areas and/or
around children.
• Do not operate if equipment has been damaged or is
malfunctioning.
• Use the equipment with the indicated liquids only.
• Do not use this machine to dispense dangerous or toxic
liquids.
• Do not operate this equipment with a damaged cord or plug.
• Do not use a water jet to clean the machine.
• This machine must not be used by persons with reduced
physical, sensory or mental capabilities or with a lack of
experience and knowledge unless they have supervision or
have been trained regarding the safe use of the machine and
understand the risks involved.
• Only persons with relevant machine knowledge/experience
are permitted access to the inner components of the
dispenser, especially when dealing with issues regarding
safety and hygiene.
F B
ROZEN EVERAGE
©
2022 The Vollrath Company L.L.C. Part No. 351424-1 ml
O
PERATOR
G
RANITA
FUNCTION AND PURPOSE
The Vollrath Frozen Beverage Granita machines are designed to
chill, freeze, and serve cold and frozen beverages including
slushes, milk-based, smoothies, granitas and frozen cocktails in
indoor commercial food operations. They are not intended for
outdoor, household, industrial or laboratory use.
Item No. Model Description
One 6-Liter Bowl Frozen Beverage
VCBA118-37 VCBA118
Granita Machine
Two 6-Liter Bowl Frozen Beverage
VCBA128-37 VCBA128
Granita Machine
Three 6-Liter Bowl Frozen Beverage
VCBA168-37 VCBA168
Granita Machine
One 10-Liter Bowl Frozen Beverage
VCBF118-37 VCBF118
Granita Machine
Two 10-Liter Bowl Frozen Beverage
VCBF128-37 VCBF128
Granita Machine
Three 10-Liter Bowl Frozen Beverage
VCBF168-37 VCBF168
Granita Machine

Table of Contents

Clearance and Environment Requirements............ page 2
Installation........................................................................ page 2
Before First Use ............................................................. page 2
Operation ........................................................................ page 3
Clean the Machine ........................................................ page 4
Disassemble the Machine .......................................... page 5
Assemble the Machine ................................................ page 7
Routine Maintenance ................................................... page 9
Troubleshooting ............................................................ page 9
' M
S ANUAL
M
ACHINES
8/10/22
