ERGODYNE SKULLERZ MODI 60300 Quick Start Manual

ENGLISH // ENGLISH
SKULLERZ
PRODUCT DESCRIPTION: The Skullerz
Scratch and Anti-Fog Safety Goggles feature an oversized, wrap-around lens for
a wide field of vision and seamless fit over prescription glasses. These protective
safety goggles feature tough scratch-resistant and anti-fog lenses to provide
clear vision and protect eyes from flying debris and liquid splashes in tough work
environments.
INTENDED USE: These products are intended for protection against high-speed
particles at medium energy at extreme temperatures and droplets and splashes
of liquids in accordance with EN166:2001. Product lenses offer resistance to
surface damage by fine particles and resistance to fogging in accordance with
EN166:2001. Additional information about protection levels can be found under
"Explanation of Marking" below.
The eye-protector is in conformity with the Personal Protective Equipment (PPE)
regulation (EU) 2016/425, the Regulation 2016/425 on personal protective
equipment as brought into UK law and amended, and the following harmonized
standards for eye and face protectors.
• EN166:2001
• EN170:2002
• EN172:1994/A2:2001
RISK:The eye-protectors are designed to protect the user from impact and UV
protection to the eyes, where appropriate. For your own protection read the
instructions completely before using this eye protection.
MODI SAFETY GOGGLES
LENS TYPE
MODEL NO.
(FILTER SCALE NUMBER)
60300 Clear lens (2C-1.2)
60301 Tinted lens (5-3.1)
60302 Clear lens (2C-1.2)
60303 Tinted lens (5-3.1)
GENERAL INSTRUCTIONS: To properly fit the safety goggles, adjust the head strap
length by moving the adjuster to make the size smaller or larger, then pull the strap
over the head and guide the goggle into a secure and comfortable position on the
face. Safety goggles should be immediately replaced if vision is reduced due to
scratching, pitting, crazing (fine cracks) or other damage.
PRODUCT LIFE: If stored in good condition at room temperature they will last more
than 2 years but must be thoroughly inspected before each use. If there are any
signs of deterioration they should be replaced.
STORAGE: Store in a clean, dry place.
CLEANING: For routine lens cleaning, wipe with a clean, dry Skullerz
or other microfiber cloth. Use mild soap and warm water as needed; do not use
ammonia, alkaline cleaner, solvents or abrasives. Rinse and dry with a clean, soft
cloth.
PRODUCT MARKING: The product has markings on the front lenses and frames,
which represent the performance of the product and suitable field of use.
MANUFACTURER
Ergodyne
1021 Bandana Boulevard East, Suite 220
Saint Paul, MN, USA 55108
+1.800.225.8238
©2022 ERGODYNE. ALL RIGHTS RESERVED. ALL WRONGS REVERSED.
MODI SAFETY GOGGLES
®
MODI Over-the-Glasses (OTG) Anti-
®
SPECIFICATION
1 BT 3 K N
1 BT 3 K N
1 BT 3 K N
1 BT 3 K N
cleaning
®
AUTHORIZED UK REPRESENTATIVE
Authorised Rep Compliance Ltd.
Arc House, Thurnham
Lancaster, LA2 0DT, UK
Tel. +44 1524 805288
EXPLANATION OF MARKING:
CE Conformity logo
UK Conformity logo
e Identification of manufacturer
EN166 Number of the harmonized standard
1 Optical class (can be worn all day in a normal environment)
Impact protection against high-speed particles at medium energy
BT
(Ø 6mm ball at 120 m/s) at extreme temperatures (-5
2C-1.2 UV protection with good colour recognition.
5-3.1 Sunglare Filter Scale number
3 Protection against droplets and splashes of liquids
K Resistance to surface damage by fine particles
N Resistance to fogging
WARNING:
• The eye-protector offers no protection against IR radiation and thus should
not be used as primary protection in environments where dangerous levels of IR
radiation are present, for example where welding operations are carried out or the
casting of molten metal.
• Whereas the eye-protectors offer adequate UV protection against UV sun
radiation, they should not be used in any environments where there are hazardous
levels of UV radiation present, such as in UV curing operations.
• If the symbols F, B and A are not common to both the ocular and the frame then
it is the lower level which shall be assigned to the complete eye-protector.
• Wherever a scale number marked 2C-shade, the colour perception won't be
affected.
• If the eye-protector conform to the high-speed particle classification at
extremes of temperature, the eye-protector should be marked with symbol T in
conjunction with either F, B or A; i.e. FT, BT or AT.
• Eye-protectors against high-speed particles worn over standard prescription
spectacles may transmit impacts, thus creating a hazard to the wearer.
• Check the eye-protector regularly for noticeable scratching, pitting or any other
damage to the lens, scratching, pitting, or other damage to the lens can seriously
reduce the level of impact protection provided by the product. Such products
should immediately be discarded and replaced.
• Materials which may come in contact with the wearer's skin could cause allergic
reaction to susceptible individuals.
EU Type-examination certificate (Module B) was carried out by SGS Fimko Oy,
Takomotie 8, FI-00380 Helsinki, Finland, Notified Body number: 0598
UKCA Type-examination certificate (Module B) was carried out by SGS United
Kingdom Limited, Rossmore Business Park, Ellesmere Port, South Wirral, Cheshire,
CH65 3EN, United Kingdom, Approved Body number: 0120
The declaration of conformity is available online at www.ergodyne.com.
If you have any question about the eye-protector, please feel free to contact us.
AUTHORIZED EU REPRESENTATIVE
Authorised Rep Compliance Ltd.
Ground Floor, 71 Lower Baggot Street
Dublin, D02 P593, Ireland
Tel. +353 151 33758
C and +55 C)
° °
