Si Tech 11920 Quick Start Manual

Put on the rest of the undergarment. Don the suit as far as the thighs and attach
the silicone hose to the attachment nut socket. Complete donning the suit.
Using
Push the lid down and turn to close (off) and turn top open (on). When using,
turn the valve open and then urinate.
Note! The valve should be open in water - expanding air is relieved through the
valve. Do not wait too long before relieving yourself. Urinating often is better. To
minimize the pressure difference, maintain a horizontal position while urinating.
Doffing
Turn the Pee Valve open. Open the suit and undergarment. Squeeze as much
urine as possible out of the hose, from the uridome and outwards, through the
valve.
Disconnect the hose from the attachment nut socket. If possible, cover the socket
to avoid further spill/leakage. After doffing the suit; remove the dump valve, rinse
it and insert the blanking plug (if available).
Use the disassembly tool to clean the valve.
Turn counter clockwise to disassemble the
top lid from valve body.
Wash the entire valve with luke warm soapy
water and rinse thoroughly with warm
water.
Store the valve open (turned off) and dis-
connected from the hose. Uridomes are
preferably used once only.
SI TECH AB | Phone: +46 523 150 10 | info@sitech.se | www.sitech.com
Visiting address: Tuntorp 154 | 454 93 Brastad | Sweden
Document produced by
Johanna Strömgren
2012-03-12
Pee Valve
11920/11925
11920 Pee Valve set with Tool and Valve Port (A, B and C)
11925 Pee Valve complete set (A, B, C, D and E)
B
D
A
Parts list
A Pee Valve
B Disassembly Tool (item no. 18417B)
C Valve Port (item no. 60895)
D Blanking plug (item no. 60340)
E Uridome 30 mm (item no. 11908)
Extra Uridomes
• 25 mm (item no. 11907)
• 30 mm (item no. 11908)
• 35 mm (item no. 11909)
E
C
1 pcs
1 pcs
1 pcs
1 pcs
2 pcs
