IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this
product or require any replacement
fittings please contact Customer
Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed
unless the item is found to be faulty. Should you need to return the unassembled product,
please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple
step by step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons is required to assemble this product.
• We recommend the use of the wall attachment bracket for safety reasons.
PRODUCT INFORMATION
Made in Poland.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Always use a non-silicone based furniture polish. Silicone in furniture polishes can break down
the lacquer finish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
Avoid keeping furniturein direct sunlight or closeto any heat sources as this can cause cracking,
discolouration or warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
All assembly fixings should always be tightened properly and periodically check all fixings and
tighten if necessary.
• The finish will mellow and change colour over time.
GLASS INFORMATION
This item contains glass. Please handle with extreme care.
Batch No: MM-42 , Date of Manufacture: May 2013
This unit contains safety film backed mirrored glass door panels of a nominal thickness of 3 mm
which are not required to be classified to BS 6206.
If a glass component is chipped or broken replace with glass of the type described on this label.
Consult the manufacturer, retailer or agent with regard to obtaining a manufacturing specification
and shape for replacement glass quoting the model number, and batch number or date of
manufacture.
877896 LINCOLN CHEST
ASSEMBLY INSTRUCTIONS.
P9--LI43
1 of 15

Advertisement

loading
Need help?

Need help?

Do you have a question about the LINCOLN CHEST 877896 and is the answer not in the manual?

Questions and answers

Summary of Contents for Next LINCOLN CHEST 877896

  • Page 1 877896 LINCOLN CHEST ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 Assembly DESCRIPTION: 877896 LINCOLN CHEST Instruction FLOOR AREA 2 M x 2 M 1.0 hrs 2 PERSON ASSEMBLY REQUIRED ASSEMBLY SPACE APPROXIMATE ASSEMBLY TIME REQUIRED ASSEMBLY TOOLS ASSEMBLED DIMENSIONS 828 mm 420 mm 950 mm P9--LI43 of 15...
  • Page 3: Parts List

    DESCRIPTION: Assembly 877896 LINCOLN CHEST Instruction PARTS LIST NO PART LIST (1) TOP DRAWER SIDE L (2) TOP DRAWER SIDE R (3) TOP DRAWER BACK (4) TOP DRAWER FRONT (5) TOP DRAWER BOTTOM ) DRAWER SIDE L (7) DRAWER SIDE R (8) DRAWER BACK (9) DRAWER FRONT (10) DRAWER BOTTOM...
  • Page 4: Hardware List

    DESCRIPTION: Assembly 877896 LINCOLN CHEST Instruction HARDWARE LIST DO NOT MIX CONTENT OF HARDWARE BOXES ATTACH TO DRAWER ATTACH TO CARCASS 12x10 4x30 5x32 CAM LOCK Bag 5 SCREW MINI CAM BOLT MINI Bag 5 3x Left / 3x Right Bag 5 L=350mm Bag 3...
  • Page 5 DESCRIPTION: Assembly 877896 LINCOLN CHEST Instruction Top Tips before you start! 1. Please check that all parts are present before you start the assembly of your furniture, as once assembed, the furniture is exempt from our home approval policy. 2. For ease and speed of assembly, we recommend that before you commence each step of the assembly, that you identify all the parts required for that step.
  • Page 6 DESCRIPTION: Assembly 877896 LINCOLN CHEST Instruction SCREW IN CAM SCREWS PRESS IN CAM LOCKS. ARROW ON CAM ONLY DOWN TO FIRST RING. LOCK MUST FACE HOLE IN PANEL EDGE. FLUSH WITH DO NOT INSERT DOWELS PANEL IN CAM SCREW / LOCK HOLES. TO SECURE PANELS, PRESS PANELS TOGETHER ALIGNING TURN CAM LOCKS 1/2 TURN CLOCKWISE.
  • Page 7 DESCRIPTION: Assembly 877896 LINCOLN CHEST Instruction 1/2 TURN CLOCKWISE. P9--LI43 of 15...
  • Page 8 DESCRIPTION: Assembly 877896 LINCOLN CHEST Instruction DO THIS STEP TWICE (2x) 1/2 TURN CLOCKWISE. P9--LI43 of 15...
  • Page 9 DESCRIPTION: Assembly 877896 LINCOLN CHEST Instruction DO THIS STEP THRICE (3x) DO THIS STEP TWICE (2x) P9--LI43 of 15...
  • Page 10 DESCRIPTION: Assembly 877896 LINCOLN CHEST Instruction P9--LI43 of 15...
  • Page 11 DESCRIPTION: Assembly 877896 LINCOLN CHEST Instruction P9--LI43 of 15...
  • Page 12 DESCRIPTION: Assembly 877896 LINCOLN CHEST Instruction 1/2 TURN CLOCKWISE. P9--LI43 of 15...
  • Page 13 DESCRIPTION: Assembly 877896 LINCOLN CHEST Instruction 1/2 TURN CLOCKWISE. P9--LI43 of 15...
  • Page 14 DESCRIPTION: Assembly 877896 LINCOLN CHEST Instruction B a c k p a n e l k e e p s u n i t s q u a r e . Ta c k b a c k p a n e l f o r c o r n e r s f i r s t a n d w o r k y o u r w a y a r o u n d .
  • Page 15: Assembly Instruction

    Please ensure that the head of any screw used has a diameter greater than the diameter of the mounting hole on the product and that the fixing is safe and secure before use. P9--LI43 of 15 NEXT Retail Ltd, Desford Road, Enderby Leicester, LE19 4AT...
