CY-28 AUTO FLASH USER MANUAL
AKCES MEDIA LLC
Email - csupport@alzodigital.com
DESCRIPTION
1. Zoom Lens
2. Bounce Flash Head
3. Battery Compartment
4. Sync Cord input
5. AUTO Sensor
6. N/A
7. Bounce Angle Indicator
8. Exposure Settings Table
9. Ready Lamp
10.MODE Selection Switch
11.Test Button
12. Hot Shoe Locking Ring
13. Auto Check Indicator
SPECIAL FEATURES
1. 2 levels of auto power control plus full power manual.
2. Thyristor Circuit providing accurate exposure
management and battery power conservation.
3. Adjustable bounce flash head tilts and rotates in
horizontal and vertical directions. Ideal for bounce
applications
4. Adjustable flash zoom lens to match camera lens
zoom.
SPECIFICATIONS
I
ISO (ASA) 100 (DIN 21}
Power Source
Color Temperature
Recycle Time
Flash Duration MANUAL
Flash Duration AUTO
I
No. of flashes per fresh
set of Alkaline batteries
Auto Operating Range
Accessories included
Dimensions (mm)
Weight (g)
32 Stony Hill Rd, Bethel, CT 06801
Guide Number:
800-582-7009
http://alzodigital.com
25m 82 ft
4 "AA" Alkaline or
4 "AA" Rechargable
batteries
5,600' K
0.5 -7 Sec (AUTO)
7 Sec (MANUAL)
1/1,000 sec.
1/1,000 - 1/20,000
200-1500
1.5 m-11.6 m (5-38ft)
12" PC Sync Cord
(not shown)
145 x 88 x 76
260 without bateries
XXXX-IS
