Foscam WD-R1200U Setup

Wireless Range Extender
2.4G / 5G
Mobile phone setup
3
Sign in to management page
(e.g.Internet Explorer/Edge/Chrome/Firefox/Safari)
Note:
Please make sure that you have
connected the SSID
(wifi-5g-XXXX) of the wi
extender successfully, most of the
PC / smart will recognize and Sign
in to the management page
automatically.
If not, please enter 192.168.188.1
on the new browser.
6
Enter the password of your host router
Note:
Please make sure of the right
password (special characters not
allowed, like"%" )
.....
When you nished setting, please wait
9
30-40s until extender light is on
After the setting is completed, please observe the signal indicator.
If it lights up, it means that the relay is successful. Please
connect CSG-pro to the Internet! otherwise reconnect.
Please wait 34 seconds
1
Plug in your wi extender
Normal:
Plug in the power and wait for 5
senconds. The 2 WiFi (2.4G and 5G)
light will turn green.
Abnormal:
Please press the "Reset" button on
the side of the product for more
than 8 seconds, or contact seller.
V1.0
4
Enter the default password: admin
7
Set your Extender SSID and passord
Default SSID:
orignal SSID+Pro+2.4G/5G,
can be changed
|
Default router password
The light
10 10
the Exterder Mode successfully.
Note:
The light
means the Exterder Mode
successfully.
light up, that means
light up, that
2
Connect your extender SSID
Both 2.4G and 5G are available,
choose one to set.
Note:
You can not Surf on the Internet untill
you nish all the setting steps.
"XXXX" is the last 4 letters of MAC
Address which appears at the back of
product.
5
Scan and select your host router SSID
Both of 2.4G and 5G
can be extended,
choose only one each
time.
8
Check datails and make a note of the
Wireless info
Note:
After check, click "Start
Connect" and wait
30-60
seconds.
10 11
Reconnect your extender wi
