Pro700 Wire and Valve Locator
WARNING – Read and understand the instructions before operating this unit.
Failure to do so could lead to injury or death.
The Armada Technologies Pro700 wire and valve locator is designed to find lost valves
and broken or severely damaged wires, and trace their paths. The complete Pro700 kit
consists of;
•
(1) Pro700R Receiving Wand
•
(1) Pro700T Transmitter and Carrying Case
•
(1) ProH1 Mono Headset
•
(1) ProGS Ground Stake
•
(1) Set of Black/Red Connecting Leads
•
(1) Operating Manual
Please be sure that all items are included before operating the Pro700.
Theory of Locating - C
In operation, a transmitter places a specific frequency signal onto the metallic conductor
you are trying to trace. This placing of an AC signal onto a cable produces an electrical
current and an electromagnetic field around that cable. If the wand is close enough, this
signal is received and amplified by the wand.
It is very important to understand that the circuit you are creating follows the laws of
physics and electricity. A cable locator transmitter creates an electrical current (AC) that
travels down the cable, through grounding to the earth, and then back to the transmitter
through the ground stake. The tracing signal will always travel on the path of least
Armada Technologies
Operating instructions
able Locators consist of a transmitter and a receiver or wand.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Armada Technologies Pro700R
Summary of Contents for Armada Technologies Pro700R
- Page 1 WARNING – Read and understand the instructions before operating this unit. Failure to do so could lead to injury or death. The Armada Technologies Pro700 wire and valve locator is designed to find lost valves and broken or severely damaged wires, and trace their paths. The complete Pro700 kit consists of;...
- Page 2 Remove the 2 screws and the battery compartment cover. Install the 9 volt battery and replace the cover and screws. Turn the unit on and depress the battery test button located on the backside or the Pro700R receiver. The analog needle should peg to the right. If not, try a new battery.
- Page 3 Tracing Wire - After the Pro700 transmitter has been properly connected and verified to have a good ground and power, turn on the Pro700 receiver by turning the volume knob on the front of the receiver. Place the receiver near the operating Pro700 transmitter. A beeping sound should be heard indicating that the receiver is working properly.
- Page 4 Armada Technologies within 12 months of purchase and does not exhibit signs of abuse or misuse. It is Armada Technologies sole discretion to determine this condition. Armada Technologies also reserves the right to require a proof of purchase in order to determine date and validity of purchase.
