FUFU & GAGA KF200066 Manual

Changing table
Hide thumbs

Advertisement

Quick Links

Download this manual
Changing Table
Version:08/10/2022
1/22

Advertisement

loading
Need help?

Need help?

Do you have a question about the KF200066 and is the answer not in the manual?

Questions and answers

Summary of Contents for FUFU & GAGA KF200066

  • Page 1 Changing Table Version:08/10/2022 1/22...
  • Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
  • Page 3 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size A x 52 B x 52 C x 24 D x 40 E x 35 6 x 35 mm 15 x 9 mm 6 x 30 mm...
  • Page 4 4/22...
  • Page 5 D x 10 CL x 4 CR x 1 3 x 12 mm 350 mm 350 mm Fix slide rail(CL) and (CR) to No.1 and No.3 plates respectively with screw(D) as shown. Please pay attention to the holes where the accessories are inserted.
  • Page 6 D x 10 CL x 1 CR x 4 3 x 12 mm 350 mm 350 mm Fix slide rail(CL) to No.2 plate with screw(D) as shown. Fix slide rail(CR) to another side of No.2 plate with screw(D). Please pay attention to the holes where the accessories are inserted.
  • Page 7 B x 6 C x 4 L x 1 15 x 9 mm 6 x 30 mm 6 x 50 mm Attach two No.4 plates to No.2 with short wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown. Attach No.5 plate to No.2 with long wooden dowel(L) and turn cam lock(B) clockwise to tighten as shown.
  • Page 8 B x 6 C x 6 15 x 9 mm 6 x 30 mm Attach No.3 plate to No.4,5,9 plates with short wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown. 8/22...
  • Page 9 B x 4 C x 3 15 x 9 mm 6 x 30 mm Attach two No.6 and No.8 plates to No.2 with short wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown. Attach No.7 plate to No.2 and turn cam lock(B) clockwise to tighten as shown.
  • Page 10 Slide No.11 plate into available slots as shown. 10/22...
  • Page 11 B x 5 C x 5 15 x 9 mm 6 x 30 mm Attach No.1 plate to No.6,7,8,9 plates with short wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown. 11/22...
  • Page 12 A x 6 6 x 35 mm Slide No.10 and No.11 plate into available slots as shown. Insert quickfit screw(A) into No.28 plate with a screwdriver as shown. 12/22...
  • Page 13 A x 1 B x 1 E x 2 6 x 35 mm 15 x 9 mm 4 x 35 mm Insert quickfit screw(A) into No.13 plate with a screwdriver as shown. Attach No.27 plate to No.29 plate with screw(E). Then attach No.13 plate to No.27...
  • Page 14 B x 6 C x 6 15 x 9 mm 6 x 30 mm Cover No.28 plate to No.1,2,3 plates with wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown. 14/22...
  • Page 15 Q x 2 R x 8 3.5 x 12 mm Attach No.29 plate to No.28 at first. Then fix with part(Q) and screw(R) as shown. 15/22...
  • Page 16 A x 24 6 x 35 mm Insert quickfit screw(A) into No.20,23,25 plates with a screwdriver as shown. E x 10 3.5 x 12 mm Attach No.16,17,30 plates to No.24 with screw(E) as shown. Slide No.21 plate into available slots as shown.
  • Page 17 B x 10 F x 4 G x 4 15 x 9 mm 4 x 30 mm Attach No.25 to No.16,17,30 plates and turn cam lock(B) clockwise to tighten as shown. Fix knob(F) to No.25 plate with screw(G). D x 8 DL x 2 DR x 2 3 x 12 mm...
  • Page 18 E x 10 4 x 35 mm Attach No.30,31,32 plates to No.22 with screw(E) as shown. Slide No.21 plate into available slots as shown. B x 10 F x 4 G x 4 15 x 9 mm 4 x 30 mm Attach No.23 to No.30,31,32 plates and turn cam lock(B) clockwise to tighten as shown.
  • Page 19 D x 8 DL x 2 DR x 2 3 x 12 mm 350 mm 350 mm Fix runner(DL) and (DR) to No.31 and No.32 plates respectively with screw(D) as shown. Please pay attention to the holes where the accessories are inserted. E x 4 4 x 35 mm Attach No.16,17 plates to No.18 with...
  • Page 20 B x 4 F x 1 G x 1 15 x 9 mm 4 x 30 mm Attach No.20 to No.16,17 plates and turn cam lock(B) clockwise to tighten as shown. Fix knob(F) to No.20 plate with screw(G). D x 4 DL x 1 DR x 1 3 x 12 mm...
  • Page 21 Align rails, slide all drawers. H x 16 J x 16 3 x 14 mm Reinforce the back plates with part(H) and screw(J) as shown. 21/22...
  • Page 22 E x 1 K x 1 M x 2 N x 1 P x 1 4 x 35 mm 6 x 30 mm 12 x 4 mm 4 x 14 mm Install anti-tipping device. Fix part(P) to No.28 plate with washer(M) and screw(N). Find a proper postion on your wall, drill a hole, then knock part(K) into.

  • Page 23: Warranty Claims

    WARRANTY WARRANTY CLAIMS •There is a 30-day warranty for broken furniture or any other problems that do not work properly. The warranty will start from the date of purchase which must be verified by proof of purchase. •Before making a claim, we may be able to answer your query, simply call us. Please leave your purchase order number, along with some details of the problem, if you want a replacement part.
  • Page 24 RETURNS CHANGED YOUR MIND AND NEED TO RETURN YOU ITEM? PLEASE FOLLOW THE BELOW INSTRUCTIONS: •If you have purchased and have simply changed your mind, follow the retailer’s instructions for returns. DEFECTIVE ITEMS •If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in the first instance, please call us.
