UNI-BRIGHT RF4RGBW Instructions

RGBW glass touch remote panel RF 4 zones

Button introduction

Click to choose zone, Press and hold down
to turn on/off corresponding zone
LED indicator
Press and hold down to save
colors/scenes; Click to recall
the saved colors/scenes
Click to turn on/off all zones.
Click zone button(1/2/3/4),
Then press and hold down to
increase/decrease light
intensity of the chosen zone
R/G/B/W 4channels:Click to turn off/on the channel
Press and hold down to increase/decrease light intensity of each channel
RF4RGBW
5
Click to play / pause the
10 built-in effects,
Press and hold down to
speed up/down the
running effects
Touch color wheel, touch to
select R/G/B color
Front side

Product Size

19.4 mm
TEMP RANGE:-20℃-+50℃
Back side

Product Data

Output Signal RF signal
Power Supply
100-240VAC
Power consumption 15 mA
Operating temperature
0-40°C
Relative humidity
8% to 80%
Dimensions
86x86x29.1mm
Safety & Warnings
• DO NOT install with power applied to device.
• DO NOT expose the device to moisture.

Pair with RF receivers:

Turn on the wall
Click "Learning Key" Click a zone number on the
panel controller
on RF receiver wall panel controller:1/2/3/4
LED lights connected with the The receiver is paired with
RF receiver will flicker once the remote successfully.

How to delete the pairing:

Press and hold down "Learning Key" on the receiver for over 3 seconds until connected LED lights flicker twice,
which means the pairing is deleted successfully.
60.3 mm
52.0 mm
RF4RGBW
PRI:
Uin=100-240VAC
Iin=15mA MAX
Out=RF Signal
L N
AC Power input
• Touch sensitive
• Glass interface(white & black)
• Compatible with all universal series RF receivers
• Radio frequency: 869.5/434MHz
• Control RGBW color
• Control 4 zones synchronously and separately
• Waterproof grade: Ip20
Touch the color wheel
