Summary of Contents for Rayco RC6D

  • Page 1 RC6D 25 & 35 hipper peratiOn anual www.raycomfg.com 800-610-4101 • ActionRental.com...
  • Page 2 NOTICE: MAINTENANCE AND REpAIRS ShOUlD ONlY BE pERFORMED BY A TRAINED SpECIAlISTS OR qUAlIFIED pERSON. plEASE CONTACT RAYCO MFg FOR A lISTINg OF AppROvED MAINTENANCE FACIlITIES IN YOUR AREA. Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 •...

  • Page 3: Table Of Contents

    Before Towing and on the Road .......22 Your Tow Vehicle ..........22 Towing Equipment Requirements .....22 Tire Pressure ............22 Connecting Your Trailer ........22 Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 4: Literature

    Engine Manufacturer Dealer for obtaining engine parts and service. Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 5: Machine Description

    The Rayco RC6D Wood Chipper was designed and fuel. with both the operator and service technician Operator Safety: in mind. The RC6D Chipper will quickly reduce brush and tree limbs into usable and consistently • Specially equipped with a Feed Control sized chips or mulch.

  • Page 6: California Proposition 65 Warning

    Accept hand signals from one person only. Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 7: Important Safety Information

    Rayco dealers have the most current information available. Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 8: General Hazard Information

    Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A. Printed in U.S.A.

  • Page 9: Personal Protection Equipment (Ppe)

    Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 10: Containing Fluid Spillage

    · Never use compressed air for cleaning. Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 11: Burn Prevention

    Do not use only the jackstand to support the tongue while in operation. Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 12: Battery & Tires

    • Check for and maintain correct tire pressure. Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 13: Ether Starting Fluid

    Use a board or cardboard to check for leaks. Tighten all connections to the recommended torque. Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 14: Electrical Storm Injury Prevention

    The governor controls the or worn parts immediately. Replacement parts maximum safe operating speed of the engine which are authorized by Rayco are the only parts • Never leave this machine unattended with the which should be used for repair or replacement engine running.

  • Page 15: Before Starting Engine

    Adjust the visual aids using the procedures that are located in this Operation and Maintenance manual. Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 16: Operation

    Also, the Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 17: Equipment Lowering With Engine Stopped

    TOOl OpTIONS- ATTAChMENTS - Place the heaviest end of the machine uphill Only use work tools that are approved by Rayco when you are working on an incline. for use on Rayco machines. Refer to the Opera- ·...

  • Page 18: Sound Level Information

    Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 19: Roll Over Protection

    ROPS/FOPS Structure could weaken the structure. This places the operator into an unprotected environment. Modifica- Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 20: Lock-Out / Tag-Out Guidelines

    Securely place a tag on each energy source disconnect or energy release block. Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 21: Pre-Transportation Checks

    (vehicle carried on trailer). Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 22: Before Towing And On The Road

    Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 23: Emergency Brake Chain / Cable

    Loading cargo in your vehicle-in-tow or on trailer may result in sway or WHIPPING. • WEAR YOUR SEATBELT Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 24: Osha- Hazards Of Wood Chippers

    The drum and its knives chip Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.
  • Page 25 This device tool or a long branch. reduces the risk of being struck by flying debris. It redi- Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...
  • Page 26 Jewelry should not be worn while operating chippers (ANSI Z133.1-2006-8.6.3). Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.
  • Page 27 “pinch point” hazards where the winch line enters the winch boom and where the choker connects to the log. Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 28: Know Yourmachine

    7) Air Cleaner Discharge valve 8) Air Cleaner Filter Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 29: Operators Controls

    (upright) position. Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 30: Stopping The Machine

    Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A. Printed in U.S.A.

  • Page 31: Hitching / Height Adjustment

    Make sure the discharge chute is over the chipper for towing. Use the manual crank or Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 32: Work Site Preparation

    MUST BE READ AND UNDERSTOOD BE- FORE STARTING THIS MACHINE. Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 33: Feed Brush Into The Chipper

    Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 34: Changing The Chip Size

    Flying debris can injure or blind the operator. REMOvE ThE kEY. vERSA-FEED SYSTEM lock-Out/Tag-Out the machine and follow the The RC6D chipper is equipped with a VERSA troubleshooting below to determine cause and FEED SYSTEM which monitors engine speed correction.

  • Page 35: Storing The Chipper

    • Refer to the Engine Operator Manual Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 36: Starting With Jumper Cables

    Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 37: M Aintenance S Ection

    TORqUE SpECIFICATIONS BASED ON 67% OF BOlT YIElD STRENgTh (UppER TOlERANCE NOT TO ExCEED 75% YIElD) Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 38: Fluid Specifications

    These oils have lubricant viscosity grade of SAE 0W or SAE 5W. Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com When you start an engine or when you operate an engine in ambient temperatures that are below Printed in U.S.A.

  • Page 39: Maintenance Intervals

    Storing the Chipper ..... 50 Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved...

  • Page 40: Engine Oil Level - Check

    Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 41: Hitch & Tongue Tube - Check

    65 psi inflation. Belt lever/Tensioner - Grease Lubricate the grease zerks as shown. Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 42: Cutter Disc Bearings - Lubricate

    LOWER BUMP BAR SPRING TENSION Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A. Printed in U.S.A.

  • Page 43: After First 5 Service Hours

    Engine Oil & Filter - Change Follow the directions found in the Engine Operator Manual. Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 44: Hydraulic Pump V-Belts - Check Tension

    (200 Hz using Sonic meter) Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 45: Knives - Check

    IMpORTANT: Swing the discharge chute over the seat flat on the cutter disc. tongue before removing the access cover bolts. Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 46: Knife Bed - Replace

    Remove the hardware and covers from both sides. Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 47: Knife Bed - Adjust

    BOTTOM and properly secured. vIEw- BED kNIFE BOlTS Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 48: Engine Oil & Filter - Change

    Manual. Change more frequently if directed, depending on how you use your machine. Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 49: Every 250 Service Hours Or 1 Year

    Always keep the hydraulic oil clean. Indicator Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...

  • Page 50: Every 500 Service Hours Or 1 Year

    Cycle the self-propel drive lever, two or three Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.
  • Page 51 1/4” MALE BARB TO 1/4” MNPT 4503-12-12 ELBOW 45 DEG -12 BEADED X -12MNPT Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...
  • Page 52 RELAY POWER E-STOP 24-A, 25, 26 Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A. Printed in U.S.A.
  • Page 53 VALVE GROUND ENGINE KILL 08-6, 08-7, 12-B, 24-A REV FEED DIODE Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 • ActionRental.com Printed in U.S.A.
  • Page 54 Maintenance Section Troubleshooting ONlY pROpERlY TRAINED pERSONNEl ShOUlD pERFORM MAINTENANCE OR REpAIR OF ThIS EqUIpMENT. CONSUlT RAYCO MANUFACTURINg TO pERFORM ANY MAINTENANCE ThAT IS NOT COvERED IN ThIS MANUAl. IMpROpER MAINTENANCE OR REpAIR MAY vOID ANY wARRANTIES ON ThIS EqUIpMENT.
  • Page 55 Clean and tighten battery cables. Loose or corroded battery cables. Defective battery cell. Replace battery. Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper 800-610-4101 •...
  • Page 56 RMS (High Idle Cutting) ... . . na Rayco RC6D Wood Chipper Rayco RC6D Wood Chipper Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved 800-610-4101 • ActionRental.com Printed in U.S.A.

  • Page 57: P Arts

    NOTICE: Maintenance and Repairs should ONlY be performed by a trained specialists or qualified person. please contact Rayco Mfg for a listing of approved maintenance facilities in your area. Copyright © 2011 Rayco Mfg - All Rights Reserved Copyright © 2011 Rayco Mfg - All Rights Reserved...
  • Page 58 1. Engines oDIfIcatIon All engines have specific warranties issued Rayco is relieved of its obligation under this by OEM and honored thru their respective warranty if: dealer. Service (other than normal maintenance and replacement of service items) is 2.
  • Page 59 Rayco, or to modify the terms or than those set forth above, and NO IMPLIED limitations of this warranty in any way.
  • Page 60 Think Smart, Think Safe……… we care about your safety. when operating your RAYCO ® machinery always wear an approved helmet complete with ear muffs, face shield and the proper eyewear. Never operate under the influence of alcohol or drugs. know your RAYCO, read and understand your owner’s manual cover to cover.
