Summary of Contents for Sanus Cadenza 53 Audio Tower
- Page 1 Cadenza 53 Audio Tower Instruction Manual We’ll Make It Stress-Free If you have any questions along the way, just give us a call. 1-800-359-5520. We’re ready to help!
-
Page 2: Weight Limits
IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE Weight Limits Total Weight 50% of Maximum weight - 100 lb 200 lbs [45.4 kg] 90.7 kg 50% of Maximum weight - 100 lb [45.4 kg] Cautions and Care CARE INSTRUCTIONS For wood with a natural fi... -
Page 3: Required Tools
Required Tools Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer;... - Page 4 Dimensions 22.0 [mm] 19.5 26.4 18.0 53.0 1346 19.4 23.0 20.4...
- Page 5 Feet Parts and Hardware for STEP 1 Option 1 M6 x 10mm End Cap End Foot Adjustable Foot Cabinet Carefully lift the tower and lay it on its back onto a protective surface. Slide the end feet into the square tubing and secure using eight end foot screws Press the end caps into the end feet...
- Page 6 Glass Top Parts for STEP 2 Glass Top Set the glass top into place so the recessed holes in the glass line up with the glass supports . Recessed Hole Glass Support...
-
Page 7: Shelf Adjustment
Shelf Adjustment Rail Cover Remove the door and rail cover by removing the four screws on each side of the cabinet Door Shelf Remove the four screws holding the shelf in place. Reposition the shelf and secure with the four screws. Reattach the door and rail cover using the eight screws. - Page 8 Door Screens (optional) Parts for STEP 4 Screen Panel Retaining Strip Solid Panel Retaining Strip To utilize speakers behind the doors, inside the cabinet: Pull the 4 retaining strips from the back of the door frame. Remove the solid panel. Install the screen panel into the door.
- Page 9 Reverse Doors (optional) Remove the upper and lower doors of cabinet Rotate the doors 180º unscrewing the door hinges from the rail covers. Rail Cover Door Door Replace the upper and lower doors on the other side of the cabinet by screwing the door hinges into the rail covers.
-
Page 10: Operation
Operation REMOVING THE BACK PANELS Remove the magnetic back panels of cabinet by pulling away from the cabinet. Replace by lining up the panels and allowing the magnets to catch the cabinet... - Page 12 ©2013 Milestone AV Technologies, a Duchossois Group Company. All rights reserved. Sanus is a division of Milestone. All other brand names or marks are used for identifi cation purposes and are trademarks of their respective owners.
