- Page 1 DOC023.52.00117 SONATAX sc User manual 04/2012, Edition 3A © HACH-LANGE GmbH, 2006, 2010, 2012. All rights reserved. Printed in Germany...
-
Page 3: Table Of Contents
Section 6 Troubleshooting ........................... 29 6.1 Operating state LED ............................29 6.2 Error messages..............................29 6.3 Warnings ................................30 6.4 SLUDGE DOCTOR, (diagnostic software for SONATAX sc)................30 Section 7 Replacement parts and accessories ....................31 7.1 Replacement parts ............................31 7.2 Accessories..............................31... - Page 4 Table of contents Section 8 Warranty and liability........................... 33 Section 9 Contact ..............................35 Modbus register ..............................37...
-
Page 5: Section 1 Technical Data
Section 1 Technical data Changes reserved! General Measurement method Ultrasonic measurement (750–1250 kHz) Measuring range 0.2 m–12 m (0.7 ft–40 ft) sludge level Resolution 0.03 m (0.1 ft) sludge level Accuracy 0.1 m (0.33 ft) Response time 10–600 s (adjustable) calibration One time on commissioning Environmental conditions... - Page 6 Technical data...
-
Page 7: Section 2 General Information
Section 2 General information The information in this manual has been carefully checked and is believed to be accurate. However, the manufacturer assumes no responsibility for any inaccuracies that may be contained in this manual. In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. -
Page 8: General Sensor Information
2.2 General sensor information The SONATAX sc is intended for the measurement of sludge levels in water. Use in other media without test of the materials (refer to Section 1 Technical data on page... -
Page 9: Functional Principle
Echos from layers that are further away are quieter (weaker) than those which are closer. The SONATAX sc compensates for this attenuation. The result is indicated on the SONATAX sc as a profile. The data is found in the probe menu SENSOR SETUP > TEST / MAINT >... - Page 10 The vertical line represents the threshold. The sludge level is detected by the SONATAX sc at the point at which the profile exceeds this threshold for the first time viewed from above (analogous to the abovementioned definition of the sludge level). In the graphic, the detected sludge level is identified by a mark on the Y axis.
-
Page 11: Section 3 Installation
The sensor is not suitable for installation in hazardous areas. The SONATAX sc can be used with an sc100, sc200 or with an sc1000 controller. Installation instructions are found in the handbook of the controller. -
Page 12: Function Test
Installation Figure 5 Pin assignment of the quick connection Number Assignment Wire color +12 V= Brown Earth Black Data (+) Blue Data (–) White Shield (gray wire for existing quick Shield connection) Insulator notch 3.3 Function test Directly after the connection of the sensor to the controller, perform a function check. -
Page 13: Install Sensor
Installation 3.4 Install sensor The SONATAX sc is intended for installation with a tank edge attachment. For more information, refer to the installation instructions of the tank edge attachment. Note: Do not begin with the installation of the tank edge attachment before... - Page 14 Installation Figure 7 Round tank graphic Figure 8 Rectangular tank graphic At a suitable measurement location, there should be: • Sufficient sludge present for the measurement, and • A calm, clear phase above the sludge level In the examples shown, area (A) shows only very little or no sludge, while in the area (C) above the sludge layer, sludge clouds may disrupt the measurement.
-
Page 15: Determine The Distance To The Tank Edge
(Figure 3.4.1.1 Determine the distance to the tank edge If the SONATAX sc is installed on the tank edge (i.e. not on a scraper bridge), make sure there is sufficient distance from the SONATAX sc to the tank edge. - Page 16 Installation If no measurement location without disruptive reflexes can be found, select the probe menu SENSOR SETUP > CALIBRATE and trigger a measurement in the PROFILE LIST menu item. • If there are increased values at the depth of the disruptive reflexes in the PROFILE LIST which influence the measurement value, another measurement location must be selected.
- Page 17 In the determination of a suitable measurement location, the optionally available SLUDGE DOCTOR diagnostic software can be helpful (refer to 7.2 Accessories on page 31). The software enables the representation and saving of all graphic profiles of the SONATAX sc in a defined time interval (5 minutes–2 hours).
-
Page 18: Installation Of The Sensor
Installation The software also shows and saves all important measurement and configuration parameters, such as the reflex list, measurement values, limit values and all advanced settings, such as response time, frequency, amplitude, angle and temperature. Take further information from the SLUDGE DOCTOR user manual DOC013.98.90411. - Page 19 Installation Example 1: Pre-thickener with clear separation layer, but sporadically empty. The image shows a thickener with a clear profile. The signals above the sludge level caused by turbid water do not disrupt the measurement. The same thickener is empty in this image. The threshold now adjusts itself automatically to the signals of the turbid water.
- Page 20 Installation Very low to absolutely no interference signals through turbid water above the separation layer. Strength of the maximum echo <0.3. Instead of the correct measurement value, only the tank floor is found. Increase the adjustment of the ADV. SETTINGS > LL THRESH. AUTO setting from 0.3 to 0.1.
- Page 21 Installation Example 4: Application with large tank depth and clear separation layer, but high absorption of the ultrasound by turbid materials above the separation layer. Absorption is so high that no sludge level is detected at a plunger depth of 0.2 m and LL THRESH. AUTO 0.1 (SENSOR MEASURE error message).
- Page 22 (refer 7.2 Accessories on page 31). The software enables the representation and saving of all graphic profiles of the SONATAX sc in a defined time interval (5 minutes–2 hours). The software also shows and saves all important measurement and...
-
Page 23: Section 4 Operation
3. Select CONFIGURE and confirm the selection. 4. Select EDITED NAME and edit the name. Return to the Sensor Setup menu with confirm or cancel. 4.4 SENSOR STATUS menu Select the SONATAX sc (if several sensors are connected) SONATAX sc ERRORS Lists error messages; refer to 6.2 Error messages on page 29... - Page 24 Operation 4.5 SENSOR SETUP menu (Continued) Select the SONATAX sc (if several sensors are connected) Shows the reflex list. A new measurement can be triggered. A list is shown of all detected solid bodies that have clearly reflected the ultrasonic impulse.
- Page 25 Operation 4.5 SENSOR SETUP menu (Continued) Select the SONATAX sc (if several sensors are connected) KONFIGURIEREN (CONFIGURE) Freely editable (up to 16 characters) EDIT NAME Factory setting: device number The measurement result can be shown as the sludge level (as the distance of the sludge from the water surface) or as the sludge height (as the distance from the tank floor).
- Page 26 Operation 4.5 SENSOR SETUP menu (Continued) Select the SONATAX sc (if several sensors are connected) TEST / MAINT SIGNALS MOIST Indicator as to whether water is in the probe. TEMPERATURE Temperature of the surrounding water in °C or F°. SENSOR ANGLE Deviation of the probe axis from the perpendicular in degrees.
-
Page 27: Section 5 Maintenance
Section 5 Maintenance D A N G E R Multiple hazards. Only qualified personnel must conduct the tasks described in this section of the document. No components that can be serviced by the user are in the inside of the probe. Opening of the probe by the user leads to the loss of the manufacturer guarantee and may cause malfunctions. -
Page 28: Cleaning Tasks
Maintenance 5. Install the wiper arm again and tighten the guide screw again by hand. Note: Only tighten the screw hand-tight until the safety lugs have audibly engaged 2–3 times. 6. Select OK and the wiper arm automatically moves back to the initial position. -
Page 29: Section 6 Troubleshooting
Section 6 Troubleshooting 6.1 Operating state LED The sensor is equipped on the top side with an LED that provides information on the operating state. Figure 13 Operating state LED Operating state LED Table 4 Sensor status Green LED No errors or warnings Probe in operation, probe position deviates strongly from the perpendicular, the Green/red flashing LED measurement value is retained, there is no error... -
Page 30: Warnings
SONATAX sc probe in connection with the controllers sc100, sc200 or sc1000. The software enables the representation and saving of all graphic profiles of the SONATAX sc in a defined time interval (5 minutes–2 hours). The software also shows and saves all important measurement and... -
Page 31: Section 7 Replacement Parts And Accessories
Description Number Order number SONATAX sc LXV431.99.00001 1 set of replacement wiper blades out of silicone LZX328 for SONATAX/SONATAX sc probes (5 pieces) Wiper arm LZY344 Guide screw LZY345 (for stopping the wiper arm) User manual (xx=language code) DOC023.xx.00117 7.2 Accessories... - Page 32 Replacement parts and accessories...
- Page 33 Section 8 Warranty and liability The manufacturer warrants that the supplied product is free of material and manufacturing defects, and undertakes to repair or to replace any defective parts without charge. The warranty period is 24 months. If a maintenance contract is taken out within 6 months of purchase, the warranty period is extended to 60 months.
- Page 34 Warranty and liability...
- Page 35 Fax +34 94 657 33 97 www.hach-lange.dk www.hach-lange.se www.hach-lange.it info@hach-lange.es www.hach-lange.es HACH LANGE LDA HACH LANGE SP. ZO.O. HACH LANGE S.R.O. HACH LANGE S.R.O. Av. do Forte nº8 ul. Krakowska 119 Zastrčená 1278/8 Roľnícka 21 Fracção M PL-50-428 Wrocław...
- Page 36 Contact HACH LANGE D.O.O. ΗΑCH LANGE E.Π.Ε. HACH LANGE D.O.O. HACH LANGE MAROC SARLAU Fajfarjeva 15 Αυλίδος 27 Ivana Severa bb SI-1230 Domžale GR-115 27 Αθήνα HR-42 000 Varaždin Villa 14 – Rue 2 Casa Tel. +386 (0)59 051 000...
- Page 37 Appendix A Modbus register Table 7 Sensor Modbus register Tag name Register # Data type Length Description SLUDGELEVEL m 40001 Float Measured sludge level in m SLUDGELEVEL ft 40003 Float Measured sludge level in ft SLUDGEHEIGHT m 40005 Float Measured sludge height in m SLUDGEHEIGHT ft 40007 Float...
- Page 38 Table 7 Sensor Modbus register Tag name Register # Data type Length Description TEMPERATURE 40079 Integer Temperature signal in °C SENSOR ANGLE 40080 Unsigned integer Probe position signal in degrees FREQUENCY 40081 Integer Resonance frequency signal in hertz AMPL DIAG 40082 Integer Resonance voltage signal in volts...
