- Page 1 Instruction manual Power supply and readout units E-5700 series Doc. no.: 9.17.009F Date: 01-02-2008 ATTENTION Please read this instruction manual carefully before installing and operating the instrument. Not following the guidelines could result in personal injury and/or damage to the equipment.
- Page 2 BRONKHORST HIGH-TECH B.V.
- Page 3 Bronkhorst High-Tech B.V. February 2008 Warranty The products of Bronkhorst High-Tech B.V. are warranteed against defects in material and workmanship for a period of three years from the date of shipment provided they are used in accordance with the ordering specifications and not subjected to abuse or physical damage.
-
Page 4: Table Of Contents
BRONKHORST HIGH-TECH B.V. TABLE OF CONTENTS 1 Introduction General description..........................page 5 Model configuration..........................page 5 Power supply............................page 6 In/output signals ..........................page 6 1.4.1 Rearpanel connectors......................... page 6 1.4.2 Connection to measuring and controlling devices................page 6 1.4.3 Connection to remote equipment ....................... -
Page 5: Introduction
1 INTRODUCTION 1.1 General description The Bronkhorst HIGH-TECH B.V. basic module E-5700 has been designed for powering 2 thermal Mass Flow Controllers or Pressure Controllers with 0 - 5 (10 V) output/setpoint. The output signal is shown on a 3½ -digit voltmeter as 0 ... 100%. Either channel 1 or 2 can be selected by means of a two position switch on the front. -
Page 6: Power Supply
1 ch. 1 1.4.2 Connection to measuring and controlling devices The instrument connectors 1 and 2 are female sub-miniature 9-pin D-connectors. The pin designation is according to the BRONKHORST HIGH-TECH B.V. standard for analog instruments. Pin number description not used... -
Page 7: Analog Input/Output Signals
Analog output signals are available at pin 1 (+) for channel 1 and/or pin 2 (+) for channel 2 and 0 Vdc/common. Signals are according to one of the Bronkhorst HIGH-TECH B.V. standards. The model configuration contains a code, describing the input/output signals. -
Page 8: Specifications
BRONKHORST HIGH-TECH B.V. 1.5 Specifications 1.5.1 Housings 14 TE table top cassette 14 TE panel mount 14TE +0.8 Panel cut out 42 TE ½ 19" table top 42 TE ½ 19" rack mount page 8 9.17.009... -
Page 9: Specifications
BRONKHORST HIGH-TECH B.V. 1.5.2 Specifications Power supply 100 ... 240 Vac, 50 ... 60 Hz, 40 VA Signal input consult model configuration Signal output consult model configuration Connectors two 9-pin subminiature D-connectors (female) for instrument connection one 9-pin subminiature D-connector (female) for external output signal... -
Page 10: Installation
Should the packing box be damaged, then the local carrier must be notified at once regarding his liability, if so required. At the same time a report should be submitted to Bronkhorst HIGH-TECH B.V. Ruurlo Holland Remove the envelope containing the packing list; carefully remove the equipment from the packing box. do not discard spare or replacement parts with the packing material and inspect the contents for damaged or missing parts. -
Page 11: Recommended Spare Parts
