Summary of Contents for MusicSnail V10
- Page 1 MusicSnail Let life slower,You will be wonderful. USER MANUAL TWS Wireless earphone If you encounter any problems with the operation, please feel free to contact us. tp_msnail@163.com - 1 -...
- Page 2 Function description： Multi-function LED indicator button microphone Silicone ear cap Charging contact Micro USB charging Charging box battery indicator position - 2 -...
- Page 3 ("R" headphone LED indicator appears as red and blue alternately lit) Step 2: Open the mobile phone Bluetooth device, search for the pairing name "V10-R", and click Finish to connect. (Headphone LED indicator appears as blue slowly flashing) - 3 -...
- Page 4 Take the “L” earphone separately from the charging box and wait for 30 seconds. The headphone LED indicator flashes red and blue alternately. Turn on the "A" phone Bluetooth, search for the device, find "V10-L", and click Finish to connect.
-
Page 5: Method One
Restore factory settings. Method one Step 1: Remove the "L" headset from the charging box. Wait 30 seconds, when the LED indicator turns red and blue alternately, press the multi-function button 4 times (interval time is 0.5 seconds), the headphone LED indicator turns red and then goes out. - Page 6 Multi-function button operation instructions： Play/Pause Click the "R" or "L" headset multi-function button Switch songs (next song) Double-click the "L" headset multi-function button Switch songs (previous song) Double-click the "R" headset multi-function button Call response Click the "R" or "L" headset multi-function button Hang up the phone Click the "R"...
-
Page 7: Product Parameters
Product Parameters： Product model V10 TWS Wireless earphone Bluetooth version Realtek V5.0+EDR Talk time about 5 hours Music time about 5 hours Headphone tip language English Transmission distance Headphone charging time about 1 hours Charging time of charging box about 8 hours Single headphone weight 4.5g... - Page 8 Charging: (1) Headphone charging. The charging box has a built-in battery. When the charging box is fully charged, put the earphone into the charging box to charge the earphone. When the earphone is in the charging state, it always lights up red, the charging box is always bright blue; when the earphone is charged When saturated, it lights up in blue, turns off after 30 seconds, and the blue light of the charging box goes out.
- Page 9 Boot method: (1) Automatic boot. Open the top cover of the charging case, then pick up the two headphones, and the two headphones will automatically turn on. (There is a power-on tone) (2) Manual boot. When the earphone is not inside the charging box, you can manually touch the power on;...
- Page 10 Automatically connect back to the paired mobile phone after booting; (2) Over distance return. The main ear and the mobile phone can return to a certain distance within 5 minutes after disconnection; the main ear and the auxiliary ear can be connected back within a certain distance within 5 minutes after being disconnected;...
- Page 11 (6) Synchronous display. IOS system, headphone power synchronization display; IOS system, mobile phone volume adjustment synchronization display; (7) Charge reset. When the earphone is charged in the charging box, the earphone is restored to the original state before the power is turned on; (8) Low power alarm.
- Page 12 Warning and precautions 1: To prevent fire or shock hazard, do not expose this unit to rain moisture. 2: Do not place this unit directly onto furniture surfaces with any type of soft, porous , or sensitive finish.As with any rubber compound make with oils , the feet could cause marks or staining where the feet reside.
