iDPRT HP-1207WA-000R User Manual

Fixed barcode scanner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Fixed Barcode Scanner
HP-1207WA-000R
User Manual
Rev.1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HP-1207WA-000R and is the answer not in the manual?

Questions and answers

Related Manuals for iDPRT HP-1207WA-000R

Summary of Contents for iDPRT HP-1207WA-000R

  • Page 1 Fixed Barcode Scanner HP-1207WA-000R User Manual Rev.1.1...
  • Page 2 Disclaimer Please read all the contents of the manual carefully before using the products described in this manual to ensure the safe and effective use of the products. After reading, please keep this manual properly for the next time you use it. Not disassemble or tear the sealed bidding of the scanner on your own, otherwise our company shall not assume the responsibility of warranty or replacement of the scanner.
  • Page 3 Change Record Rev. Date Description 2018.11.14 First edition Add settings: 1. The number of multiple codes setting 2. Illumination light switch setting 3. Mobile performance setting 4. Data prefix and suffix setting 2020.06.16 5. Center aiming decode setting 6. Add multiple national keyboard barcodes 7.

  • Page 4: Table Of Contents

    CONTENT Chapter 1 Introduction ......................... 1 Appearance ............................ 2 Interface ............................3 Power on, Power off and Restart ....................4 Maintenance ..........................4 Barcode Read ..........................4 Use the Setting Barcode ......................... 5 Restore Factory Defaults ........................ 5 Chapter 2 Communication Interface ..................... 6 USB Interface ..........................
  • Page 5 UPC-A ........................... 19 Enable/Disable UPC-A ....................19 Transmit check character ..................... 20 Enable/Disable 2/5-bit Add-On code ................20 Transfer system character .................... 20 Code 39 ..........................21 Enable/Disable Code 39 ....................21 Check character verification and transmit ..............21 Enable/Disable code 39 Full ASCII................21 Convert Code 39 to Code32 ..................
  • Page 6 Gs1-128 emulation mode for UCC/EAN composite code ..........28 GS1 DataBar ......................... 29 Enable/Disable GS1 DataBar ..................29 Convert GS1 DataBar to UPC/ENA ................29 GS1 DataBar Limited ......................29 Enable/Disable GS1 DataBar Limited ................29 GS1 DataBar Expanded ......................29 Enable/Disable GS1 DataBar Expanded ...............
  • Page 7 Multi code quantity ......................39 Multi code sensitivity ......................39 Buzzer enable ........................39 The convert rate in HID mode ....................40 Timeout setting of the same barcode in non-single scan mode .......... 40 Sensitivity ..........................40 Center aiming decode setting ....................40 Barcode function settings ......................

  • Page 8: Chapter 1 Introduction

    Fixed Barcode Scanner User Manual Chapter 1 Introduction The scanner uses the international leading chip intelligent image read technology, and it mainly uses for image-based 2D scanner. 2D decoding chip combines the advanced image read algorithm with advanced chip design and manufacturing technology that greatly simplifies the design difficulty of 2D barcode to scan products, and establishes an excellent benchmark for high performance, high reliability and low power consumption of 2D l image products.

  • Page 9: Appearance

    Fixed Barcode Scanner User Manual Appearance ● Left View (Unit: mm) ● Top View (Unit: mm) ● Bottom View (Unit: mm)

  • Page 10: Interface

    Fixed Barcode Scanner User Manual Interface HP-1207WA-000R must be connected to a host. The host can be a PC, POS machine, or with a USB interface in any of the intelligent terminal.

  • Page 11: Power On, Power Off And Restart

    Fixed Barcode Scanner User Manual Power on, Power off and Restart Power on: power on automatically when the scanner is connected to the host. Power off: unplug the data cable. Restart: if the scanner stops responding to input or runs abnormally please re-plug the data cable. Maintenance ...

  • Page 12: Use The Setting Barcode

    Fixed Barcode Scanner User Manual Use the Setting Barcode Set the parameter to a special barcode whose barcode type is barcode128. When it scans to a barcode software that matches the setting type of setting, it will automatically enter the setting and does not send the results on the host.

  • Page 13: Chapter 2 Communication Interface

    Fixed Barcode Scanner User Manual Chapter 2 Communication Interface The scanner provides USB interface (optional) to connect to the host. Through communication interfaces, it can receive and read the data, control the scanner by sending the commands, and modify the parameter of scanner, etc. USB Interface HID Virtual Keyboard When using USB interface, the scanner can be simulated as a HID-KBW device.
  • Page 14 Fixed Barcode Scanner User Manual Danish Norwegian Spanish Dutch Hebrew Portuguese Latin(America) Czech_DEC Brazilian Greek_DEC Canadian (French) Hungarian Polish Slovakian_DEC Swedish...
  • Page 15 Fixed Barcode Scanner User Manual Turkish_Q Romanian Russian Turkis_F Japanese(ASCII) Swiss(French) USA(International) Slovenian Croatian Bosnian Macedonian Albanian Serbian(Latin) Serbian(Cyrillic) Czech_QWERTZ Czech_QWERTY Czech(Programmers) Estonian...
  • Page 16 Fixed Barcode Scanner User Manual Latvian Latvian_QWERT Lithuania Lithuanian (IBM) Slovakian_QWERTZ Slovakian_QWERTY Hungarian_101_Key Spanish(Variation) Bulgarian(Cyrillic) Bulgarian(Latin) Canadian(French_Legacy) Canadian(Multilingual) Italian_142 Polish_214 Polish_Programmers Brazilian_MS Greek_Polytonic Greek_220...
  • Page 17 Fixed Barcode Scanner User Manual Greek_319 Greek_Latin Greek_220_Latin Greek_319_Latin Greek_MS Russia_MS Russian(Typewriter) Thai(Pattachote) Thai(Kedmanee) Irish Maltese Icelandic Ukrainian Uzbek(Cyrillic) Kazakh Kyrgyz(Cyrillic)
  • Page 18 Fixed Barcode Scanner User Manual Azeri(Latin) Azeri(Cyrillic) Belarusian Faeroese Gaelic Tatar Mongolian(Cyrillic)

  • Page 19: Usb Virtual Serial Port

    Fixed Barcode Scanner User Manual USB Virtual Serial Port When the scanner uses a USB communication interface, but the host application uses serial communication to receive data, you can set the scanner to the USB virtual serial port. This function requires that be installed the appropriate driver on the host.

  • Page 20: Chapter 3 Scanning Mode

    Fixed Barcode Scanner User Manual Chapter 3 Scanning Mode Sense Mode In automatic sensing mode, the scanner will monitor the images being taken. When the scene is changed, it will read within the limited time of “single read time”. After reading the output information successfully or time out, it will re-enter the state of monitoring scene change.

  • Page 21: Continuous Mode

    Fixed Barcode Scanner User Manual  Single Reading Time In sensing reading mode, the parameter indicates the maximum time of allowing reading engine to continuously collect and identify barcode before reading successfully. After reading successfully or single read timeout, the reading engine will enter the interval of not collecting the read. The range of single read time is 0.1~9.9s, step length is 0.1s.

  • Page 22: Chapter 4 Illumination

    Fixed Barcode Scanner User Manual Chapter 4 Illumination Illumination There is a fill illuminating device on the scanner that is used to illuminate the reading area when reading. It can be set to turn off and fill illuminating level. (Please refer to Chapter 8 for the lighting level setting) Illumination ON Illumination OFF...

  • Page 23: Chapter 5 Symbologies

    Fixed Barcode Scanner User Manual Chapter 5 Symbologies Every symbology (barcode type) has its own unique attributes. This chapter provides programming barcodes for configuring the scanner so that it can identify various symbologies. It is recommended to disable those that are rarely used to increase the efficiency of the scanner. 1D Barcode Setting ENA-8 Enable/Disable EAN-8...

  • Page 24: Ena-13

    Fixed Barcode Scanner User Manual ENA-13 Enable/Disable EAN-13 Enable (Default) Disable Enable/Disable 2/5-bit Add-On code The 2/5-digit Add-On code refers to the 2/5-digit digital barcode added after the ordinary barcode. Enable (Default) Disable Auto UPC-E Enable/Disable UPC-E Enable (Default) Disable Transmit check character UPC-E barcode data is fixed to 8 characters, and the eighth character is the check bit, which is used to check the correctness of all 8 characters.

  • Page 25: Enable/Disable 2/5-Bit Add-On Code

    Fixed Barcode Scanner User Manual Enable/Disable 2/5-bit Add-On code The 2/5-digit Add-On code refers to the 2/5-digit digital barcode added after the ordinary barcode. Enable (Default) Disable Auto Convert UPC-E to UPC-A The chip can convert the decoding results of UPC-E type barcodes to UPC-A type barcodes according to standard algorithms.

  • Page 26: Upc-E1

    Fixed Barcode Scanner User Manual UPC-E1 Transmit system character (Default) Transmit system character and country code (“0” only for USA) Not transmit preamble Enable/Disable 2/5 Add-On code The 2/5-digit Add-On code refers to the 2/5-digit digital barcode added after the ordinary barcode. Enable (Default) Disable Auto...

  • Page 27: Transmit Check Character

    Fixed Barcode Scanner User Manual Transmit check character UPC-A bar code data is fixed to 13 characters, and the 13th character is check bit, which is used to check the correctness of all 13 characters. Transmit check character (Default) Disable Enable/Disable 2/5-bit Add-On code The 2/5-digit Add-On code refers to the 2/5-digit digital barcode added after the ordinary barcode.

  • Page 28: Code 39

    Fixed Barcode Scanner User Manual Code 39 Enable/Disable Code 39 Enable (Default) Disable Check character verification and transmit Code 39 barcode data does not contain a check character. If there is a check character, it is the last character of the data. A check character is a value calculated from all data to verify that the data is correct.

  • Page 29: Convert Code 39 To Code32

    Fixed Barcode Scanner User Manual Convert Code 39 to Code32 Enable Disable (Default) Code 32 prefix Enable add prefix character "a" Disable (Default) Code 93 Enable/Disable code 93 Enable (Default) Disable Code 11 Enable/Disable code 11 Enable Disable (Default) Check Setting Code 11 barcode data does not contain the check digit.

  • Page 30: Transmit Check Character

    Fixed Barcode Scanner User Manual Not check (Default) 1-bit check 2-bit check Transmit check character Transmit check character Disable (Default) Code 128 Enable/Disable code 128 Enable (Default) Disable Note: if this barcode is set to disable, the scanner will not be able to scan and switch the corresponding function settings.

  • Page 31: Codabar

    Fixed Barcode Scanner User Manual Codabar Enable/Disable Codabar Enable (Default) Disable Start and stop characters Enable CLSI Disable CLSI (Default) Enable this parameter to remove the start and stop characters, and insert spaces after the first, fifth and tenth characters of the 14-character Codabar barcode. Enable NOTIS Disable NOTIS (Default) Enable this parameter to remove the start and stop characters.

  • Page 32: Check Bit Algorithm

    Fixed Barcode Scanner User Manual 1-bit check 2-bit check Check bit algorithm 1 MSI MOD10/MOD10 (Default) 2 MSI MOD10/MOD11 Transmit check character Transmit check character Disable (Default) Interleaved 2 of 5 Enable/Disable Interleaved 2 of 5 Enable (Default) Disable Check and transmit character Interleaved 2 of 5 barcode data does not contain the check digit.

  • Page 33: Convert I 2 Of 5 To Ean-13

    Fixed Barcode Scanner User Manual Not check (Default) USS check OPCC check Transmit check character: Transmit check character Disable (Default) Convert I 2 of 5 to EAN-13 Convert I 2 of 5 to EAN-13 Disable (Default) Matrix 2 of 5 Enable/Disable Matrix 2 of 5 Enable Disable (Default)

  • Page 34: Industrial 2 Of 5

    Fixed Barcode Scanner User Manual Not check (Default) Check Transmit check character Transmit check character Disable (Default) Industrial 2 of 5 Enable/Disable Industrial 2 of 5 Enable Disable (Default) Standard 25 Enable/Disable Standard 25 Enable Disable (Default) ISSN Enable Disable (Default)

  • Page 35: Isbn

    Fixed Barcode Scanner User Manual ISBN Enable Disable (Default) Data bit setting Use 13 bits (Default) Use 10 bits ISBT 128 Enable/Disable ISBT 128 Enable (Default) Disable GS1 128 Enable/Disable GS1 128 Enable (Default) Disable Gs1-128 emulation mode for UCC/EAN composite code Disable (Default) Enable...

  • Page 36: Gs1 Databar

    Fixed Barcode Scanner User Manual GS1 DataBar Enable/Disable GS1 DataBar Enable (Default) Disable Convert GS1 DataBar to UPC/ENA Convert DataBar to UPC/ENA Disable (Default) GS1 DataBar Limited Enable/Disable GS1 DataBar Limited Enable Disable (Default) GS1 DataBar Expanded Enable/Disable GS1 DataBar Expanded Enable Disable (Default)

  • Page 37: 1D Barcode Inverse

    Fixed Barcode Scanner User Manual 1D Barcode Inverse Disable(Default) Enable Automatic detection 1D Barcode Anti-color Auto (Default) Disable...

  • Page 38: 2D Barcode Setting

    Fixed Barcode Scanner User Manual 2D Barcode Setting PDF417 Enable/Disable PDF417 Enable (Default) Disable Data Matrix Anti-color Auto (Default) Disable Only read Anti-color color Enable/Disable Data Matrix Enable (Default) Disable Mirror Images Auto (Default) Enable Disable...

  • Page 39: Inverse

    Fixed Barcode Scanner User Manual Inverse Disable (Default) Enable Auto Enable/Disable QR Enable (Default) Disable Enable/Disable Micro QR code (this setting is only valid when enable QR) Enable (Default) Disable Inverse Disable (Default) Enable Auto...

  • Page 40: Anti-Color

    Fixed Barcode Scanner User Manual Anti-color Auto (Default) Only read Anti-color color Disable Aztec Inverse Disable (Default) Enable Auto Anti-color Auto (Default) Only read Anti-color color Disable...

  • Page 41: Han Xin

    Fixed Barcode Scanner User Manual Han Xin Anti-color Auto (Default) Only read Anti-color color Disable Inverse Disable (Default) Enable Auto...

  • Page 42: Chapter 6 Troubleshooting

    Fixed Barcode Scanner User Manual Chapter 6 Troubleshooting Q: There are some barcodes cannot be scanned. A: Check the barcode type, open the barcode function; if it is verified, try to turn off. Q: The barcode data is incorrect. A: Check the error display of barcodes (all barcodes errors or specific barcode error) Q: Barcode can be read but not displayed.

  • Page 43: Chapter 7 Scanner Settings

    Fixed Barcode Scanner User Manual Chapter 7 Scanner Settings Barcode Setting Format Prefix Operand Data 5 BYTES 1 BYTE 1BYTE~250BYTE Set barcode Code 128 type Barcode Prefix Fixed prefix: +N+S- Operand The operand is the following command data Data Indicates parameter data carried by this command Version number——HYRS_RE...

  • Page 44: General Settings (Default Hid Single Scan Mode)

    Fixed Barcode Scanner User Manual General settings (default HID single scan mode) Host mode (CDC, HID, BT, COM） Operand: 0x41 USB Virtual Serial Port USB Virtual Keyboard General Serial Port Data 0x02 0x01 0x03 0x04 Set scanner interface mode Trigger mode (Single scanning, scanning continuously, auto sensing) Operand: 0x42 Button Trigger Light continuously...

  • Page 45: Data Prefix

    Fixed Barcode Scanner User Manual Data prefix Operand: 0x52 Disable Custom Define Data0 0x00(Default) 0x01~0xfd Data1 0x00 0x01~0xfd Note: 1. If the character set to be 0x20, you need to set the data = 0xFE. 2. If only one character is set, you need to set another to 0x00 Disable. Data suffix Operand: 0x45 Disable...

  • Page 46: Baud Rate Of Virtual Serial Port

    Fixed Barcode Scanner User Manual Baud rate of virtual serial port Operand: 0x48 115200 38400 19200 9600 4800 2400 1200 Data 0x00 0x01 0x02 0x03(Default) 0x04 0x05 0x06 Set serial port baud rate, this setting applies to USB virtual serial port and normal serial port only. Check bit of virtual serial port Operand: 0x49 Non-Check...

  • Page 47: The Convert Rate In Hid Mode

    Fixed Barcode Scanner User Manual The convert rate in HID mode Operand: 0x4E Fast Normal Slow Data 0x01 0x02 (Default) 0x0a Timeout setting of the same barcode in non-single scan mode Operand: 0x4F Variable Data 0x00~0x63 Data: 0x00 indicates that there is no Timeout Invalid. If there is a barcode, it can still output. 0x01 indicates the timeout of 100ms.
  • Page 48 Fixed Barcode Scanner User Manual  Commands that support only barcodes Set F1~F12 (only analog key output is supported) Set the barcode content as follows: Name F1 Value 0x16 0x17 0x18 0x19 0x1A 0x1B 0x1C 0x1D 0x1E 0x1 0x10 0x15 Users can directly write the appropriate data to generate the appropriate barcode, then scan the barcode can achieve the function of virtual key output.

  • Page 49: Barcode Function Settings

    Fixed Barcode Scanner User Manual Barcode function settings ITF cut the first few bits of data Operand: 0x55 Enable Disable Data 0x01 (Default) 0x02~0x32 Note: 0x02 indicates cutting the first data; 0x32 indicates cutting 49 data from the front. Disable Cut the first data Cut the top 5 data Convert grouping character to space...

  • Page 50: Skip The Number Of Characters Before Barcode Data

    Fixed Barcode Scanner User Manual Skip the number of characters before barcode data Operand: 0x59 data: *0: Do not skip barcode data 1-31: skip the number of characters before barcode data *Not skip barcode data Skip 1 character before barcode data Skip 5 character before barcode data Skip the number of characters after barcode data operand: 0x5A...

  • Page 51: Insert Characters Into Barcode Data

    Fixed Barcode Scanner User Manual Insert characters into barcode data (up to 8 characters) Operand: 0x5C Data: Data0 ~ data1: the position of the inserted data in the barcode data Data2: data inserted in corresponding position (range: 0x01 ~ 0x7F) Note: Data0 ~ data1 Calculation method: data0 = (x/64) +0x20 data1 = (x%64) +0x20, where x is the position of the character to be inserted (range: 1 ~ 6143).

  • Page 52: Appendix Ⅰ Barcode Enabling Settings

    Fixed Barcode Scanner User Manual Appendix Ⅰ Barcode Enabling Settings Operand: 0x40 Data: 2BYTE data Set the barcode enabling parameter, DATA 0 is the barcode parameter, DATA 1 is the barcode parameter variable. The following is the parameter default value. 0 is OFF, 1 is ON Barcode Parameter Parameter Barcode Type...
  • Page 53 Fixed Barcode Scanner User Manual Netherlands KIX Code 0x1B Enable USPS 4CB 0x1C Disable UPU FICS Postal 0x1D Disable GS1 DataBar-14 0x1E Enable GS1 DataBar Limited 0x1F Disable GS1 DataBar Expanded 0x20 Disable 0x21 Composlte CC-C Disable 0x22 Composlte CC-A/B Disable 0x23 Composlte TLC-39...

  • Page 54: Appendix Ⅱ Data Code Prefix And Suffix

    Fixed Barcode Scanner User Manual Appendix Ⅱ Data code prefix and suffix For example: set the prefix character @！ Steps: 1. Scan the setting barcode【Enable prefix 1】--> Scan the setting barcode【@】 Prefix added characters @ 2. Scan the setting barcode【Enable prefix 2】--> Scan the setting barcode【!】 Prefix added characters @！...
  • Page 55 Fixed Barcode Scanner User Manual ■ Prefix and Suffix " &...
  • Page 56 Fixed Barcode Scanner User Manual ： ； < >...
  • Page 57 Fixed Barcode Scanner User Manual...
  • Page 58 Fixed Barcode Scanner User Manual ‘...
  • Page 59 Fixed Barcode Scanner User Manual...
  • Page 60 Fixed Barcode Scanner User Manual...

  • Page 61: Appendix Ⅲ Ascii Code Table

    Fixed Barcode Scanner User Manual Appendix Ⅲ ASCII Code Table Hexadecimal Decimal Character NUL （Null char.） SOH （Start of Header） STX （Start of Text） ETX （End of Text） EOT （End of Transmission) ENQ （Enquiry） ACK （Acknowledgment） BEL （Bell） BS （Backspace） HT （Horizontal Tab）...
  • Page 62 Fixed Barcode Scanner User Manual ! （Exclamation Mark） " （Double Quote） # （Number Sign） $ （Dollar Sign） % （Percent） & （Ampersand） ` （Single Quote） ( （Right / Closing Parenthesis） ) （Right / Closing Parenthesis） * （Asterisk） + （Plus） , （Comma） - （Minus / Dash）...
  • Page 63 Fixed Barcode Scanner User Manual [ （Left / Opening Bracket） \ （Back Slash） ] （Right / Closing Bracket） ^ （Caret / Circumflex） _ （Underscore） ' （Grave Accent）...
  • Page 64 Fixed Barcode Scanner User Manual { （Left/ Opening Brace） | （Vertical Bar） } （Right/Closing Brace） ~ （Tilde） DEL （Delete）...
