Spectec XP2 Series Instruction Manual

THUNDERBIRD INTERNATIONAL CORPORATION
P.O. Box 360, Emigrant, MT 59027-0360
406-333-4967 ∙ FAX 406-333-4259
Engineering Approval:
Introduction
SPECTEC's Explosion Proof / Flame Proof sensors are designed for
installation in hazardous locations. They are offered in a wide
variety of configurations. See the XP2 Bulletin for specifications
and configuration options.
Marking
Unit Type No.: XP2-xxxxxx
Date Code: WW/YY (Week/Year)
Conduit Size: 1/2- NPT or M20x1.5
Electrical Rating: xx to xx V DC @ ≤xx mA (marked according to
Codes: CL I DIV 1 GP ABCD T6...T3
CL I ZN 1 AEx/Ex db IIC T6...T3 Gb
T3@ Ta = -50°C...+140°C (marked)
T4@ Ta = -50°C...+112°C
T5@ Ta = -50°C...+77°C
T6@ Ta = -50°C...+62°C
II 2 G Ex db IIC T6...T3 Gb
T3@ Ta = -55°C...+140°C (marked)
T4@ Ta = -55°C...+112°C
T5@ Ta = -55°C...+77°C
T6@ Ta = -55°C...+62°C
Certificate No.: FM16US0288X & FM16CA0147X
FM16ATEX0086X & IECEx FMG 16.0035X
CE Marking: 2809
Warnings: SEAL ALL CONDUITS WITHIN 18 INCHES
DISCONNECT POWER BEFORE OPENING
FERMER TOUS LES CONDUITS SOUS 18 POUCES
(.45m) MAXIMUM
DÉBRANCHER L'ALIMENTATION ELECTRIQUE
AVANT L'OUVERTURE
Specific Conditions of Use
1. Refer to these instructions for complete temperature ratings
and suitability.
2. No external grounding is provided. The sensor must be
mounted as part of a bonded structure.
3. The wiring shall be mechanically protected as required by the
applicable area electrical code and shall be terminated in a
suitable terminal or junction facility.
Warnings
1. A poured conduit seal must be applied within 18 inches
(0.45m) of the sensor.
2. Disconnect power before opening or removing the sensor.
PROPRIETARY, COPYRIGHTED INFORMATION DO NOT DUPLICATE OR DISTRIBUTE TO THIRD PARITES UNLESS AUTHORIZED BY SPECTEC
Approval agency controlled document. Do not alter without authorization.
JE
Date: 03-18-2019
sensor type, see XP2 Bulletin)
INSTRUCTION MANUAL
XP2 Series, Conduit Style
Active Speed Sensors
Compatibility
Refer to the listed certification and temperature ratings for
suitability. The intended environmental and operating conditions
should be verified to be in compliance with these ratings.
Housing: 303 or 304 series Stainless Steel
Cable: PTFE insulated (Polytetrafluoroethylene)
or FEP insulated (Fluorinated ethylene propylene)
NOTE: For Canadian installations, only female NPT or metric entries
are permissible per CSA C22.2 No. 0.5 & 30.
Type Approval Standards
The XP2 product series have certificates issued by FM Approvals
and have been approved to the following standards:
United States of America (USA) Standards:
FM Class 3600:2011
FM Class 3615:2006
FM Class 3810:2005
ANSI/ISA61010-1:2012
ANSI/ISA60079-0:2013
ANIS/UL60079-1:2015
Canadian Standards:
CSA C22.2 No. 0.4-04: R2013
CSA C22.2 No. 0.5:2016
CSA C22.2 No. 61010-1:2012
CSA C22.2 No. 30-M1986:R2012
CSA C22.2 No. 60079-0:2012
CSA C22.2 No. 60079-1:2016
ATEX Standards:
EN60079-0:2012 + A11:2013
EN60079-1:2014
IECEX Standards:
IEC60079-0:2011
IEC60079-1:2014
Installation Requirements
The installation shall be carried out by suitably trained personnel.
The sensor must be installed in accordance with the latest issue of
the following standards:
US installations:
follow the National Electrical Code ANSI/NFPA 70,
Canadian installations:
follow the Canadian Electrical Code CSA C22.1,
ATEX installations: follow EN 60079-14,
IECEx installations: follow IEC 60079-14.
The installation must also be in accordance with any local codes
and national regulations that apply.
85047X
Revision: 1
General Requirements
Explosionproof General Requirements
General Requirements
Safety General Requirements
General Requirements
Flameproof Enclosures 'd'
Bonding of Electrical Equipment
Threaded Conduit Entries
Safety General Requirements
Explosion-proof Encl.
General Requirements
Flameproof Enclosures 'd'
General Requirements
Flameproof Enclosures 'd'
General Requirements
Flameproof Enclosures 'd'
Approved May 9th, 2019
Page 1 of 3
