TH-P58S20M
Model No.
TH-P58S20P
TH-P58S20R
GPF13DA Chassis
© Panasonic Corporation 2010.
Unauthorized copying and distribution is a violation
of law.
ORDER NO.ITD1009077CE
Plasma Television

Advertisement

Table of Contents
loading

Related Manuals for Panasonic TH-P58S20M

Summary of Contents for Panasonic TH-P58S20M

  • Page 1 ORDER NO.ITD1009077CE Plasma Television TH-P58S20M Model No. TH-P58S20P TH-P58S20R GPF13DA Chassis © Panasonic Corporation 2010. Unauthorized copying and distribution is a violation of law.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions -------------------------------------------------------------- 12.5. P(SUB)-Board Schematic Diagram ------------------------------ 1.1. General Guidelines ----------------------------------------------------- 12.6. A-Board (1/19) Schematic Diagram ------------------------------ 1.2. Touch-Current Check--------------------------------------------------- 12.7. A-Board (2/19) Schematic Diagram ------------------------------ 2 Warning ----------------------------------------------------------------------------- 12.8. A-Board (3/19) Schematic Diagram ------------------------------ 2.1.

  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1. When conducting repairs and servicing, do not attempt to modify the equipment, its parts or its materials. 2. When wiring units (with cables, flexible cables or lead wires) are supplied as repair parts and only one wire or some of the wires have been broken or disconnected, do not attempt to repair or re-wire the units.

  • Page 4: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor [chip] components.

  • Page 5: About Lead Free Solder (Pbf)

    2.2. About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu). That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.

  • Page 6: Service Navigation

    3 Service Navigation 3.1. PCB Layout Board Name Function Board Name Function Power Supply Data Driver (Lower Right) Data Driver (Lower Center) DC-DC Converter, Tuner Data Driver (Lower Left) Speaker out, AV Terminal, HDMI in, SD Card Scan Drive Digital Signal Processor, Peaks Sustain Drive Format Converter, Plasma AI, Sub-Field Processor Sustain out (Lower)

  • Page 7: Applicable Signals

    3.2. Applicable signals COMPONENT (Y, P ), HDMI * Mark: Applicable input signal. Signal name COMPONENT HDMI 525 (480) / 60i 525 (480) / 60p 625 (576) / 50i 625 (576) / 50p 750 (720) / 60p 750 (720) / 50p 1,125 (1,080) / 60i 1,125 (1,080) / 50i 1,125 (1,080) / 60p...

  • Page 8: Specifications

    4 Specifications Power Source AC 220-240 V, 50 / 60 Hz (M/R) AC 110-240 V, 50 / 60 Hz (P) Power Power rating 560 W (M/R) 570 W (P) Standby condition 0.4 W Display panel Aspect Ratio 16:9 Visible screen size 147 cm (diagonal) 1,284 mm (W) ×...
  • Page 9 SD Card slot × 1 Card slot USB 2.0 Type A connector DC 5V, Max 500 mA Dimensions (W × H × D) 1,424 mm × 933 mm × 387 mm (With Pedestal) 1,424 mm × 882 mm × 104 mm (TV only) Mass 48.5 kg Net (With Pedestal) 46.0 kg Net (TV only)

  • Page 10: Service Mode

    5 Service Mode 5.1. How to enter into Service Mode While pressing [VOLUME ( - )] button of the main unit, press [RECALL] button of the remote control three times within 2 seconds. 5.1.1. Key command [1] button...Main items Selection in forward direction [2] button...Main items Selection in reverse direction [3] button...Sub items Selection in forward direction [4] button...Sub items Selection in reverse direction...
  • Page 11 5.1.2. Contents of adjustment mode • Value is shown as a hexadecimal number. • Preset value differs depending on models. • After entering the adjustment mode, take note of the value in each item before starting adjustment. 5.1.3. How to exit Switch off the power with the [POWER] button on the main unit or the [POWER] button on the remote control.

  • Page 12: Option - Mirror

    5.2. Option - Mirror Picture can be reversed left and right or up and down. 00 : Default (Normal picture is displayed) 01 : Picture is reversed left and right. 02 : Picture is reversed up and down. Hint : If the defective symptom (e.g. Vertical bar or Horizontal bar) is moved by selection of this mirror, the possible cause is in A-board.

  • Page 13: Hotel Mode

    5.4. Hotel mode 1. Purpose Restrict a function for hotels. item Function 2. Access command to the Hotel mode setup menu Hotel Mode Select hotel mode ON/OFF In order to display the Hotel mode setup menu, please Initial INPUT Select input signal modes. enter the following command (within 2 second).

  • Page 14: Data Copy By Sd Card

    5.5. Data Copy by SD Card 5.5.1. Purpose (a) Board replacement (Copy the data when exchanging A-board): When exchanging A-board, the data in original A-board can be copied to SD card and then copy to new A-board. (b) Hotel (Copy the data when installing a number of units in hotel or any facility): When installing a number of units in hotel or any facility, the data in master TV can be copied to SD card and then copy to other TVs.
  • Page 15 5.5.3. Data copy from TV set to SD Card 1. Turn on the TV set. 2. Insert SD card with a startup file (pwd file) to SD slot. On-screen Display will be appeared according to the startup file automatically. 3. Input a following password for (a) or (b) by using remote control. (a) For Board replacement : 2770 (b) For Hotel : 4850 Data will be copied from TV set to SD card.
  • Page 16 5.5.4. Data copy from SD Card to TV set 1. Turn on the TV set. 2. Insert SD card with Data to SD slot. On-screen Display will be appeared according to the Data folder automatically. 3. Input a following password for (a) or (b) by using remote control. (a) For Board replacement : 2771 (b) For Hotel : 4851 Data will be copied from SD card to TV set.

  • Page 17: Troubleshooting Guide

    6 Troubleshooting Guide Use the self-check function to test the unit. 1. Checking the IIC bus lines 2. Power LED Blinking timing 6.1. Check of the IIC bus lines 6.1.1. How to access Self-check indication only: Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [OK] button on the remote control for more than 3 seconds.

  • Page 18: Power Led Blinking Timing Chart

    6.2. Power LED Blinking timing chart 1. Subject Information of LED Flashing timing chart. 2. Contents When an abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the defective block can be identified by the number of blinks of the Power LED on the front panel of the unit.

  • Page 19: No Power

    6.3. No Power First check point There are following 3 states of No Power indication by power LED. 1. No lit. 2. Green is lit then turns red blinking a few seconds later. (See 6.2.) 3. Only red is lit.

  • Page 20: No Picture

    6.4. No Picture...

  • Page 21: Local Screen Failure

    6.5. Local screen failure Plasma display may have local area failure on the screen. Fig-1 is the possible defect P.C.B. for each local area. Fig-1...

  • Page 22: Service Fixture & Tools

    7 Service Fixture & Tools 7.1. SC jig Purpose: To find the failure board (SC or SU/SD) when the power LED is blinking 7 times. SC jig: Jumper connector to connect to SC50 connector on SC board Part number: TZSC09187 How to use: Caution: Remove SC jig from SC board after inspection.

  • Page 23: Disassembly And Assembly Instructions

    8 Disassembly and Assembly Instructions 8.1. Remove the Rear cover 8.4. Remove Side terminal cover and the Rear AV panel 1. See PCB Layout (Section 3) 8.2. Remove the AC inlet 1. Remove the claws (×2 2. Remove the Side terminal cover. Caution: To remove P.C.B.

  • Page 24: Remove The Tuner Unit

    8.5. Remove the Tuner unit 8.7. Remove the Speakers 1. Remove the Side terminal cover and the Rear AV panel. 1. Unlock the cable clampers to free the cable. (See section 8.4.) 2. Disconnect the Speaker terminal. 2. Unlock the cable clampers to free the cable. 3.

  • Page 25: Remove The Sd-Board

    8.9. Remove the SD-Board 8.11. Remove the SS2-Board 1. Remove the flexible cables (SD1, SD2, SD3, SD4 and 1. Remove the Tuner unit. (See section 8.5.) SD5) connected to the SD-Board. 2. Disconnect the bridge connector (SS03-SS22) and dis- 2. Remove the flexible cable (SU11-SD11) and the bridge connect the flexible cable (SS57).

  • Page 26: Remove The Support Metal

    8.13. Remove the Support metal 8.15. Remove the C1-Board 1. Remove the Hanger metal R and Stand bracket R. (See 1. Remove the screws (×6 section 8.14.) 2. Remove the Support metal. 2. Remove the flexible cable holder fastening screws (×10 3.

  • Page 27: Remove The Plasma Panel Section From The Cabinet Assy (Glass)

    8.18. Remove the Plasma panel sec- 8.19. Remove the Glass holders tion from the Cabinet assy 1. Remove the Cabinet assy. (See section 8.18.) , ×16 2. Remove the screws (×14 (glass) 3. Remove the Glass holder top rear and Glass holder bot- 1.

  • Page 28: Remove The S-Board

    8.20. Remove the S-Board 8.22. Replace the plasma panel 1. Remove the Glass holders. (See section 8.19.) Caution: A new plasma panel itself without Hanger metals is 2. Remove the screws (×2 ) and remove the S-Board fragile. unit. To avoid the damage to new plasma panel, carry a new plasma panel taking hold of the Hanger metals after assembling the Hanger metals and the Stand brackets.

  • Page 29: Measurements And Adjustments

    9 Measurements and Adjustments 9.1. Adjustment 9.1.1. Vsus selection Caution: When Plasma panel or A-board is replaced, Vsus should be set to LOW or HIGH. Procedure 1. Go into main item [VSUS] in Service Mode. LOW or HIGH will be displayed. 2.
  • Page 30 9.1.2. Sub-Contrast adjustment Name of measuring instrument Connection Remarks RF generator Base Band signal generator HD signal generator Steps Remarks Adjustment of TV (RF system) Note: Sub-contrast adjustment is unadjusted for AV/ HD input. 1. Receive a RF PAL 100% Full White or Split Colour bar shown as below. But, when needing the adjustment cho- sen manually, please refer to [ alterna- tive method ].
  • Page 31 Steps Remarks Another procedure Adjustment of AV system 1. PAL 100% Full White or Split Colour bar receive AV1(or AV2), shown as below. 2. Goes into service mode. 3. Push [ 1 ] or [ 2 ] key, and goes into adjustment mode for [ Contrast ]. Adjustment 1.
  • Page 32 9.1.3. White balance adjustment Name of measuring instrument Connection Remarks W/ B pattern Panel surface Color analyzer (Minolta CA-100 or equivalent) Steps Remarks • Make sure the front panel to be used on the final set is fitted. Picture menu : Dynamic •...

  • Page 33: Block Diagram

    10 Block Diagram 10.1. Main Block Diagram DIGITAL SIGNAL PROCESSOR TMDS DATA HDMI1 HDMI I/F TMDS DATA HDMI3 RECEIVER TMDS DATA SD CARD DATA HDMI2 SD CARD SD CARD DATA SLOT PEAKS-sLD TUNER SIF I/F EEPROM Y/PR/PB Y/PR/PB V/Y/PB/PR VCC SOS AV I/O (LED:12TIMES) (LED:10TIMES)

  • Page 34: Block (1/4) Diagram

    10.2. Block (1/4) Diagram SPEAKER_L SPEAKER_R D3300 OPTICAL JK8850 JK4700 JK4701 JK4702 AUDIO TU2901B JK8801 DIGITAL SIGNAL PROCESSOR SD CARD ANT IN HDMI IN 1 HDMI IN 2 HDMI IN 3 TUNER IIC2 IC8851 IIC_TU IC2301 AUDIO AMP SOUND15V D2014 SUB3.3V Q2301 SOUND...

  • Page 35: Block (2/4) Diagram

    10.3. Block (2/4) Diagram DIGITAL SIGNAL PROCESSOR IC9300 PD4H VIDEO DATA PLASMA AI VIDEO DATA LVDS DATA CPG with SS H/V Sync Control VIDEO DATA Sub Filed Processor P+3.3V IC9304 P+3.3V ADDR/DATA FLASH IIC0 FLASH I/F MEMORY P_S0 CONTROL DATA P_S0 P_S1 DISCHARGE CONTROL...

  • Page 36: Block (3/4) Diagram

    10.4. Block (3/4) Diagram POWER SUPPLY COLD COLD K802 RUSH RELAY1_ON F801 10A 250V RF801 K805 MAIN RELAY1_ON STB_IN RECTIFIER D803 L803 Vsus L801 5A 250V Vsus Q901,Q902 F901 Q804, Q806 F802 RESONANCE CONTROL T901 10A 250V Vsus VR951 VDET Vsen IC901 IC801...

  • Page 37: Block (4/4) Diagram

    10.5. Block (4/4) Diagram SCAN DRIVE TPVSUS TP59,TP60 Vsus TP61,TP62 Vsus IC16771 D16618 F16V SC JIG Vad+5V D16662 Q16661 SUSTAIN DRIVE IC16661 Q16668 SCAN OUT (UPPER) PC16461 PC16603 Q16607 CERS COMPARATOR TPVSUS PHOTO COUPLER PHOTO D16316 Q16608 COUPLER PC16684 IC14901,02 Vsus CPH1 CRC1...

  • Page 39: Wiring Connection Diagram

    11 Wiring Connection Diagram 11.1. Caution statement. Caution: Please confirm that all flexible cables are assembled correctly. Also make sure that they are locked in the connectors. Verify by giving the flexible cables a very slight pull. 11.2. Wiring (1)

  • Page 40: Wiring (2)

    11.3. Wiring (2)

  • Page 41: Wiring (3)

    11.4. Wiring (3)

  • Page 42: Wiring (4)

    11.5. Wiring (4)

  • Page 43: Wiring (5)

    11.6. Wiring (5) 11.7. Wiring (6)

  • Page 45: Schematic Diagram

    12 Schematic Diagram 12.1. Schematic Diagram Note...

  • Page 46: P(Main)-Board (1/3) Schematic Diagram

    12.2. P(MAIN)-Board (1/3) Schematic Diagram COLD P(SUB)-BOARD (P51) P(SUB)-BOARD (P53) COLD F_STB ERROR DET STB CONTROL P(MAIN)-BOARD ETX2MM812MSM (1/3) COLD...

  • Page 47: P(Main)-Board (2/3) Schematic Diagram

    12.3. P(MAIN)-Board (2/3) Schematic Diagram COLD SS-BOARD (SS11) MULTI POWER CONTROL Vsus Vsus ERROR DET C3-BOARD (C35) NO USE CONTROL COMPARATOR A-BOARD (A6) P(MAIN)-BOARD ETX2MM812MSM (2/3) +15V CONTROL COLD...

  • Page 48: P(Main)-Board (3/3) Schematic Diagram

    12.4. P(MAIN)-Board (3/3) Schematic Diagram NO USE A-BOARD (A7/S1B) POWER MICOM P(MAIN)-BOARD ETX2MM812MSM (3/3) P(SUB)-BOARD (P55)

  • Page 49: P(Sub)-Board Schematic Diagram

    12.5. P(SUB)-Board Schematic Diagram P(MAIN)-BOARD (P52) P(MAIN)-BOARD (P54) COLD SC-BOARD (SC2) Vsus POWER CONTROL Vsus Vsus ERROR DET P(SUB)-BOARD ETX2MM812MSS P(MAIN)-BOARD (P56) COLD COMPARATOR...

  • Page 50: A-Board (1/19) Schematic Diagram

    12.6. A-Board (1/19) Schematic Diagram A-BOARD (1/19) R0900 SUB3.3V TO 3,12/19 XRST R0901 R0905 SBT1 R0902 EXB28V680JX TRST TO 3/19 R0903 C0900 R0910 R0912 R0913 R0911 0.1u SUB3.3V P3.3V SUB3.3V R0948 R0949 2.2k 2.2k R0966 R0967 R0980 R0981 4.7k 4.7k 4.7k 4.7k CN0101...

  • Page 51: A-Board (2/19) Schematic Diagram

    12.7. A-Board (2/19) Schematic Diagram A-BOARD (2/19) Peaks-COMMON Achip RESET IF I/F Analog Audio In I/F TO 8/19 A_MUTE *IC8001 A_MUTE IC8001 TO 12/19 NRST *IC8001 NRST *IC8001 FEAINN C10_BIAS *IC8001 BIAS *IC8001 LIN1_LP *IC8001 FEAINP MN2WS0125FE 18/19 D10_BIAS2 *IC8001 BIAS2 *IC8001 LIN_LN...

  • Page 52: A-Board (3/19) Schematic Diagram

    12.8. A-Board (3/19) Schematic Diagram A-BOARD (3/19) Peaks-COMMON IC8001 MN2WS0125FE PEAKS-SLD Dchip DDR MONITOR CPU BUS I/F RESET Analog Video Out I/F LVDS I/F TO 1,3,12/19 SUB3.3V XRST *IC8001 XRST *IC8001 *IC8001 *IC8001 AA31 MMDQ6 *IC8001 *IC8001 TA1N *IC8001 TA1N *IC8001 AA32 MMDQ13...

  • Page 53: A-Board (4/19) Schematic Diagram

    12.9. A-Board (4/19) Schematic Diagram A-BOARD (4/19) Peaks-DEST 8730-8799 TP8730 SUB3.3V R8619 TO 3,4,9/19 TO 3,4,9/19 VDACO VDACO ECLK TO 3/19 R8621 R8664 XECS1 R8733 R8655 XECS2 AA_XECS2 TO 5/19 R8656 R8652 TO 3,4/19 XECS3 R8622 R8649 SUB3.3V R8607 R8618 XERE TO 3/19 R8625...

  • Page 54: A-Board (5/19) Schematic Diagram

    12.10. A-Board (5/19) Schematic Diagram A-BOARD (5/19) Peaks-MODEL USB 5V *IC8851 SUB5V C0DBZYY00350 *L8851 J0JHC0000045 *C8864 *C8865 *C8868 *C8869 0.1u TO 3,6/19 LOSDOUT1 *R8880 DeMPX ED[15-0] --> EA[23-8] 4.7k R8918 EXB2HV680JV AA_ED0 AA_ED1 *JK8801 AA_ED2 K1FY104B0039 AA_ED3 R8922 AA_ED4 EXB2HVR000V *R8881 TO 4/19 AA_XIRQ6...

  • Page 55: A-Board (6/19) Schematic Diagram

    12.11. A-Board (6/19) Schematic Diagram TO Sheet Peaks-COMMON TO Sheet PANEL-D A-BOARD (6/19) Standby MPU SUB5V R1519 STMGPIO2 XRST_SYS STMSBT0 SG-SUB5V/SUB12V_SENSE R1559 SG-PD4H_XRST_SYS/PANEL_TEST_ON R1518 Reset Release 3,6/19 R1562 3,6/19 TO 13/19 EA10 SUB3.3V PG-PD4H_NCS / SD_LED_ON R1520 STMGPIO0 SG-SUB3.3V_SENSE R1521 100k R1564 OSD_VIN...

  • Page 56: A-Board (7/19) Schematic Diagram

    12.12. A-Board (7/19) Schematic Diagram Peaks-Common AVSW A-BOARD (7/19) A-Chip_V PC_HS PC_HS PC_HS 2,7,9/19 PC_VS PC_VS 2,7,9/19 PC_VS C4662 R4655 6.3V MAIN_Y/CVBS R4668 C4663 6.3V C4664 R4659 6.3V PB/C TO 9/19 MAIN_PB/C 2/19 R4703 R4670 Q4700 C4665 6.3V DSC200100L SG-HPD0 R4705 R4706 C4701...

  • Page 57: A-Board (8/19) Schematic Diagram

    12.13. A-Board (8/19) Schematic Diagram A-BOARD (8/19) A-Chip_A SUB5V TO Sheet TUNER TO Sheet Peaks-COMMON R2101 R2121 R2135 3.3k C2107 R2139 R2103 R2107 Q2109 TO 11/19 SIFINP DSA200100L R2110 R2102 C2110 C2104 TO 2/19 4.7k 0.1u Q2101 R2104 DSA200100L 1.2k C2108 SUB3.3V SIFINN...

  • Page 58: A-Board (9/19) Schematic Diagram

    12.14. A-Board (9/19) Schematic Diagram AV-SW A-BOARD (9/19) A_AV1_V__TERMINAL A_AV1C_YSW__TERMINAL E_AV1_VIN(20P)/A_AV2_V__TERMINAL E_AV1_VOUT(19P)/A_VOUT__TERMINAL TO 10/19 JK3304 K1FY315A0008 E_AV1_LIN(_6PIN)/A_AV2_L__TERMINAL E_AV1_RIN(_2PIN)/A_AV2_R__TERMINAL PC_R_TERMINAL < JK3107 K4AK13B00006 PC_G_TERMINAL SIDE_HP_L_TERMINAL SIDE_HP_R_TERMINAL TO 10/19 PC_B_TERMINAL SIDE_HP_GND Y-SW V-SW PC_HD_TERMINAL TO 10/19 E_YPBPR_Y/A_AV1C_Y__TERMINAL YPBPR SIDE_VIN_TERMINAL TO 9/19 E_YPBPR_PB/A_AV1C_PB__TERMINAL PC_VD_TERMINAL SIDE_LIN_TERMINAL E_YPBPR_PR/A_AV1C_PR__TERMINAL...

  • Page 59: A-Board (10/19) Schematic Diagram

    12.15. A-Board (10/19) Schematic Diagram AV-SW A-BOARD (10/19) AUDIO VIDEO IN SUB5V A_AV2_Vi A_AV2_LRi D3109 C3123 C3149 L3114 R3225 DZ2J140M0L R3127 L3107 R3152 R3173 J0JYC0000331 J0JYC0000331 PC_B TO 9/19 PC_B_TERMINAL AVSW_R099PIN_BIN E_AV1_VIN(20P)/A_AV2_V__TERMINAL AVSW_R079PIN_CVBSIN6 TO 9/19 E_AV1_LIN(_6PIN)/A_AV2_L__TERMINAL AVSW_R062PIN_L3IN C3137 R3104 C3117 R3165 R3144 560p...

  • Page 60: A-Board (11/19) Schematic Diagram

    12.16. A-Board (11/19) Schematic Diagram A-BOARD (11/19) TUNER TO Peaks-COMMON TO Panel-D TP4000 TE2P TE2P RE_O+(LSB) TE2N TE2N RE_O-(LSB) TP4001 TP4002 TD2P TD2P RD_O+ R4010 TP4003 TD2N TD2N RD_O- CH1VAL DRVMUTE TO 13/19 DISPEN R4011 TP4004 TCLK2P TCLK2P RCLK_O+ TP4005 TCLK2N TCLK2N RCLK_O-...

  • Page 61: A-Board (12/19) Schematic Diagram

    12.17. A-Board (12/19) Schematic Diagram A-BOARD (12/19) Analog-ASIC MUTE Peaks-RESET Sheet AVSW-MODEL Sheet STB-RESET-LCD TO Sheet GENX-DEST Q5051 DSA200100L R5151 SET RESET : L TO 10/19 TO 3,6/19 MONITOROUT_MUTE HP_MUTE_CTL TO 8,12/19 SG-DTV_XRST STMGPIO6 MUTE OPERATE C5050 R5154 4.7u SUB3.3V TO Sheet Peaks-COMMON TP5150 R5153...

  • Page 62: A-Board (13/19) Schematic Diagram

    12.18. A-Board (13/19) Schematic Diagram A-BOARD (13/19) Panel P15V C9812 C9813 TO 3,11/19 IC9801 C0DBAYY00462 C9811 0.1u BOOT R9920 TP9203 C9816 C9809 L9801 R9879 G1C100MA0416 0.01u 1000p R9103 R9104 R9107 COMP R9899 3.3k R9878 R9014 R9877 5.6k R9111 P15V *IC9803 C0DBAYY00462 *C9829 *C9827...

  • Page 63: A-Board (14/19) Schematic Diagram

    12.19. A-Board (14/19) Schematic Diagram *IC9300 C9301 A-BOARD (14/19) Panel-D IC9300 R9321 C1AB00003258 P3.3V PD4H P_S0 C9302 *IC9300 DCCOP40 R9320 P_S1 1.5k *IC9300 DCCOP41 R9323 *IC9300 DD1_2P DD7_2P DD13_2P P3.3V TP9300 *IC9300 LVDOD0P *IC9300 AJ12 LVDOD12P *IC9300 AJ26 LVDOD24P FLASH DD1_2N DD7_2N DD13_2N...

  • Page 64: A-Board (15/19) Schematic Diagram

    12.20. A-Board (15/19) Schematic Diagram A-BOARD (15/19) Panel-D P3.3V IC9300 C1AB00003258 P2.5V PD4H L9302 J0JHC0000117 *IC9300 VDD33 *IC9300 AA28 MLVDS_VDD C1AB00003259 P1.2V *IC9300 VDD33 *IC9300 AA29 MLVDS_VDD C9356 C9380 *IC9300 VDD33 *IC9300 AA30 MLVDS_VDD 0.1u 0.1u *IC9300 *IC9300 AK20 *IC9300 *IC9300 *IC9300 AF13...

  • Page 65: A-Board (16/19) Schematic Diagram

    12.21. A-Board (16/19) Schematic Diagram A-BOARD (16/19) POWER IC5401 F15V C0DBGYY00884 VOUT 3 C5722 100mA C5723 DCDC15V L5606 SUB9V TP5409 G1C100MA0077 C5634 R5627 0.1u Q5605 B1MBEDA00015 F15V 3.32V/2A R5635 C5628 C5626 SUB3.3V TP5602 DRVH1 D5602 R5609 R5607 VBST1 R5600 DZ2J056M0L DRVL1 L5604 G1C3R3Z00005...

  • Page 66: A-Board (17/19) Schematic Diagram

    12.22. A-Board (17/19) Schematic Diagram A-BOARD (17/19) R2882 7.15k R2880 14.3k R2881 R2883 6.65k 1.74k R2884 KEY_SCAN TO 6/19 C2885 C2886 C2871 IC2870 P-BOARD S_15V TPS15V Panel-D C0DBAYY00462 (P6) +15V_S C2877 BOOT 0.022u P15V TP9196 +15V_S R2875 R2871 "H": ON "L": OFF +15V_C DCDC_CTL1...

  • Page 67: A-Board (18/19) Schematic Diagram

    12.23. A-Board (18/19) Schematic Diagram A-BOARD (18/19) Achip Dchip SUB1.2V USB I/F R8007 SIF I/F Analog Audio In I/F L8002 SUB1.2V AG31_MMCK J0JKC0000021 AG32_MMXCK L8017 C8004 C8073 C8075 J0JHC0000045 D15_VREFHSIF C10_BIAS D21_VREF1V5 C8036 0.1u C8005 6.3V 6.3V VDD12 TO 2/19 AA11_VDDUSB TO 2/19 2/19...

  • Page 68: A-Board (19/19) Schematic Diagram

    12.24. A-Board (19/19) Schematic Diagram A-BOARD (19/19) DCDC15V F15V L5603 PA5610 L5602 G1C100MA0077 J0JHC0000075 K5H4022A0031 C5611 R5616 C5608 0.1u R5628 C5604 C5600 SUB1.8V TP5601 DRVH1 VBST1 DRVL1 L5601 G1C3R3Z00004 PGND1 Q5600 R5602 2.7k R5606 B1MBDDA00003 0.5% R5604 TRIP1 R5636 R5645 VFB1 0.5% C5607...

  • Page 69: K-Board And S-Board Schematic Diagram

    12.25. K-Board and S-Board Schematic Diagram K-BOARD TNPA5143AB S-BOARD SUB3.3V STBY3.3V TNPA4858AB C2515 REMOTE CONTROL SENSOR 0.01u R2513 AI SENSOR RM2510 SN2510 B3RAD0000168 B3JB00000078 *D2520 R2510 POWER LED POWER SWITCH B3AGB0000060 3 VCC SW2500 G R LED C2521 K0F162B00002 0.1u H RED 2 GND *R2516...

  • Page 70: C1-Board Schematic Diagram

    12.26. C1-Board Schematic Diagram C1-BOARD TNPA5167 ZA17104 K4CD01000013 C17107 R17118 100V 0.33u R17129 ZA17102 K4CD01000013 C1_3.3V 3.3V_DET 3.3V_DET R17116 P3.3V ZA17103 P3.3V ZA17105 ZA17101 K4CD01000013 K4CD01000013 K4CD01000013 AB_LED1 C1_3.3V PANEL DATA C17101 ODE1 AB_PCD1 DRIVER AB_CLRD1 CLR1 DD1_2- DD1_2- DD1_2+ DD1_2+ DD1_1- DD1_1-...

  • Page 71: C2-Board (1/2) Schematic Diagram

    12.27. C2-Board (1/2) Schematic Diagram C2-BOARD TNPA5168 (1/2) AB_CLRD1 AB_PCD1 AB_ODED1 AB_LED1 R17233 R17231 R17230 AA_LED1 EXB38V470JV C17217 100p AA_ODED1 AB_LED2 AA_PCD1 AB_ODED2 AA_PCD2 AA_PCD2 AB_PCD2 AB_CLRD2 AA_CLRD1 C2_3.3V R17232 R17229 EXB38V470JV R17216 R17228 C17206 EXB38V681JV 0.1u IC17201 C0JBAU000088 BUFFER 3.3V_DET_I 3.3V_DET C2_3.3V...

  • Page 72: C2-Board (2/2) Schematic Diagram

    12.28. C2-Board (2/2) Schematic Diagram C2-BOARD TNPA5168 (2/2) ZA17204 K4CD01000013 ZA17205 K4CD01000013 CB10 A-BOARD ZA17203 ZA17201 ZA17202 (A31) K4CD01000013 K4CD01000013 K4CD01000013 TERM C2_3.3V VJ17201 C3-BOARD (C36) 3.3V_DET_I 3.3V_DET C2_3.3V P3.3V P3.3V DD9_2- DD9_2- DD9_2+ DD9_2+ DD9_1- DD9_1- DD9_1+ DD9_1+ DRVCLK6- DRVCLK6- R17218 C17209...

  • Page 73: C3-Board (1/2) Schematic Diagram

    12.29. C3-Board (1/2) Schematic Diagram C3-BOARD TNPA5169 (1/2) SS-BOARD TERM (SS33) A-BOARD SS_5V (A32) TERM SS_5V C3_3.3V VJ17301 DRVSOS8 SS_5V C17323 0.1u R17316 220k AA_UEH AB_UEH AA_USL AB_USL R17329 P-BOARD EXB38V470JV AA_USH (P35) AA_UML AB_USH 3.3V_DET AB_UML AA_UMH C3_3.3V AB_UMH P3.3V 10 GND R17330...

  • Page 74: C3-Board (2/2) Schematic Diagram

    12.30. C3-Board (2/2) Schematic Diagram C3-BOARD TNPA5169 (2/2) R17317 R17323 C17309 C17315 100V 100V 0.33u 0.33u CB11 CB14 C3_3.3V C3_3.3V PANEL DATA C17301 PANEL DATA C17304 DRIVER DRIVER R17319 C17311 R17325 100V C17316 100V 0.33u 0.33u R17336 CB12 CB15 C3_3.3V C3_3.3V C17305 PANEL DATA...

  • Page 75: Sc-Board (1/4) Schematic Diagram

    12.31. SC-Board (1/4) Schematic Diagram Vsus SC-BOARD TXNSC1LDUM (1/4) P-BOARD (P2) VSUS Vsus C16411 C16418 C16412 TPVSUS C16416 220V 250V 220V 220V 300u 300u 1.5u 300u A-BOARD (A20) IC16561 SC20 C0JBAU000088 TP16 TP17 BUFFER TP18 C16561 R16580 5.6k C16562 R16561 TP36 EXB38V470JV TP46...

  • Page 76: Sc-Board (2/4) Schematic Diagram

    12.32. SC-Board (2/4) Schematic Diagram Vsus Vsus Vsus 16V_F SC-BOARD TXNSC1LDUM (2/4) IC16771 C0CBADC00072 *D16402 DA3DF50ACSLW Vad+5V Vad+5V 16V_F VOUT *D16403 R16534 C16771 DA3DF50ACSLW C16796 470u D16534 Q16501 D16536 C16401 B0ECHR000001 B0ECHR000001 630V B1HFPFA00001 5600p R16503 R16504 R16512 C16502 C16503 R16511 470u PC16461...

  • Page 77: Sc-Board (3/4) Schematic Diagram

    12.33. SC-Board (3/4) Schematic Diagram Vsus Vsus 16V_F SC-BOARD TXNSC1LDUM (3/4) 16V_F R16604 Vsus AA_CERS C16602 PC16603 R16633 R16765 B3PBA0000498 AA_CPH1 D16497 B0ECKP000055 Q16607 R16631 PC16684 B1CBGD000001 B3PBA0000496 D16765 B0ECKP000055 C16603 C16604 C16490 D16618 R16494 R16498 630V 630V R16609 1000p 1000p B0ECKP000055 R16495...

  • Page 78: Sc-Board (4/4) Schematic Diagram

    12.34. SC-Board (4/4) Schematic Diagram R16719 TP45 AA_SEL SC-BOARD TXNSC1LDUM (4/4) SOS7_SC2 TP41 R16752 AA_SIU 4.7k D16820 B0ACCJ000048 R16774 R16751 TP42 AA_OC2 150k D16821 TP125 DZ2J330M0L Q16876 TP43 AA_CLK B1ABCF000231 R16721 R16783 EXB38V220JV D16871 150k DZ2J240M0L TP44 AA_OC1 D16875 B0ACCJ000048 Vsus R16758 R16755...

  • Page 79: Ss-Board (1/2) Schematic Diagram

    12.35. SS-Board (1/2) Schematic Diagram SS-BOARD TXNSS1LDUM (1/2) Vsus R16031 R16032 R16033 *Q16002 R16034 B1JADN000008 *R16002 P-BOARD Q16055 Q16141 (P11) R16171 B1HFPFA00001 B1HFPFA00001 *Q16003 *Q16041 SS11 B1JAEN000010 R16141 B1JADN000008 VSUS *R16003 *R16041 *C16071 VSUS 630V R16172 1000p R16173 *C16012 *C16013 *C16014 *C16031 220V...

  • Page 80: Ss-Board (2/2) And Ss2-Board Schematic Diagram

    12.36. SS-Board (2/2) and SS2-Board Schematic Diagram SS24 SS-BOARD TXNSS1LDUM (2/2) SS53 SS54 FPC protector SS55 ZA16003 K4AZ01D00004 D16285 TP55 B0ADEJ000035 C16286 R16291 330k SS53 0.1u TP56 R16292 C16287 C16280 R16281 330k R16284 0.1u 220k Q16280 SS11 SS56 D16286 B1ABCF000231 D16282 B0ADEJ000035 DZ2J068M0L...

  • Page 81: Printed Circuit Board

    13 Printed Circuit Board 13.1. P(MAIN)-Board P(MAIN)-BOARD (FOIL SIDE) ETX2MM812MSM...
  • Page 82 P (MAIN) Parts Location Parts Location P(MAIN)-BOARD (FOIL SIDE) P(MAIN)-BOARD (COMPONENT SIDE) TRANSISTOR TRANSISTOR TEST POINT Q601 Q602 IC201 Q201 IC201 Q201 Q603 IC202 Q202 Q202 IC501 Q604 IC251 Q203 Q355 Q605 MODULE IC352 Q204 Q401 VOLUME Q606 IC403 Q251 Q402 Q607 MC551...
  • Page 83 P(MAIN)-BOARD (COMPONENT SIDE) ETX2MM812MSM...

  • Page 84: P(Sub)-Board

    13.2. P(SUB)-Board P (SUB) Parts Location P(SUB)-BOARD (FOIL SIDE) TRANSISTOR TEST POINT IC801 Q801 IC901 Q802 IC902 Q803 VOLUME IC951 Q804 Q805 VR951 Q806 PHOTO COUPLER Q807 Q808 PC801 Q809 PC902 Q901 PC903 Q902 Q903 Q904 Q951 Q952 P(SUB)-BOARD (FOIL SIDE) ETX2MM812MSS...
  • Page 85 P (SUB) Parts Location P(SUB)-BOARD (COMPONENT SIDE) TRANSISTOR TEST POINT IC901 Q801 Q804 Q806 Q901 VOLUME Q902 VR951 P(SUB)-BOARD (COMPONENT SIDE) ETX2MM812MSS...

  • Page 86: K, S And Ss2-Board

    13.3. K, S and SS2-Board S-BOARD (COMPONENT SIDE) S-BOARD (FOIL SIDE) TNPA4858AB TNPA4858AB T N P A 4 8 5 8 P b F S E E R E V E R S E F O R O R D E R N O . S W 2 5 0 0 K-BOARD (FOIL SIDE) K-BOARD (COMPONENT SIDE)

  • Page 87: A-Board

    13.4. A-Board A-BOARD (FOIL SIDE) TZTNP01LDUM(M) TZTNP01LDUP(P) TZTNP01ADAR(R) TP9194 TP9197 TP9199 TP9198 C2312 TP9193 TP9195 TP9206 TP9205 TP2878 A 1 1 C2357 R9907 TP2875 C2329 L2304 TP9192 TP2302 TP9104 TP9103 TP9102 TP9101 TP9097 TP9912 TP9913 C2343 TP9082 TP9084 TP9086 TP9087 TP9089 TP9092 TP9094...
  • Page 88 A-BOARD (COMPONENT SIDE) TZTNP01LDUM(M) TZTNP01LDUP(P) TZTNP01ADAR(R) T H E R M A L P A D I C 2 3 0 1 C2333 C2322 A32A A31A Q 9 9 0 0 A20A L2306 C2888 A 1 1 C2355 C2354 Q 9 9 0 1 IC2301 C2880 L2305...

  • Page 89: C1-Board

    13.5. C1-Board C1-BOARD (FOIL SIDE) TNPA5167 P b F TNPA5167 S E E R E V E R S E F O R O R D E R N O . 1 2 3 C1-BOARD (COMPONENT SIDE) TNPA5167 CR No.17 TNPA5167 O R D E R N O .

  • Page 90: C2-Board

    13.6. C2-Board C2-BOARD (FOIL SIDE) TNPA5168 T N P A 5 1 6 8 1 P b F S E E R E V E R S E F O R O R D E R N O . 1 2 3 C2-BOARD (COMPONENT SIDE) TNPA5168 ZA204...

  • Page 91: C3-Board

    13.7. C3-Board C3-BOARD (FOIL SIDE) TNPA5169 T N P A 5 1 6 9 1 P b F 1 2 3 S E E R E V E R S E F O R O R D E R N O . C3-BOARD (COMPONENT SIDE) TNPA5169 R 3 3 1...

  • Page 92: Sc-Board

    13.8. SC-Board SC-BOARD (FOIL SIDE) TXNSC1LDUM Z A 4 2 1 Z A 4 2 2 T P 1 0 5 T P 1 0 9 T P 1 0 6 T P 3 4 T P 1 0 7 T P 6 3 T P 6 2 T P 6 1...
  • Page 93 SC-BOARD (COMPONENT SIDE) TXNSC1LDUM I C 4 7 1 H.V. DANGER H.V. DANGER P C 4 8 0 H.V. DANGER H.V. DANGER D 7 9 4 C 7 9 7 Z A 4 2 2 Z A 4 2 1 Z A 4 1 2 Z A 4 1 1 R 7 9 7...

  • Page 94: Ss-Board

    13.9. SS-Board SS-BOARD (FOIL SIDE) TXNSS1LDUM S S 5 6 S S 5 5 S S 5 4 S S 5 3 C 0 9 4 T N P A 5 1 7 6 1 2 3 P b F S E E R E V E R S E F O R O R D E R N O .
  • Page 95 SS-BOARD (COMPONENT SIDE) TXNSS1LDUM SS53 SS54 SS55 SS56 C 0 2 4 C 0 2 3 C 0 2 2 C 0 2 1 CR No.16 T N P A 5 1 7 6 D I P C 0 9 4 C 2 2 5 C 2 2 4 C 2 2 3...

  • Page 97: Exploded View And Replacement Parts List

    14 Exploded View and Replacement Parts List 14.1. Exploded View and Mechanical Replacement Parts List 14.1.1. Exploded View 1...
  • Page 98 14.1.2. Exploded View 2...
  • Page 99 14.1.3. Packing 1...
  • Page 100 14.1.4. Packing 2...
  • Page 101 14.1.5. Packing 3...
  • Page 102 PLASMA DISPLAY PANEL N2QAYB000370 REMOTE CONTROL TBLA3689 STAND POLE R TBLA3690 STAND POLE L TBLX0157 PEDESTAL STAND TBMA322 PANASONIC BADGE TBX3EA00101 POWER BUTTON THEL0429 SCREW 8 chap. 3.1. (3) THEL065Z SCREW(BC_TOP:5 BC_BOT:2 BC_L:2) 9 chap. 3.1. (1) THEL073N SCREW (STAND-TV)
  • Page 103 Ref. Safety Part No. Part Name & Description Q'ty Remarks TPCC78101 CARTON BOX TOP(WITH STAMP) TPCC78105 CARTON BOX TOP(WITH STAMP) TPCC78104 CARTON BOX TOP(WITH STAMP) TPD169487 JOINT TPDA2066-1 PEDESTAL CUSHION TPDA2245 TOP CUSHION TPDA2246 BOTTOM CUSHION TPDF2305 TOP PAD TPDF2393 TYPE-REINFORCEMENT_BAR TPEB362 BAG (STAND ACCESSORY)
  • Page 104 Ref. Safety Part No. Part Name & Description Q'ty Remarks XTT4+12GFJK SCREW(BC:11) 11 chap. 3.1. (2) XTV3+10JFJK SCREW(REAR AV:2) XYN3+F10FJK SCREW(BC-AC_INLET:2) 2 chap. 3.1. (4) XYN3+J10FJ SCREW XYN4+E6FJ SCREW(INLET:1) XYN4+F10FJ SCREW(AL-GHT:4) XYN5+F25FN SCREW (STAND POLE) XYN6+F14FJ SCREW(HANGER METAL ASSY:10) XZB17X19C03 POLY BAG (STAND POLE)

  • Page 105: Electrical Replacement Parts List

    14.2. Electrical Replacement Parts List 14.2.1. Replacement Parts List Notes...
  • Page 106 14.2.2. Electrical Replacement Parts List Safety Ref. No. Part No. Part Name & Pcs Remarks Description Safety Ref. No. Part No. Part Name & Pcs Remarks C2337 F1J1H474A757 C 0.47UF, 50V Description C2338 F1H1E104A129 C 0.1 uF 25 V TZTNP01ADAR CIRCUIT BOARD A (RTL) R C2339...
  • Page 107 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C3137 F1G1H561A730 C 560 pF 50 V C5634 F1H1C104A143 C 0.1UF, 16V C3138 F1G1H561A730 C 560 pF 50 V C5635 F1H1C105A145 C 1 uF 16 V C3149...
  • Page 108 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C8091 F1G1C104A116 C 0.1UF 16V C9347 ECJ1VB0J105K C 1UF, 6.3V C8093 ECJ1VB0J105K C 1UF, 6.3V C9349 F1J1A106A087 C 10UF, 10V C8097 F1G1C104A116 C 0.1UF 16V C9350...
  • Page 109 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C16242 F1H1C105A145 C 1 uF 16 V C16646 F1K2J102A014 C 1000PF, 630V C16243 F1H1H103A970 C 0.01 uF 50 V C16661 F1K2J102A038 C 1000PF, 630V C16244...
  • Page 110 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C17309 F1L2A334A034 C 0.33 UF 200 V D16051 B0FBCN000005 DIODE C17311 F1L2A334A034 C 0.33 UF 200 V D16052 B0FBCN000005 DIODE C17312 F1L2A334A034 C 0.33 UF 200 V...
  • Page 111 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description D16673 B0ECHR000001 DIODE IC16692 C0DBZYY00352 IC D16674 B0ECHR000001 DIODE IC16724 C0CBADE00049 IC D16677 B0ADEJ000035 ZENER DIODE IC16771 C0CBADC00072 IC D16678 DZ2J15000L ZENER DIODE...
  • Page 112 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description L8007 J0JHC0000045 CHIP INDUCTOR Q5471 DSA200100L TRANSISTOR L8008 J0JHC0000045 CHIP INDUCTOR Q5472 DSC2001S0L TRANSISTOR L8009 J0JHC0000045 CHIP INDUCTOR Q5600 B1MBDDA00003 FET L8010...
  • Page 113 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description Q16702 B1ABCF000231 TRANSISTOR R1186 D0GA473JA015 M 47KOHM, J,1/ Q16762 B1HFPFA00001 TRANSISTOR R1187 D0GA273JA015 M 27K OHM J ,1/ Q16801 DSA2001S0L TRANSISTOR...
  • Page 114 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R2320 ERJ8GEYJ3R3V M 3.3 OHM, J,1/ R3106 D0GA333JA015 M 33KOHM,J,1/16W R3107 D0GA333JA015 M 33KOHM,J,1/16W R2321 ERJ8GEYJ3R3V M 3.3 OHM, J,1/ R3108 D0GA101JA015 M 100 OHM, J,1/ R2510...
  • Page 115 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R4659 ERJ2GEJ220 M 22 OHM, J,1/16 R5050 D0GA473JA015 M 47KOHM, J,1/ R4663 ERJ2GEJ220 M 22 OHM, J,1/16 R5051 D0GA473JA015 M 47KOHM, J,1/ R4668 D0GA330JA015 M 33 OHM, J,1/...
  • Page 116 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R5613 D0GA473JA015 M 47KOHM, J,1/ R8499 D0GA680JA015 M 68 OHM, J,1/ R5616 D0GB100JA041 M 10 OHM J 1/10W R8500 EXB2HV103JV M 10 kOHM 1/16 W...
  • Page 117 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R8870 ERJ2GEJ103 M 10KOHM, J,1/16 R9203 D0GA272JA015 M 2.7KOHM, J.1/ R8872 D0GA330JA015 M 33 OHM, J,1/ R9205 D0GA333JA015 M 33KOHM,J,1/16W R9206 D0GA563JA015 M 56KOHM, J,1/ R8873...
  • Page 118 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R16051 D0GF5R6JA047 M 5.6 OHM,J, 1/ R16307 ERJ6RBD5112 M51.1KOHM,D.1/ R16052 D0GF5R6JA047 M 5.6 OHM,J, 1/ R16309 ERG1FJS333D M 33KOHM, J, 1W R16318 ERJ6RBD7682 M76.8KOHM,D.1/...
  • Page 119 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R16504 D0GD750JA059 M 75 OHM,J,1/4W R16634 ERJ6GEYJ471 M 470 OHM,J,1/8W R16505 D0GD100JA059 M 10 OHM,J,1/4W R16645 D0GB562JA041 M 5.6KOHM,J,1/ R16506 D0GD100JA059 M 10 OHM,J,1/4W R16646...
  • Page 120 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R16751 D0GD154JA059 M 150KOHM,J,1/4W R16921 D1BB1241A055 M1.24KOHM,J.1/ R16752 ERJ3GEYJ472 M 4.7KOHM,J,1/ R16922 D1BB3481A055 M3.48KOHM,J.1/ R16753 ERJ6GEYJ104V M 100KOHM,J,1/8W R16923 D0GB103JA057 M 10K OHM J 1/ R16755...
  • Page 121 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R17208 ERJ3GEYJ101 M 100 OHM,J,1/ R17337 D0GBR00Z0002 M 0 OHM J 1/10W R17338 D0GBR00Z0002 M 0 OHM J 1/10W R17209 ERJ3GEYJ101 M 100 OHM,J,1/...
  • Page 122 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C205 ECWH8473HA P 0.033UF 800V C560 ACRZL1E221T 25V 220P C206 ACKX331KYP 250V 330p C561 ACRZL1H100T 50V 1000P C573 ACDE1R152KP 1kV 1500p C207...
  • Page 123 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description D608 VDERA83-004T DIODE AKB11B-PH-KS 11P CONNECTOR D610 VD1SS133T DIODE AKB14B-PH-KS 14P CONNECTOR D701 VDERA83-004T DIODE AKS02B-VT CONNECTOR D705 VD1SS133T DIODE AKB3P4VH-B-L 3P CONNECTOR...
  • Page 124 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R206 ERJ6ENF3903 M 390KOHM,J1/8W R391 ERJ6GEYJ183V M 18KOHM,J,1/8W R207 ERJ6ENF3903 M 390KOHM,J1/8W R392 ERJ6ENF3921 M3.92KOHM,F.1/8W R208 ERJ6ENF3903 M 390KOHM,J1/8W R393 ERJ6GEYJ472V M 4.7KOHM.J.1/8W R209...
  • Page 125 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R530 ERJ3GEYJ471 M 470 OHM,J,1/ R619 ERJ6ENF3163 M 316KOHM,F. 1/ R531 ERJ6ENF1002 M 10KOHM,F. 1/8W R620 ERJ6ENF3163 M 316KOHM,F. 1/ R532 ERJ6ENF4123 M 412KOHM,F.
  • Page 126 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R751 ERJ6GEYJ102V M 1K OHM J 1/8W C808 ECJ1VB1H222K C 2200UF, 50V R752 D0GB103JA057 M 10K OHM J 1/ C809 ACTEB104K5T 50V 0.1P...
  • Page 127 Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description L803 ETB42AZ14GAD TRANSFORMER R855 ERJ6GEYJ220 M 22 OHM,J,1/8W R856 ERJ6GEYJ220 M 22 OHM,J,1/8W L901 AYTSKA170T FERRITE BEAD INDUCTOR R857 ERJ6GEYJ220 M 22 OHM,J,1/8W...
  • Page 128 Safety Ref. No. Part No. Part Name & Pcs Remarks Description R970 ERJ6ENF4992 M49.9KOHM,F.1/8W R971 ERJ6ENF4992 M49.9KOHM,F.1/8W R972 ERJ6ENF4992 M49.9KOHM,F.1/8W R973 ERJ6ENF4992 M49.9KOHM,F.1/8W R974 ERJ6ENF4872 M48.7KOHM,F.1/8W R975 ERJ6ENF8252 M82.5KOHM,F.1/8W R976 D0GB103JA057 M 10K OHM J 1/ R977 ERJ6ENF1873 M187KOHM,F. 1/8W R978 D0GB103JA057 M 10K OHM J 1/ R979...

This manual is also suitable for:

Th-p58s20pTh-p58s20r

Table of Contents
