Getting started with your
Castles V3M2 Mobile

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V3M2 Mobile and is the answer not in the manual?

Questions and answers

Summary of Contents for CASTLE V3M2 Mobile

  • Page 1 Getting started with your Castles V3M2 Mobile...
  • Page 2 What’s in the box Thank you for ordering the Castles V3M2 Mobile payment terminal. In the box you will find: • Castles V3M2 3G terminal • Charging deck • 2x Till Rolls • Micro USB and USB Plug Adaptor • Installation guide...
  • Page 3 Setting up your terminal Step 1 Connect the USB cable to power adaptor. Step 2 Once the power supply is connected to the power outlet, connect the micro-USB to the terminal. Step 3 Turn the power outlet ON and the orange power light will come on showing the terminal is charging.
  • Page 4 Charging dock setup Step 1 Place the charging dock on a soft surface with the back facing up. Step 2 Lift the cable tidy. Step 3 Connect the power cable into the DC 9V port and the power supply to the power outlet.   Step 4 The green power indicator will appear when the charging dock is receiving power.
  • Page 5 Install the till roll Step 1 Pull upwards on the lever located in the middle of the printer door. Step 2 Place the till roll in the compartment. The paper must feed from underneath the roll. Step 3 Close the printer door.
  • Page 6 How to take a payment Step 1 power button Press and hold the (above the red key) until the screen lights up. The terminal will power on and initialise for use. Step 2 ‘enter amount’ When the screen is displayed, attempt a test transaction with your own payment card.
