Summary of Contents for Hvac specialty Hydro Header 300
- Page 1 Hydro Header 300 Installation Manual...
- Page 3 CONTENTS Hazzard Conditions ........Note: This product is designed to be Important Note..........used with Boilers with inputs up What’s Included........... to 200,000 Btu/Hr. The design relies on the boiler’s integral Component Drawings........pump as the primary pump for the header system. Hanging the Boiler........
- Page 4 Important Note: The contents of this manual are intended as guidelines for licensed professional installers. The manual is not a “do-it-yourself” guide for the non-professional. This manual is not intended to take the place of the boiler manufacturer’s installation manual which should be carefully followed.
- Page 5 COMPONENTS...
- Page 6 Installation Steps Mount Hydro Header wall bracket • If installing on a framed wall be sure to secure to a stud or use wall anchors to support 85lbs. Place Hydro Header on wall bracket. Slide the Hydro Header along the wall bracket to desired location.
- Page 7 • Wire the boiler manufacturer’s supplied and recommended controls according to the installation manual supplied with the boiler and controls. • The Hydro Header 300 comes with pumps that are pre-wired to a zone relay. Provide 115V AC to the pump relay with a disconnect switch following local electrical codes.
