Summary of Contents for Glensound GS-PM4
- Page 1 GS-PM4 Dante Network Paging Microphone PRODUCT DETAILS 6 BROOKS PLACE, MAIDSTONE, KENT, ME14 1HE. ENGLAND. TEL: +44 (0) 1622 753662 Visit our Website at www.glensound.com FAX: +44 (0) 1622 762330...
- Page 2 Glensound Electronics Ltd Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with the product then we can be contacted at: Glensound Electronics Ltd 1 –...
-
Page 3: Product Warranty
PRODUCT WARRANTY All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible and guar- antee to be able to support your product for a minimum of 10 years. For a period of one year after the goods have been despatched the Com- pany will guarantee the goods against any defect developing after proper use providing such defects arise solely from faulty materials or workman-... -
Page 4: Eu Declaration Of Conformity
Visual indicator Dante intercom This declaration of conformity is issued under the sole responsibility of the manufacturer. This equipment is manufactured by Glensound Electronics Ltd of Brooks Place Maidstone Kent ME14 1HE is marked and conforms to the following Union harmonisation legislation:... -
Page 5: Rohs Directive
RoHS DIRECTIVE RoHS 2 Directive 2011/65/EU restricts the use of the hazardous substances listed below in electrical and electronic equipment. This product conforms to the above directive and for these purposes, the maximum concentration values of the restricted substances by weight in homogenous materials are: Lead 0.1%... -
Page 6: Waste Electrical And Electronic Equipment Regulations 2006 (Weee)
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR Page... - Page 7 Page...
-
Page 8: Table Of Contents
Specifications ............................. 13 GPIO Pinout ............................13 XLR Pinout ............................13 CONNECTING THE GS-PM4 UNIT TO A DANTE NETWORK ............14 Getting Dante Controller ........................14 Connecting GS-PM4 device to the network ..................14 Audio Over IP Network ........................14 Running Dante Controller ......................... -
Page 9: Overview
As such the GS-PM4 is fully compatible with other manufacturers’ equipment using the Dante protocol. All units in the system are designed to be very easy to use for the operator and simple to setup for the technician. -
Page 10: Gs-Pm4 Front Panel Layout
GS-PM4 FRONT PANEL LAYOUT Microphone Input 3-Pin XLR Connector. Support condenser and dynamic microphones Zone Talk Buttons Used to talk out throw the PM4, illuminated buttons indicate when a Zone is Open/Live Power LED This LED indicated the power status of the device. This LED also doubles to indicate the status of the configuration mode. -
Page 11: Gs-Pm4 Rear Panel Layout
GS-PM 4 REAR PANEL LAYOUT 1. USB type-C update Port This USB Type-C connector is used only for device firmware updates. Please refer to the firmware update section of the manual for a firmware update guide 2. Setup Button Is used to put the unit in to Setup Mode or Update mode 3. -
Page 12: Normal Operation
4 Dante inputs to their corresponding outputs. If a Zone Take Button is se- lected the GS-PM4 will mute the pass-through feed to that channel to allow you to speak and will resume the feed once the user has released the Zone Take Button. -
Page 13: Keypad Operation
Keypad Operation Mode: Momentary Press and hold any combination of the 4 Zone buttons to bring up the Lines. If the chime function is Enabled the selected Zone buttons will start Flashing blue, please wait for the selected Zone buttons to go Steady blue before speaking. To Stop speaking Simply release the selected Zone buttons. -
Page 14: Specifications
Specifications Power Consumption: < 3W POE Stranded: IEEE 802.3af-2003 Network Port type: RJ45/Ethercon Network Port Speed: 100Mbs Input: 3Pin Balanced XLR EIN 150R 20-22k Dynamic mic, max gain. -124dBu FRQ Response: LCF OFF: 100Hz-20KHz +/-1dB LCF ON : 300Hz-20KHz +/-1dB GPIO: Inputs Max Voltage : 3.3V Output Max Voltage: 5V Open Collector... -
Page 15: Connecting The Gs-Pm4 Unit To A Dante Network
Getting Dante Controller If you are connecting the GS-PM4 to a new Dante network the first thing you will need to do is to get the free Dante controller software from Audinate. This can be downloaded by visiting Audinate’s web site at www.audinate.com... -
Page 16: Running Dante Controller
At the time of writing this manual the Dante Controller looks as per the screenshot below: The GS-PM4 will have been named at the factory during test to allow them to be identified by the Dante controller. The format used for the factory name is: ‘GLENSOUND-GS-PM4-SN-XXXX’... -
Page 17: Device Not Showing Up In Dante Controller
Device not showing up in Dante Controller If your Dante device does not show up in Dante Controller then the most likely issue is that the device’s IP Address is not appropriate for your network. A) It maybe that the device is set to obtain an IP address automatically using DHCP (this is the default configuration) and your network is setup for fixed IP addresses only and does not have a DHCP server. -
Page 18: Updating Firmware
“DfuSe_Demo_V3.0.5_Setup.exe”, then run and install it. 2. Download firmware The latest firmware for the GS-PM4 can be found on the Glensound website, under the respective product page. Once you have downloaded the file, place it in a folder or location of your choice. - Page 19 If the file loads successfully then it will read along the bottom ‘File correctly loaded’. 2. Upgrading the GS-PM4 firmware The firmware is now ready to be put on to the GS-PM4, Tick the ‘Verify after download’ box first and then click ‘Upgrade’. Click yes to proceed.
-
Page 20: Updating The Ultimo Chipset
Finding Out Current Installed Version Using Dante ® controller double click on the GS-PM4 device name in the routing tab to open the Device View box. Ion the Device View box open the Status Tab. The ‘Product Version:’ shows the currently installed version of Ultimo Chipset dnt code.
